Homelegance SH8897GRY-LCR Assembly Instruction

Caution: Please read instructions thoroughly before unpacking assembly parts. Sharp, exposed staple tips can
cause injury, therefore, for your protection, please remove any exposed staples used in packing.
1. We recommend that you should assemble this product with the assistance of another person; this will make
assembly easier, and will help to eliminate damage to the product or injury to persons during assembly.
2. Be sure to check all packing materials carefully for small parts that may have come loose inside the carton
during shipment.
3. Please do not over tighten screws or bolts.
4. Please put all parts on a non-abrasive floor before assembly, and follow the assembly steps to assemble your
newly purchased product correctly and efficiently.
HARDWARE LIST
Part
No.
Description
Ø5/16" x 75MM
1 Bolt
2 Ø5/16" x 13MM
Lock Washer
Flat Washer Ø5/16" x 19MM
3
Allen Key M5x100mm
4
5 Legs 80x80x80mm
Legs
6 110x80x80mm
PART LIST
Part
No.
Description
A SEAT BASE
B ARM
C BACK FRAME
D SEAT CUSHION
E BACK CUSHION
F ARM CUSHION
ASSEMBLY INSTRUCTION
SH8897GRY/DGR/CRM-LCR
LEFT SIDE FACE CHAIR
Size Sketch
Sketch
1 pc
1 pc
1 pc
1 pc
1 pcs
1 pcs
PAGE: 1 OF 4
Q'ty
4 pcs
4 pcs
4 pcs
1 pc
3 pcs
1 pcs
Q'ty
MADE IN VIETNAM
