Summary of Contents for HIKVISION DS-D5019 Series
- Page 1 LCD Monitor User Manual...
- Page 2 Any and all information, including, among others, wordings, pictures, graphs are the properties of Hangzhou Hikvision Digital Technology Co., Ltd. or its subsidiaries (hereinafter referred to be “Hikvision”). This user manual (hereinafter referred to be “the Manual”) cannot be reproduced, changed, translated, or distributed, partially or wholly, by any means, without the prior written permission of Hikvision.
- Page 3 LCD Monitor User Manual Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
- Page 4 LCD Monitor User Manual Applicable Models This manual is applicable to the model: LCD Monitor. Symbol Conventions The symbols that may be found in this document are defined as follows.
-
Page 5: Table Of Contents
LCD Monitor User Manual TABLE OF CONTENTS 1.Introduction ....................1 1.1 Key Features..................... 1 1.2 Power Supply Connection................. 1 2.Device Interfaces..................2 3.Panel keys ....................2 4.Basic Operation ..................3 Specifications ....................9 Structure Figure.................... 10 IIII... -
Page 6: Introduction
Support software spread-spectrum technology to reduce EMI radiation; Standby Power Consumption is lower than 0.5W; DS-D5019 Series:Viewing Angle:Horizontal 90°, Vertical 65º ; DS-D5022QE-B:Viewing Angle:Horizontal 170°, Vertical 160º ; DS-D5022QE-E:Viewing Angle:Horizontal 90°, Vertical 65º ; DS-D5024QE:Viewing Angle:Horizontal 178°, Vertical 178º ;... -
Page 7: Device Interfaces
LCD Monitor User Manual Chapter2. Device Interfaces Interfaces Interfaces Interfaces Figure 2.1 Rear Panel of Device Interfaces Interfaces Interfaces Interfaces POWER IN（1） Power Input Power Input Power Input VGA Analog Signal Input VGA IN（3） VGA Analog Signal Input VGA Analog Signal Input HDMI Digital Signal Input HDMI IN（2）... -
Page 8: Basic Operation
LCD Monitor User Manual Chapter4. Basic Operation 4.1 Input Source Selection(optional) Turn on the display unit when the power supply is on and input source is confirmed. Press key of the remote controller to enter the menu ◄ as shown on the right. DS-D5019/22 /24/27inch LCD display unit includes 2 input sources as HDMI and VGA signal. - Page 9 LCD Monitor User Manual 4.4 Main Menu 4.4.1 Image Settings Purpose: You can adjust the picture parameters by switching image modes and adjust the values of contrast, brightness, color temperature,auto adjust,color adjust. Steps: Press MENU key to enter the main menu interface as shown below. 2.
- Page 10 LCD Monitor User Manual 4.4.2 Image Adjustment Purpose: When the input source is selected VGA, you can adjust the VGA parameters. It is for adjusting VGA H position, V Position, clock and phase. Steps: 1. Press Menu key to enter the main menu interface. 2.
- Page 11 LCD Monitor User Manual 4.4.3 OSD Setting Purpose: You can set the language, blending and OSD duration of the menu. Steps: 1. Press MENU key to enter the main menu interface. 2. Press ◄ key twice and press MENU key to enter the【Language】interface, press ◄ or ► to switch the language you want.
- Page 12 LCD Monitor User Manual 4.4.4 Other Settings Purpose: You can set Mode,Audio Volume,Signal Source,Aspect Ratio,DCR. Steps: 1. Press MENU key to enter the main menu interface. 2. Press triple◄ key and press MENU key to enter the Mode interface, press ◄ or ► to switch the mode between PC/GAME/MOVIE.
- Page 13 LCD Monitor User Manual 4.4.5 Reset Setting Purpose: You can reset settings to the factory defaults. Steps: 1.Press MENU key to enter the main menu interface. reset settings to the factory defaults. 2.Press ◄ key 4 times and press MENU key to Figure 4.4.5 Reset Setting...
-
Page 14: Specifications
LCD Monitor User Manual Appendix: Specifications Device Model DS-D5019 Series Display Type TFT-LED Backlight Screen Size 18.5" Color 16.7M Dot Pitch 0.300×0.300 mm Max Resolution 1366×768 Best Operation Resolution 1366×768@60Hz Brightness 200cd/m² Contrast 600:1 Horizontal 90°, Vertical 65º Viewing Angle Viewable Area 409.8×230.4mm Interfaces 1... -
Page 15: Structure Figure
LCD Monitor User Manual S tructure Figure 44.60 445.58 411.20 200.13 130.6 75.00 70.50 180.29... - Page 16 LCD Monitor User Manual Appendix: Specifications Device Model DS-D5022QE-B Display Type TFT-LED Backlight Screen Size 21.5" Dot Pitch 0.248×0.248 mm Max Resolution 1920×1080 Best Operation Resolution 1920×1080@60Hz Brightness 250cd/m² Contrast 1000:1 Color 16.7M Viewable Area 477×268mm Viewing Angle Horizontal 170°, Vertical 160º (optional) Interfaces 2 Interfaces 3...
- Page 17 LCD Monitor User Manual Appendix: Specifications Device Model DS-D5022QE-E Display Type TFT-LED Backlight Screen Size 21.5" Dot Pitch 0.248×0.248 mm Max Resolution 1920×1080 Best Operation Resolution 1920×1080@60Hz Brightness 200cd/m² Contrast 600:1 Color 16.7M 477×268mm Viewable Area Viewing Angle Horizontal 90°, Vertical 65º Interfaces 2 Interfaces 3 (optional)
- Page 18 LCD Monitor User Manual Structure Figure 511mm...
- Page 19 LCD Monitor User Manual Appendix: Specifications Series Device Model DS-D5024 Display Type TFT-LED Backlight Screen Size 23.8" Color 16.7M Dot Pitch 0.2745×0.2745mm Max Resolution 1920×1080 Best Operation Resolution 1920×1080@60Hz Brightness 250cd/m² Contrast 1000:1 Viewing Angle Horizontal 178°, Vertical 178º Viewable Area 527×296mm Interfaces 2 Interfaces 3...
- Page 20 LCD Monitor User Manual LCD Monitor User Manual Structure Figure...
- Page 21 LCD Monitor User Manual Appendix: Specifications Device Model DS-D5027 Series Display Type TFT-LED Backlight Screen Size 27" Color 16.7M Dot Pitch 0.311×0.311mm Max Resolution 1920×1080 Best Operation Resolution 1920×1080@60Hz Brightness 250cd/m² Contrast 1000:1 Viewing Angle Horizontal 170°, Vertical 170º Viewable Area 598×336mm (optional) Interfaces 2...
- Page 22 LCD Monitor User Manual Structure Figure 49.4 646.6 22.5 384.9 279.8 219.8...
- Page 23 PN:G6AUM027000029...
