NI PXIe-1086DC Features

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PXIe-1086DC
Features
2025-03-09

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PXIe-1086DC and is the answer not in the manual?

Questions and answers

Related Manuals for NI PXIe-1086DC

Summary of Contents for NI PXIe-1086DC

  • Page 1 PXIe-1086DC Features 2025-03-09...

  • Page 2: Table Of Contents

    Replacement Fan Modules ..........9 PXIe-1086DC Chassis Backplane Overview ........9 Interoperability with CompactPCI .
  • Page 3 PXIe-1086DC Features Setting Fan Speed ..........20 Installing Filler Panels .
  • Page 4 PXIe-1086DC Features System Controller Slot XP3 Connector Pinout ....... 45 System Controller Slot XP4 Connector Pinout .

  • Page 5: Pxie-1086Dc

    PXIe-1086DC Features PXIe-1086DC The manual includes instructions for installing and configuring your PXIe-1086DC chassis and PXI Express system. © 2019 National Instruments Corporation. All rights reserved. Refer to the <National Instruments>\_Legal Information directory for information about NI copyright, patents, trademarks, warranties, product warnings, and export compliance.

  • Page 6: High Performance For Instrumentation Requirements

    (MTTR). The chassis also features redundant power supplies and fans designed to maximize system availability. The PXIe-1086DC chassis fully complies with the PXI-5 PXI Express Hardware Specification , offering advanced timing and synchronization features.

  • Page 7: Optional Features

    • Slot blockers for improved cooling performance • Factory installation services • Replacement fan modules Chassis Description The following figures show key features of the PXIe-1086DC chassis front and back panels. Figure 19. Front View of the PXIe-1086DC PXIe-1086DC 8 10 8 14 8 1.

  • Page 8: Optional Equipment

    3. Earth Ground Terminal (PE) 4. Inhibit Mode Selector Switch 5. Fan Speed Selector Switch Optional Equipment Contact NI to order the following options for the PXIe-1086DC chassis. EMC Filler Panels EMC filler panel kits are available from NI. ni.com...

  • Page 9: Power Supply Filler Panels

    Rack Mount Kits There are two optional kits for mounting the PXIe-1086DC chassis into a rack. The first option is a pair of mounting brackets for use on the front of the chassis. The second option is a rear rack mount kit. The rear rack mount kit differs from the front kit to allow for easier installation into the rack.

  • Page 10: System Controller Slot

    Gen-2 x16 PCI Express link. These switches distribute PCI Express connections to the peripheral slots and to two PCI Express-to-PCI bridges to provide PCI buses to the hybrid peripheral slots. Refer to the PXIe-1086DC PCI Express Backplane Diagram in the Hybrid Peripheral Slots topic for more information.

  • Page 11: Hybrid Peripheral Slots

    PXIe-1086DC Features By default, the system controller will control the power supply with the PS_ON# signal. A logic low on this line will turn the power supply on. Note The Inhibit Mode switch on the rear of the chassis must be in the Default position for the system controller to have control of the power supply.

  • Page 12: System Timing Slot

    PXIe-1086DC Features Figure 3. PXIe-1086DC PCI Express Backplane Diagram PCIe Switch #1 PCIe Switch #2 Port 16 Port 17 Port 8 Port 9 Port 16 Port 17 Port 8 Port 9 PCIe-to- PCIe-to- PCI Bus (32-bit, 33 MHz) to slots 2-9...

  • Page 13: Pxi Local Bus

    PXIe-1086DC Features The system timing slot has a pin (PXIe_SYNC_CTRL) through which a system timing module can control the PXIe_SYNC100 timing. Refer to the PXI Express Specification and the PXIe SYNC CTRL section of this chapter for details. Figure 4. PXIe_DSTAR and PXI Star Connectivity Diagram...

