ASSEMBLY INSTRUCTIONS
ITEM NO :.SH8895BLK-3/SH8895GRW-3 / SH8895RED-3
DROP-DOWN CUP HOLDER, POWER HEADRESTS &
NOTE: Do not use power tools for assembly. Power tool increase the risk
of over tightening which lead to splitting or cracking the wood.
PARTS LIST
NO.
A
B
C
D
E
F
HARDWARE LIST
NO.
1
POWER DOUBLE RECLINER SOFA W/
LED LIGHT/SPEAKERS
DRAWING
DRAWING
DESCRIPTION
SEAT WITH WIRE
LSF BACK REST
MIDDLE BACK REST
RSF BACK REST
LSF EAR
RSF EAR
DESCRIPTION
PLUG ADAPTER WITH WIRE
1 / 5
QTY
1PC
1PC
1PC
1PC
1PC
1PC
QTY
1PC
