Summary of Contents for AEG CIB6490APB
- Page 1 EN User Manual | Cooker CIB6490APB aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................8 4. PRODUCT DESCRIPTION................10 5. BEFORE FIRST USE..................11 6. -
Page 3: General Safety
be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. - Page 4 • WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. • Never use water to extinguish the cooking fire. Switch off the appliance and cover flames with e.g. a fire blanket or lid. •...
-
Page 5: Safety Instructions
• If the mains power supply cable is damaged, it must be replaced by the manufacturer, its Authorised Service Centre or similarly qualified persons to avoid an electrical hazard. • Be careful when you touch the storage drawer. It can get hot. - Page 6 the appliance, especially when it operates cools down. If errors appear when the or the door is hot. appliance is cool, disconnect it from the • The shock protection of live and insulated power supply for 10 seconds. parts must be fastened in such a way that •...
-
Page 7: Care And Cleaning
2.5 Pyrolytic cleaning • Use a deep pan for moist cakes. Fruit juices cause stains that can be permanent. • Do not keep hot cookware on the control Risk of Injury / Fires / Chemical panel. Emissions (Fumes) in Pyrolitic Mode. •... -
Page 8: Internal Lighting
harmful to humans, including children or • Use only lamps with the same persons with medical conditions. specifications. 2.6 Internal lighting 2.7 Service • To repair the appliance contact the WARNING! Authorised Service Centre. • Use original spare parts only. Risk of electric shock. -
Page 9: Levelling Of The Appliance
3.3 Levelling of the appliance CAUTION! Make sure you install the anti-tilt protection at the correct height. Make sure that the surface behind the appliance is smooth. 1. Set the correct height and area for the appliance before you attach the anti-tilt protection. -
Page 10: Product Description
temperature of 90 °C or higher. Contact an Authorised Service Centre. The connection cable may only be replaced by a qualified electrician. Applicable types of cables for different phases: Phase Min. size cable 3x6.0 mm² 3 with neutral 5x1.5 mm² WARNING! The power cable must not touch the part of the appliance shaded in the illustration. -
Page 11: Before First Use
To open the drawer, push the drawer. The drawer comes out. 5. BEFORE FIRST USE 3. Set the function . Set the maximum WARNING! temperature. Let the appliance operate Refer to Safety chapters. for 15 min. 4. Turn off the appliance and wait until it is 5.1 Initial preheating and cleaning cold. -
Page 12: Heat Setting Displays
Sensor Function Comment field ON / OFF To activate and deactivate the hob. Lock / Child safety device To lock / unlock the control panel. Pause To activate and deactivate the function. Bridge To activate and deactivate the function. Heat setting display To show the heat setting. -
Page 13: Activating And Deactivating
6.3 OptiHeat control (3 step • the hob gets too hot (e.g. when a Residual heat indicator) saucepan boils dry). Let the cooking zone cool down before you use the hob again. • you use incorrect cookware. The symbol WARNING! comes on and the cooking zone As long as the indicator is deactivates automatically after 2 minutes. -
Page 14: Automatic Heat Up
touch a desired heat setting. After 3 seconds comes on. For optimal heat transfer use cookware To deactivate the function: change the heat with bottom diameter similar to the size of setting. the cooking zone (i.e. the maximum cookware diameter value in "Technical 6.10 PowerBoost data"... -
Page 15: Child Safety Device
When the function operates, all other symbols on the control panels are locked. When the time comes to an end, the The function does not stop the timer sound operates and 00 flashes. The functions. cooking zone deactivates. 1. To activate the function: press To stop the sound: touch comes on. - Page 16 6.15 OffSound control (Deactivating and activating the sounds) Automat‐ Boiling 1) Frying 2) ic light Deactivate the hob. Touch for 3 seconds. Fan speed Fan speed The display comes on and goes out. Touch Mode H2 for 3 seconds. comes on. Touch Mode H3 Fan speed of the timer to choose one of the following:...
