Homelegance 1645-1 Assembly Instruction

Thank you for purchasing this product. Please take time to read and follow the instructions below. Check that you have all parts and
hardware before assembly. Parts apparently missing are often found in the packing materials. If you do not have all the parts listed,
have your dealer contact us and they will be sent to you immediately.
It is recommended to install protective pads under all legs and supports to avoid damage or
scratches when placing furniture on a wood floor or other hard surface, and to limit
indentation and prevent discoloration if placing on carpet.
PART LIST/ LISTE DE PIECE
NO COMPONENT
HEADBOARD PANEL / TETE DE
A
LIT
FOOTBOARD / PIED DE LIT
B
LEG LSF / PIED
C
LEG RSF / PIED
D
E
BED SLAT / LATTE
BED SLAT SUPPORT / LATTE
F
SOUTIEN
G
SIDE RAIL / LONGERONS

STEP 1

MADE IN MALAYSIA
NOTE : MUST TIGHTEN SCREWS PERIODICALLY
ASSEMBLY INSTRUCTION /
INSTRUCTION D' ASSEMBLANGE
QTY
SKETCH NO
1 PC 1
2
1 PC
3
1 PC
Nail Leg
4
1 PC
Nail Leg
4
5
PCS
4
6
PCS
2
PCS
:
WITH USE SCREW WILL BECOME LOOSE CHECK TIGHTNESS OF ALL SCREW EVERY 6-8 WEEKS.
DO NOT TIGHTEN BOLTS UNTIL COMPLETELY ASSEMBLED.
NE PAS SERRER LES BOULON JUSQU'A CE QUE LE MONTAGE SOIT COMPLETMENT TERMINE
DESCRIPTION SKETCH
JCBC BOLT/
BOULON
SPRING WASHER/ RONDELLE D'
ARR T
FLAT WASHER/ RONDELLE PLATE
C SK SCREW / VIS M4 x 32MM
ALLEN KEY / CLE ALLEN
ALLEN KEY / CLE ALLEN
2
3
A
RIGHT/DROITE
D
QTY
SIZE
6
M6 x 30MM
PCS
6
1/4" x
2mm(Thickness)
PCS
6
1/4" ID x 13mm x
1mm(Thickness)
PCS
8
M4 x 32MM
PCS
1 PC
M4 x 65MM
1 PC
M5 x 65MM
5
1
x6
C
LEG GLIDE
LEFT/GAUCHE
PAGE 1 OF 2 /
PAGE 1 DE 2