  • Page 14: System Reference Clock

    Static trigger routing (user-specified line and directional assignments) can be configured through Measurement & Automation Explorer (MAX). Dynamic routing of triggers (automatic line assignments) is supported through certain National Instruments drivers like NI- DAQmx. Note Although any trigger line may be routed in either direction, it cannot be routed in more than one direction at a time.
  • Page 15 PXIe-1086DC Features PXI_CLK10, PXIe_CLK100 and PXIe_SYNC100 have the default timing relationship described in the following figure. Figure 6. System Reference Clock Default Behavior 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9 0 1 2 3 4 5 6 7 8 9...

  • Page 16: Pxie_Sync_Ctrl

    PXIe-1086DC Features Backplane PXI_CLK10, System Timing Slot Front Chassis Panel 10 MHz PXIe_CLK100 and PXI_CLK10_IN REF IN PXIe_SYNC100 REF IN PXI_CLK10, PXIe_CLK100 and PXIe_SYNC100 all phase-locked 10 MHz clock present No clock present to System Timing Slot— PXI_CLK10_IN PXI_CLK10, PXIe_CLK100 and...

  • Page 17: Installation And Configuration

    PXIe-1086DC Features Figure 7. PXIe_SYNC100 at 3.33 MHz Using PXIe_SYNC_CTRL as Restart PXI_CLK10 PXIe_SYNC_CTRL PXIe_SYNC100 SYNC100 Divider Restarted Here Safety Information Caution Before undertaking any troubleshooting, maintenance, or exploratory procedure, carefully read the following caution notices. Caution Protection may be impaired if equipment is not used in the manner specified.

  • Page 18: Chassis Cooling Considerations

    Providing Adequate Clearance The primary cooling exhaust vent for the PXIe-1086DC is on the top of the chassis. The primary intake vent is on the bottom of the chassis. The secondary intake vents are located along on the rear of the chassis. Adequate clearance between the chassis and surrounding equipment or blockages must be maintained to ensure proper cooling of the chassis power supply as well as the modules plugged into the chassis.
  • Page 19 PXIe-1086DC Features Figure 8. PXIe-1086DC Cooling Clearances Dimensions are in inches (millimeters) 1.75 (44.5) PXIe-1086DC 1.75 (44.5) 3.00 (76.2) The vent locations are shown in the following figure. © National Instruments...

  • Page 20: Chassis Ambient Temperature Definition

    PXIe-1086DC Features Figure 9. PXIe-1086DC Vents Ie -1 08 6 1. Ambient Temperature Sensor 2. PXI Module Air Intake (3x) 3. PXI Module Air Exhaust Vent 4. Airflow Chassis Ambient Temperature Definition The chassis fan control system uses ambient intake air temperatures for controlling fan speeds when in Auto Fan Speed mode.

  • Page 21: Installing Filler Panels

    Fan Access Door Clearance When installing the PXIe-1086DC chassis, you also must provide the proper clearance for the fan access door to open fully, as shown in the following figure. Figure 10. Fan Access Door Clearance Dimensions are in inches (millimeters) 0.35...

  • Page 22: Connecting To Safety Ground And Power Source

    The PXIe-1086DC chassis has a single power connector that supplies input power to both chassis power supplies. The power connector is on the front panel. The PXIe-1086DC ships with a power cord that has an appliance coupler and leads for connection to the source. The cord requires custom termination. The following figure shows the cord connector pinout.

  • Page 23: Power-On Test

    (NI part number 711849-01) onto the power cord as close to the input connector as possible. You can order this ferrite bead directly from NI using the Order By Part Number link on the home page at ni.com. Order the following part number: 781233-02 EMI suppression ferrite, 10.2 mm (includes NI part number 711849-01 (Fair-Rite...

  • Page 24: Installing A Pxi Express System Controller

    To completely remove power, you must disconnect all power cables. The PXIe-1086DC chassis has two slots for inserting power supplies on the rear of the chassis. A power supply must be installed in one or both of these slots to power on the chassis.
  • Page 25 The following figure shows a PXI Express system controller installed in the system controller slot of a PXIe-1086DC chassis. You can place CompactPCI, CompactPCI Express, PXI, or PXI Express modules in other slots depending on the slot type.

