- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Hikvision DS- D5022FN-C o cerca il tuo prodotto tra le migliori offerte di Monitor Monitor User Manual...
-
Page 2: Legal Information
The Manual includes instructions for using and managing the Product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons. Please find the latest version of this Manual at the Hikvision website (https://www.hikvision.com/). -
Page 3: Regulatory Information
Monitor • User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 4: Applicable Models
Monitor • User Manual Applicable Models This manual is applicable to monitor. Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text. Indicates a potentially hazardous situation, which if not avoided, could result in equipment damage, data loss, performance degradation, or unexpected results. - Page 5 Keep vertical when moving or using the equipment. CAUTION: This equipment is for use only with specified bracket (Hikvision's monitor stand). Use with other (carts, stands, or carriers) may result in instability causing injury.
-
Page 6: Table Of Contents
Monitor • User Manual TABLE OF CONTENTS Chapter 1 Introduction ......................... 1 Key Features ..........................1 Packing List ..........................1 Power On ..........................1 Chapter 2 Device Interface ......................2 Chapter 3 Panel Buttons ....................... 3 Chapter 4 Basic Operation ......................4 Select the Signal Source ...................... -
Page 7: Chapter 1 Introduction
Monitor • User Manual Chapter 1 Introduction Key Features 8-bit/10-bit dual channel LVDS (1920 × 1080) HD display. 3D digital comb filter. Hi-Fi color OSD and user-friendly menu for operation. Programmable 12-bit RGB gamma correction. Complete factory setting mode. ... -
Page 8: Chapter 2 Device Interface
Monitor • User Manual Chapter 2 Device Interface The device panel interfaces vary with different models. Panel Interface Interface Description Interface Description Interface Description HDMI HDMI digital signal input VGA analog signal input interface interface DC 12V Direct current power adapter interface... -
Page 9: Chapter 3 Panel Buttons
Monitor • User Manual Chapter 3 Panel Buttons The buttons at the bottom-right corner of the monitor panel are shown as follows. Panel Buttons Button Description Button Description Power On/Off MENU, signal source, and volume pages: Exit MENU, signal source, and volume pages. ... -
Page 10: Chapter 4 Basic Operation
Monitor • User Manual Chapter 4 Basic Operation The interfaces vary with different models. The figures followed are for illustration purpose only. Select the Signal Source Connect the device to power source and signal source, and power the device on. Press to enter the signal source page as follows. -
Page 11: Luminance
Monitor • User Manual Luminance Luminance Parameters Parameter Description Brightness The brightness of image. Ranges from 0 to 100. The higher the value is, the brighter the display will be. Contrast The contrast of image color. Ranges from 0 to 100. The higher the value is, the clearer the image will be. -
Page 12: Color Setup
Monitor • User Manual Image Setup Parameter Description Adjust horizontal display position of image. H. Position Ranges from 0 to 100. Adjust vertical display position of image. V. Position Ranges from 0 to 100. Adjust image clock to reduce vertical noise. Clock Ranges from 0 to 100. -
Page 13: Osd Setup
Monitor • User Manual Color Parameters Parameter Description Adjust the style of the color display. Color Temp. Optional: Warm/User/Cool/Normal Adjust the value to change color temperature. Red/Green/Blue Ranges from 0 to 100. LowBlue Mode can reduce the damage of blue light to the eyes to a certain extent. -
Page 14: Reset
Monitor • User Manual OSD Parameters Parameter Description Optional: 简体中文/English. Language Adjust horizontal display position of OSD H. Position menu. Ranges from 0 to 100. Adjust vertical display position of OSD menu. V. Position Ranges from 0 to 100. Adjust transparency degree of OSD menu. Transparence Ranges from 0 to 100. -
Page 15: Extra
Monitor • User Manual Reset Parameters Parameter Description Adjust horizontal/vertical position, clock, and Auto Config. phase parameters of image automatically. AutoColor Adjust color balance automatically. Reset Restore to factory settings. Set the time for screen to enter the automatic sleep mode. Dormancy Time Optional: Off Timer/5 Minute/10 Minute/15 Minute/30 Minute. - Page 16 UD25222B...
