Summary of Contents for HIKVISION DS-D5027F2-2P2
- Page 1 Monitor User Manual...
- Page 2 This product can only enjoy the after-sales service support in the country or region where the purchase is made. Acknowledgment of Intellectual Property Rights ●Hikvision owns the copyrights and/or patents related to the technology embodied in the Products described in this Document, which may include licenses obtained from third parties.
- Page 3 OR IMPLIED, INCLUDING WITHOUT LIMITATION, MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE. THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL HIKVISION BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR INDIRECT DAMAGES, INCLUDING, AMONG OTHERS,...
-
Page 4: Fcc Conditions
Monitor User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. -
Page 5: Applicable Models
Monitor User Manual Applicable Models This manual is applicable to the model: Monitor. Symbol Conventions The symbols that may be found in this document are defined as follows. Safety Instructions • Proper configuration of all passwords and other security settings is the responsibility of the installer and/or end-user. -
Page 6: Table Of Contents
Monitor User Manual TABLE OF CONTENTS 1.Introduction ......................1 1.1 Key Features......................1 1.2 Power Supply Connection..................1 2.Device Interfaces....................... 2 3.Panel keys ........................3 4.Basic Operation ......................4 4.1 Input Source Selection..................... 4 4.2 Brightness........................ 4 4.3 Audio Volume Adjustment(optional)..............4 4.4 Auto Adjust...................... -
Page 7: Chapter1. Introduction
Monitor User Manual Chapter1. Introduction 1.1 Key Features Supports 1920 × 1080 FHD display; User-friendly operation menu; Three image modes to adapt different environment; 1 channel HDMI 1.4 input interface; Supports software spread-spectrum technology to reduce EMI radiation; Standby Power Consumption is lower than 0.5 W; Viewing Angle: Horizontal 178°, Vertical 178°... -
Page 8: Chapter2. Device Interfaces
Monitor User Manual Chapter2. Device Interfaces Description Interfaces HDMI Digital Signal Input HDMI VGA Analog Signal Input Power Input Description Interfaces HDMI Digital Signal Input HDMI VGA Analog Signal Input Audio Input (optional) AUDIO IN Power Input... -
Page 9: Chapter3. Panel Keys
Monitor User Manual Description Interfaces HDMI Digital Signal Input HDMI VGA Analog Signal Input AUDIO Out (optional) Audio Output Power Input Figure 2.1 Rear Panel of Device Chapter3. Panel Keys Keys on lower right corner of the display unit panel are shown in the following figure. Figure 3.1 Keys on the Display Unit The functions of the keys on lower right corner of the display unit vary according to different situations. -
Page 10: Chapter4. Basic Operation
Monitor User Manual Chapter4. Basic Operation 4.1 Input Source Selection Turn on the display unit when the power supply is on and input source is confirmed. Press ◄ key of the remote controller to enter the menu as shown on the right. Monitor includes 2 input sources as HDMI and VGA signal. -
Page 11: Main Menu
Monitor User Manual Figure 4.4 Input Source 4.5 Main Menu 4.5.1 Image Settings Purpose: You can adjust the picture parameters by switching image modes and adjust the values of contrast, brightness, color temperature, auto adjust, color adjust. Steps: Press 1 key to enter the main menu interface as shown below. Press 1 key to enter the setting you want. -
Page 12: Image Adjustment
Monitor User Manual 4.5.2 Image Adjustment Purpose: When the input source is selected VGA, you can adjust the VGA parameters. It is for adjusting VGA H position, V Position, clock and phase. Steps: 1. Press Menu key to enter the main menu interface. 2. -
Page 13: Osd Setting
Monitor User Manual 4.5.3 OSD Setting Purpose: You can set the language, blending and OSD duration of the menu. Steps: 1. Press 1 key to enter the main menu interface. 2. Press ◄ key twice and press 1 key to enter the【Language】interface, press ◄ or ► to switch the language you want. -
Page 14: Other Settings
Monitor User Manual 4.5.4 Other Settings Purpose: You can set Mode, Audio Volume, Signal Source, Aspect Ratio, DCR. Steps: 1. Press 1 key to enter the main menu interface. 2. Press triple◄ key and press 1 key to enter the Mode interface, press ◄ or ► to switch the mode between PC/GAME/MOVIE. -
Page 15: Reset Setting
Monitor User Manual 4.5.5 Reset Setting Purpose: You can reset settings to the factory defaults. Steps: 1.Press 1 key to enter the main menu interface. reset settings to the factory defaults. 2.Press ◄ key 4 times and press 1 key to 1920×1080 60Hz Figure 4.5.5 Reset Setting... - Page 16 Monitor User Manual Installation of bracket base Dismantling of bracket base The appearance scheme supports two types of base (optional).
- Page 17 PN:G6AUM027000191...