  • Page 26: Installing Peripheral Modules

    This section contains general installation instructions for installing a peripheral module in a PXIe-1086DC chassis. Refer to your peripheral module user manual for specific instructions and warnings. To install a module, complete the following steps: 1. Ensure that the chassis is properly grounded to protect it from electrical damage while you install the module.

  • Page 27: Remote System Monitoring

    5. PXIe-1086DC Chassis 6. Injector/Ejector Rail Remote System Monitoring The PXIe-1086DC chassis provides an Ethernet port on the front panel of the chassis. You can use this Ethernet port to monitor the chassis operating parameters remotely over a network. The Ethernet port on the chassis supports communication speeds of 10 Mbps and 100 Mbps.

  • Page 28: Default Configuration Settings

    PXIe-1086DC Features To use the remote monitoring interface, connect one end of an Ethernet cable to your PXIe-1086DC chassis. Connect the other end of the cable to your Ethernet network. Note The Ethernet controller can perform automatic crossover, thus eliminating the need for crossover cables.

  • Page 29: Led Indicators

    • DHCP with Auto IP fallback • Default hostname as printed on the product label LED Indicators The PXIe-1086DC chassis has four main LEDs on the front panel next to the Power Inhibit switch. Refer to Front View of the PXIe-1086DC in the Chassis Description topic to locate these LEDs.
  • Page 30 PXIe-1086DC Features State Description voltages are within normal operating ranges. Power supply is active, and at Blinking red least one voltage is out of range. Steady red Power supply has failed. Power supply is not installed or is in standby.

  • Page 31: Remote Inhibit And Fault Monitoring

    PXIe-1086DC Features Remote Inhibit and Fault Monitoring The PXIe-1086DC chassis supports remote inhibit and fault monitoring through a 4-pin terminal block on the chassis front panel. Refer to Front View of the PXIe-1086DC in the Chassis Description topic to locate this connector.

  • Page 32: Pxi_Clk10 Front Panel Connectors

    Inhibit Mode switch must be in the Manual position. PXI_CLK10 Front Panel Connectors There are two SMA connectors on the front of the PXIe-1086DC chassis for PXI_CLK10. The connectors are labeled IN and OUT. You can use them for supplying the backplane with PXI_CLK10 or routing the backplane’s PXI_CLK10 to another chassis.

  • Page 33: Trigger Configuration In Max

    If static reservations are required, static reservation of trigger lines can be implemented by the user in MAX through the Triggers tab. PXI modules dynamically configured by programs such as NI-DAQmx will not use reserved trigger lines. This prevents the instruments from double-driving the trigger lines, possibly damaging devices in the chassis.

  • Page 34: Pxi Trigger Bus Routing

    Routing tab in MAX. Note Selecting any non-disabled routing automatically reserves the line in all trigger buses being routed to. If you are using NI-DAQmx, it will reserve and route trigger lines for you, so you won’t have to route trigger lines manually.

  • Page 35: Maintenance

    System controllers from NI provide the pxisys.ini file for the PXIe-1086DC chassis, so you should not need to use the chassis.ini file. Refer to the documentation provided with the system controller or to ni.com/support...

  • Page 36: Preparation

    PXIe-1086DC Features Preparation The information in this section is designed for use by qualified service personnel. Read the PXIe-1086DC Safety, Environmental, and Regulatory Information document included with your kit before attempting any procedures in this section. Caution Many components within the chassis are susceptible to static discharge damage.

  • Page 37: Replacing A Modular Power Supply

    PXIe-1086DC Features especially through the top vents. Use just enough moisture to dampen the cloth. Do not wash the front- or rear-panel connectors or switches. Cover these components while cleaning the chassis. Do not use harsh chemical cleaning agents; they may damage the chassis.

  • Page 38: Removal Of Power Drawer

    PXIe-1086DC Features The PXIe-1086DC power supply (part number 782106-01) is a replacement part for the PXIe-1086DC chassis. Before attempting to replace a power supply, verify that there is adequate clearance behind the chassis. The power supplies for this chassis are redundant and hot swappable. If both power supplies are installed and functional, you can remove either without disconnecting main AC power from the system.
  • Page 39 3. Side Latch 4. Power Supply Caution If you are using the PXIe-1086DC and SC Express modules with front mounting terminal blocks together, you must remove the SC Express module front mount terminal blocks to access the power drawer. Refer to your module documentation for more information about removing the terminal blocks.