-
Page 17: Power Management Function
• Each phase has a maximum electricity speed manually. When you press load. raise the fan speed by one. When you reach • The function divides the power between an intensive level and press again you will cooking zones connected to the same set fan speed to 0 which deactivates the hood phase. -
Page 18: Noises During Operation
receives only a part of the power generated is made of different materials (a sandwich by the cooking zone. construction). • humming: you use a high power level. 7.2 Minimum cookware diameter Hob-related noises: • clicking: electric switching occurs. • hissing, buzzing: the fan operates. Cooking Cookware diam‐... -
Page 19: Hob - Care And Cleaning
Heat setting Use to: Time Hints (min) 7 - 9 Cook larger quantities of food, stews 60 - 150 Up to 3 l of liquid plus ingredients. and soups. 9 - 12 Gentle fry: escalope, veal cordon bleu, as neces‐ Turn over when needed. -
Page 20: Control Panel
9.1 Control panel Control panel sensor fields Timer Fast heat up Light Lock Confirm setting Select a heating function to turn on the oven. Turn the knob for the heating functions to the off position to turn the oven off. The display with the maximum number of functions set. -
Page 21: Oven Functions
Position Default Setting Setting Options Demo Mode Demo Mode- only for the demon‐ stration Software Version Software version display Reset All Settings NO-YES 9.3 Oven functions Symbol Oven function Symbol Oven function Moist fan baking This function was used to comply Off position with the energy efficiency class and The oven is off. -
Page 22: Cooling Fan
9.4 Activating and deactivating the 9.7 Lock oven The door locks when this function is activated. It depends on the model if your appliance has knob symbols, indicators or lamps: This function prevents an accidental • The indicator comes on when the change of the oven function. -
Page 23: Telescopic Runners - Inserting The Oven Accessories
Push the deep pan between the guide bars of With telescopic runners you can put in and the shelf support. remove the shelves more easily. Put the wire shelf on the telescopic runners so that the feet point downwards. Deep pan: Put the baking tray or deep pan on the •... -
Page 24: Oven - Clock Functions
10. OVEN - CLOCK FUNCTIONS 10.1 Clock functions 4. Press 5. The timer starts counting down immediately. 00:00 pulses on the display when you 6. When the time ends, press and turn connect the appliance to the electrical the knob for the heating functions to the supply. -
Page 25: How To Set: Assisted Cooking
11. HOW TO SET: ASSISTED COOKING Assisted Cooking - use it to prepare a dish 3. Select the dish and press quickly with default settings: 4. Insert the dish to the oven and press 1. Turn the knob for the heating functions to to confirm the setting. - Page 26 Dish Weight Shelf level / Accessory Duration time Fillet, rare, LTC 80 min Fillet, medium, 0,5 - 1,5 kg; 5 - 2; baking tray 95 min 6 cm thick Fry the meat for a few minutes on a hot pan. In‐ pieces sert to the oven.
- Page 27 Dish Weight Shelf level / Accessory Duration time Chicken legs, 45 min 3; baking tray fresh If you marinated chicken legs first, set lower temperature and cook them longer. Duck, whole 1,5 - 2,5 kg 80min 2; roasting dish on wire shelf with deep pan on level 1 to collect the fat.
-
Page 28: Oven - Hints And Tips
Dish Weight Shelf level / Accessory Duration time Wegdes 1 kg 50 min 3; baking tray lined with baking paper Cut potatoes into pieces. Grilled mixed 1 - 1,5 kg 30 min 3; baking tray lined with baking paper vegetables Cut the vegetables into pieces. - Page 29 stand back from the appliance when you Do not put the objects directly on the open the appliance door while cooking. To appliance floor and do not put aluminium foil decrease the condensation, operate the on the components when you cook. This can appliance for 10 minutes before cooking.
-
Page 30: Information For Test Institutes
Food Temperature (°C) Time (min) Shelf position Savoury cracker 25 - 30 Short crust pastry biscuits 25 - 35 Tartelettes 20 - 30 Vegetarian Food Temperature (°C) Time (min) Shelf position Mixed vegetables in pouch 400 g 20 - 30 Omelette 25 - 35 Vegetables on tray 700 g... -
Page 31: Oven - Care And Cleaning
Food Function Tempera‐ Time (min) Accesso‐ Shelf po‐ ture (°C) ries sition Beef burger Grilling 15 - 20 first side. Grid/Drip‐ 10 - 15 second ping pan side. 14. OVEN - CARE AND CLEANING WARNING! WARNING! Refer to Safety chapters. There is a risk of burns. -
Page 32: Removing The Shelf Supports
- flashes in the display for 5 sec after each activation and deactivation of the oven. To turn off the reminder enter the Menu and select Settings, Cleaning Reminder. 14.4 Removing the shelf supports To clean the oven, remove the shelf supports. 1. -
Page 33: Replacing The Lamp
1. Turn the lamp glass cover counterclockwise to remove it. 2. Clean the glass cover. 3. Replace the oven lamp with a suitable 300 °C heat-resistant oven lamp. Use the same oven lamp type. 4. Install the glass cover. 14.8 The drawer 4. - Page 34 Problem Possible cause Remedy You cannot activate the appliance. The fuse is blown. Make sure that the fuse is the cause of the malfunction. If the fuse is blown again and again, contact a qualified electrician. You cannot activate or operate the You touched 2 or more sensor fields Touch only one sensor field.
-
Page 35: Service Data
Do not remove the rating plate from the appliance cavity. 16. ENERGY EFFICIENCY 16.1 Product Information according to EU Ecodesign Regulations for Hob Model identification CIB6490APB Type of hob Hob inside Freestanding Cooker Number of cooking zones ENGLISH... -
Page 36: Hob - Energy Saving
16.3 Product Information Sheet and Product Information according to EU Energy Labelling and Ecodesign Regulations for Oven Supplier's name Model identification CIB6490APB 940002993 Energy Efficiency Index 81.4 Energy efficiency class Energy consumption with a standard load, conventional mode 0.98 kWh/cycle... -
Page 37: Environmental Concerns
Keep the door gasket clean and make sure it Use the residual heat to keep the food warm is well fixed in its position. or warm up other dishes. Use metal cookware and dark, non-reflective When you turn off the appliance, the display tins and containers to improve energy saving. - Page 40 867363797-E-282024...
