KI6106 / T6106 series 10G/XG PON Power Meter
Warranty:
Information in this manual is given in good faith for the benefit of the user. It
cannot be used as the basis for claims against Kingfisher International or its
representatives, if accidental damage or inconvenience results from use or
attempted repair of the equipment.
This Kingfisher International product is guaranteed against defective
components and workmanship for a period of 1 year from the date of delivery,
unless specifically stated in the original purchase contract or agreement.
This warranty excludes optical connectors or incorrect use.
The warranty will be voided if the following instance happens:-
1) Opening the instrument.
2) The instrument has been immersed in water or subjected to
extreme environmental conditions.
Liability is limited solely to repair of the equipment.
Revision 4
User Manual
Date: 21 Dec 2023
Page 1 of 12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tempo Communications KINGFISHER KI6106 Series
Summary of Contents for Tempo Communications KINGFISHER KI6106 Series
- Page 1 User Manual KI6106 / T6106 series 10G/XG PON Power Meter Warranty: Information in this manual is given in good faith for the benefit of the user. It cannot be used as the basis for claims against Kingfisher International or its representatives, if accidental damage or inconvenience results from use or attempted repair of the equipment.
-
Page 2: Table Of Contents
CONTENTS 1. The instrument ..................3 2. Technical specifications ............... 4 3. Operation instructions ................5 3.1 ON / OFF instrument ................. 5 3.2 Auto Power Off mode ............... 5 3.3 Setting Time..................5 3.4 Selecting measurement unit ............6 3.5 Relative Measurement Mode ............ -
Page 3: The Instrument
1. The instrument Optical connector ports: Captive ONT (left): for upstream 1270 & 1310 nm tests dust cap OLT (right): for downstream 1490 & 1577 nm tests Product label Keypads Battery door Rubber holster Rubber flap USB connector Charging jack Revision 4 Date: 21 Dec 2023 Page 3 of 12... -
Page 4: Technical Specifications
2. Technical specifications Standard wavelengths 1270 1310 1490 1577 (nm) (upstream) (upstream) (downstream) (downstream) 1260 ～ 1280 1290 ～ 1330 1470 ～ 1505 Pass zone(nm) 1570 ~1585 -30 ～ 10 -30 ～ 10 -45 ～ 10 -45 ～ 10 Range(dBm) >... -
Page 5: Operation Instructions
3. Operation instructions 3.1 ON / OFF instrument To switch on instrument, press and hold [ON]. The home display below will be seen. The instrument is now ready for measurements. Power levels of the respective wavelengths in live fibers will be displayed automatically when appropriately connected at OLN &... -
Page 6: Selecting Measurement Unit
Use [◄, ►] to select the digit to be edited; the selected digit will be highlighted. Use [▲, ▼] to edit the value of selected digit. Press [OK] to save changes or press [OFF] to exit Time Setting mode without saving. Date and time format: Date: YY/MM/DD Time: HH:MM... -
Page 7: Alert/Pass/Fail Threshold Setup
3.6 Alert/Pass/Fail threshold setup Threshold group number The alert/pass/fail threshold values for 1270, 1310, 1490, 1577 nm can be individually preset. These preset values can be stored in 3 groups (01, 02, 03). To enter Threshold Setup mode (see picture on the right), press and hold [▲] at home display. -
Page 8: Measurement With Pass/Fail Display Mode
press [OK] to save settings. Note that if invalid threshold values have been entered, the unit will automatically exit Threshold Setup mode and return to home display without saving those values. ➎ Use [►] to select the next wavelength and, repeat steps ➌ ~ ➍ above to set and save the respective threshold values. -
Page 9: Data Management
3.8 Data management Measurement data can be saved in instrument’s internal memory. A max of 99 records of 4 wavelengths with time stamp can be saved. Data saved in internal memory can be retrieved for viewing on instrument. To save measurement data: Press [F1], the symbol indicates that instrument is in Data Save mode. -
Page 10: Battery / Power
3.9 Battery / Power The instrument can be powered by either the supplied rechargeable Lithium battery or, by the supplied charger alone. When operating the instrument with Lithium battery installed, as battery voltage drops below 6.7volt, a symbol will be displayed, and instrument will beep for a short instant before powering off automatically. -
Page 11: Safety
5. Safety Take appropriate eye-safe precautions when handling live fibre. Avoid condensation The instrument is resistant to normal dust and moisture; however, it is not waterproof. If moisture gets into the instrument, remove the batteries and dry it out carefully for at least one hour before using it again. Storage During prolonged storage, remove batteries to eliminate the possibility of acid leakage. -
Page 12: Optional Accessories
7. Optional Accessories Description AC Power Adapter Plug, US-to-UK OPT093 AC Power Adapter Plug, US-to-AUS OPT094 AC Power Adapter Plug, US-to-EUR OPT095 Revision 4 Date: 21 Dec 2023 Page 12 of 12...
