PART LIST:
A: LSF HB LEG FOR
ALL SIZE BED
1PC
E: SLAT CONNECTOR
FOR ALL SIZE BED
28PCS
I: CENTER SLAT
SUPPORT LEG
3PCS
M: BRACKET
1PC
HARDWARE SET:
1: Bolt 1/4*10mm
2: Bolt 1/4*17.5mm
X 8pcs
6: Nut 1/4
X 6psc
ASSEMBLY INSTRUCTION
1602BKF/BK-1: METAL FULL/QUEEN BED
B: RSF HB LEG FOR
ALL SIZE BED
1PC
F:SIDE RAIL
2PCS
J:CENTER RAIL
SUPPORT LEG
2PCS
N: SLAT
14PCS
3: Bolt 1/4*22mm
X 8pcs
8: Ratchet Tool
7: Washer 1/4
X 4psc
WITH BLACK PVC HEADBOARD
C: HEADBOARD
1PC
G:SIDE RAIL
2PCS
K: SIDE CROSS BAR
2PCS
4: Bolt 5/16*19mm
X 12pcs
X 8pcs
X 1pc
D: FOOTBOARD
1PC
H: CENTER CROSS BAR
1PC
L: CENTER RAIL
SUPPORT BAR
2PCS
5: Bolt 1/4*40mm
X 6pcs
9: Wrench
X 1PC
Page:1/4
Advertisement
Related Manuals for Homelegance 1602BKF/BK-1
Summary of Contents for Homelegance 1602BKF/BK-1
- Page 1 ASSEMBLY INSTRUCTION 1602BKF/BK-1: METAL FULL/QUEEN BED WITH BLACK PVC HEADBOARD PART LIST: A: LSF HB LEG FOR B: RSF HB LEG FOR C: HEADBOARD D: FOOTBOARD ALL SIZE BED ALL SIZE BED E: SLAT CONNECTOR F:SIDE RAIL H: CENTER CROSS BAR...
- Page 2 How to Use the Ratchet Tool (8) 1. Before assembling the furniture, please adjust the lock as needed. Lock on the right Lock on the left to tighten bolts! to loosen bolts! 2. Tighten or loosen bolts. Tighten bolts: Locate the turncap and rotate it clockwise to screw the bolt quickly until it cannot be rotated any more.
- Page 3 N ote: Please do not tighten all bolts until the bed is assembled completely. STEP 1 STEP 2 Hardware 1: 8 pcs Hardware 2: 4 pcs STEP 3 STEP 4 Hardware 5: 4 pcs Hardware 3: 8 pcs Hardware 6: 4 pcs Hardware 7: 4 pcs STEP 5 STEP 6...
- Page 4 N ote: Please do not tighten all bolts until the bed is assembled completely. STEP 7 Hardware 3: 4 pcs Hardware 5: 2 pcs Hardware 6: 2 pcs STEP 8 COMPLETED Page:4/4...