  • Page 40: Installation Of Power Supply

    6. Place the drawer on a table surface to remove the power supply. 7. Disengage the two screws on the rear of the power supply with a flat-blade screwdriver. Refer to the Rear View of the PXIe-1086DC figure in the Chassis Description topic for the location of the screws.

  • Page 41: Replacing A Modular Fan Assembly

    PXIe-1086DC Features Caution If you are using the PXIe-1086DC and SC Express modules with front mounting terminal blocks together, you must remove the SC Express module front mount terminal blocks to access the power drawer. Refer to your module documentation for more information about removing the terminal blocks.

  • Page 42: Removal

    Caution If all fans are installed and operating normally, you can remove any fan without causing the system to shut down. The following figure shows the PXIe-1086DC chassis with a fan assembly removed. ni.com...

  • Page 43: Installation

    PXIe-1086DC Features Figure 20. PXIe-1086DC Chassis with Fan Assembly Removed I e - 1 0 8 1. Modular Fan Assembly 2. Fan Latch 3. Fan Door Complete the following steps to remove a fan assembly: 1. Open the fan door by sliding the door latches inward and rotating the door down.

  • Page 44: Pinouts

    PXIe-1086DC Features Complete the following steps to install a fan assembly: 1. Open the fan door by sliding the door latches inward and rotating the door down. 2. Slide the fan module into an empty fan slot with the connector facing the chassis until it latches.

  • Page 45: System Controller Slot Xp3 Connector Pinout

    PXIe-1086DC Features System Controller Slot XP3 Connector Pinout PWR_OK PS_ON# GND LINKCAP PWRBTN# GND SMBDAT SMBCLK GND RSVD RSVD RSVD RSVD PERST# GND 2RefClk+ 2RefClk- GND 1RefClk+ 1RefClk- GND 1PETp0 1PETn0 1PERp0 1PERn0 GND 1PETp1 1PETn1 1PETp2 1PETn2 1PERp2 1PERn2 GND...

  • Page 46: System Timing Slot Tp2 Connector Pinout

    PXIe-1086DC Features Pin A *B5+ *B5- GND *B16+ *B16- *B13+ *B13- *A5+ *A5- GND *A7+ *A7- *C14+ *C14- *C6+ *C6- GND PXI_STAR16 RSV *A14+ *A14- *B6+ *B6- GND *C15+ *C15- *B14+ *B14- 10 *A6+ *A6- GND *B15+ *B15- *A15+ *A15-...

  • Page 47: System Timing Slot Xp4 Connector Pinout

    PXIe-1086DC Features Pin A **PXIe_DSTAR System Timing Slot XP4 Connector Pinout 5Vaux SYSEN# WAKE# ALERT# 3.3V 3.3V 3.3V PXI_TRIG3 PXI_TRIG4 PXI_TRIG5 GND PXI_TRIG6 GND PXI_TRIG2 ATNLED PXI_CLK10_IN PXI_CLK10 GND PXI_TRIG1 PXI_TRIG0 ATNSW# PXI_TRIG7 GND PXIe_SYNC_CTRL GND PXI_LBL6 PXI_LBR6 Hybrid Slot P1 Connector Pinout...

  • Page 48: Where To Go For Support

    The National Instruments Web site is your complete resource for technical support. At ni.com/support you have access to everything from troubleshooting and application development self-help resources to email and phone assistance from NI Application Engineers. A Declaration of Conformity (DoC) is our claim of compliance with the Council of the European Communities using the manufacturer’s declaration of conformity.
  • Page 49 PXIe-1086DC Features telephone support in the United States, create your service request at ni.com/support and follow the calling instructions or dial 512 795 8248. For telephone support outside the United States, visit the Worldwide Offices section of ni.com/niglobal to access the branch office Web sites, which provide up-to-date contact information, support phone numbers, email addresses, and current events.
