1 x Front Panel
1 x Back Panel
1 x Side Panel—Right
1 x Side Panel—Left
1 x Floor Panel
2 x Front / Side Corners Covers
1 x 18mm OSB3 Roof Board
1 x Roofing Felt
8 x 100mm Front Panel Cladding Boards
42 x 50mm Green Coated Screws
22 x 75mm Green Coated Screws
20mm Clout Nails
All images are for illustration only. Please see individual item listings for actual item specifications.
(A)
(B)
(C-R)
(C-L)
(D)
(E)
(F)
(G)
(H)
(FIX 1)
(FIX 2)
(FIX 3)
Tools Required
Drill Driver
PZ2 Driver Bit
Pilot drill bit
Hammer
Pencil
Spirit Level
Page 1 of 8
Advertisement
Related Manuals for eDecks Barkmgham Palace Kennel
Summary of Contents for eDecks Barkmgham Palace Kennel
- Page 1 Tools Required 1 x Front Panel 1 x Back Panel Drill Driver 1 x Side Panel—Right (C-R) PZ2 Driver Bit 1 x Side Panel—Left (C-L) Pilot drill bit 1 x Floor Panel Hammer 2 x Front / Side Corners Covers Pencil 1 x 18mm OSB3 Roof Board Spirit Level...
- Page 2 *To prevent splits, drill a pilot hole before driving screws* To begin, start by placing the Floor Panel (D) face up as below and attach the both side panels (C-R) & (C-L) as shown below using 3 x 75mm Green Coated Screws (FIX 2) per side, driving directly through the frame and into the floor.
- Page 3 *To prevent splits, drill a pilot hole before driving screws* With both side panels and the back fastened together, we now complete the frame by fixing the Front Panel (A) into posi- tion, using 3 x 75mm Green Coated Screws (FIX 2) at each side, driving directly into the 2 x 2 timber frame and into the adjacent panel.
- Page 4 *To prevent splits, drill a pilot hole before driving screws* Place the roof board (F) on top of the kennel with an even amount of overhang on all sides, secure in place using 12 x 50mm Green Coated Screws (FIX 1) driving through the top and down into the frame. Page 4 of 8 All images are for illustration only.
- Page 5 *To prevent splits, drill a pilot hole before driving screws* In order to avoid damage in transportation we have pur- posely left the front panel cladding boards (H) unattached. These will arrive to you predrilled and just need to be attached to the front edge using 2 x 50mm Green Coated Screws (FIX 1) per piece.
- Page 6 *To prevent splits, drill a pilot hole before driving screws* To finish the roof part of your kennel, the felt (G) needs to be fastened down the roof board using the 20mm Clout Nails (FIX 3). Note: Because of the size of the roof, the felt needs to be installed in two sections.
- Page 7 *To prevent splits, drill a pilot hole before driving screws* To give a clean and neat finish to the front of your kennel, install the corner trims (E) over the gap where the front and side panels meet, and secure at the top, middle and bottom with 6 x 50mm Green Coated Screws (FIX 1). Repeat this for both sides / front corners.
