ASSEMBLY INSTRUCTIONS

POWER DOUBLE RECLINER SOFA W/

DROP-DOWN CUP HOLDER, POWER

HEADRESTS & LED LIGHT/SPEAKERS

NOTE: Do not use power tools for assembly. Power tool increase the risk

of over tightening which lead to splitting or cracking the wood.

PARTS LIST

NO.

NO.

ITEM NO :. SH8895BLK-3

DRAWING

DESCRIPTION

SEAT WITH WIRE

LSF BACK REST

MIDDLE BACK REST

RSF BACK REST

LSF EAR

RSF EAR

DESCRIPTION

ADAPTER

1 / 5

QTY

1PC

QTY

1PC

Table of Contents

Do you have a question about the SH8895BLK-3 and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTIONS ITEM NO :. SH8895BLK-3 POWER DOUBLE RECLINER SOFA W/ DROP-DOWN CUP HOLDER, POWER HEADRESTS & LED LIGHT/SPEAKERS NOTE: Do not use power tools for assembly. Power tool increase the risk of over tightening which lead to splitting or cracking the wood.
Page 2 Please follow the below drawings to assemble the item. STEP 1 Align the female brackets at the back onto the male brackets at the seat, insert back rest to the seat then push to the end and make sure it is fixed in position securely.
Page 3 Please follow the below drawings to assemble the item. STEP 3 Connect the power cord and plug it into the outlet socket. Recliner / Headrest Receptacle outlet STEP 4 USB Port 5V/1A Headrest Press Press Press Close Open/Close Open USB Port 5V/1A Chair Press...
Page 4 Please follow the below drawings to assemble the item. STEP 5 Headrest Chair Control Switch STEP 6 Receptacle with USB port LED Light W=90mm 4 / 5...
Page 5 Completed. CARE INSTRUCTION FOR POLYESTER In order to maintain the original appearance of your polyester funiture, please follow below simple care procedure: ● Avoid exposing funiture directly to sunlight or heating and air conditioning outlets. Exposure to sunlight or heating and air conditioning outlets will fade/damage polyester. ●...
