- Page 1 OFL100 OTDR www.lambdaphoto.co.uk T: +44 (0)1582 764334 Read and understand all of the instructions and safety information in this manual before operating or servicing this tool. Register this product at www.TempoCom.com 55501342 REV 0 © 2022 Tempo Communications Inc. 03/2022...
-
Page 2: Table Of Contents
VFL ..................................14 Laser Source ............................... 15 Optical Loss Test .............................. 15 RJ45 Sequence Testing ..........................15 System Settings ............................... 16 Section 4. OFL100 Troubleshooting Section 5. Trace Viewer Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 3: Preface
Tempo Communications OFL100 handheld OTDR. This instruction manual is free to download from www.tempocom.com Warranty Tempo Communications Inc. warrants to the original purchaser of these goods for use that these products will and conditions contained in Tempo Communication’s standard one-year limited warranty. upon request. -
Page 4: Important Safety Information
• gases or fumes. • Before applying power, verify that the unit is set to match the available line voltage. Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... - Page 5 CLASS 2 LASER PRODUCT IEC 60825-1:2014 MAX OUTPUT < 1mW WAVELENGTH 650±20nm PULSE DURATION CW • because they may be connected to active laser transmitters. • • Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155...
- Page 6 The OFL100 uses a polymer lithium battery and is to be charged with the supplied charger at 5V/2A at a temperature range of 0° to 50°. The OFL100 will not charge. Do not use any other charger to charge the OFL100. Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155...
-
Page 7: Section 1. Introduction
The OFL100 is easy to use, small, and compact with large touchscreen LCD display with graphical interfaces. Basic applications: • Measure fusion splice losses. Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 8: Section 2. Basic Otdr Information
4 Charging indicator 5 LAN 1 5 Power on status indicator 6 LAN 2 7 SD Card Bottom 8 Type C USB 1 RJ45 Sequence Test Remote Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 9: Function Keys
Main Interface function or directly select on the screen. Flashlight Date & Time Battery SD Card Shortcut menu desired function. screen shot. The screen shot is automatically Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 10: Auto Otdr
Perform an updated real time test at a rate of interface. events. Averaging Test Perform a test with user determined settings with a static display upon completing the measurement. Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 11: Parameter Settings
Unit: or miles. IOR: The Index of Refraction is provided by optical IOR for the most accurate measurements. Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 12: Threshold/Criterion
Loss: the loss of the current event. : The order of the current event. the return loss of the current event. Type: The type of the current event. Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 13: Otdr File Saving
Operator: Enter the name of the technician. code set when the line is installed: File Operation File Operation All the test curves are saved in the standard SD Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 14: Event Map
Open: Turns the visual fault locator on in continuous wave mode. 1Hz: 2Hz: Close: WARNING Avoid looking directly at the laser output port; permanent eye damage may occur Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 15: Laser Source
The indicators of the host and 4,5,2,7,8. Both T568A and T568B cables can be tested. Do not connect live cables to the OFL100. Doing so may result in permanent damage. Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 16: System Settings
USB connection: Allows the technician to connect and Allows the technician to set the time and date. Restore factory settings: Allows the technician to Provides the technician the utility to update Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... -
Page 17: Section 4. Ofl100 Troubleshooting
- Fiber information - File name/date All events are listed with test results documented in tabular form. The Tempo Communications Trace Viewer is available for download at www.tempocom.com. Tempo Communications Inc. 1390 Aspen Way • Vista, CA 92081 USA • 800-642-2155... - Page 18 Distribution in the UK & Ireland Lambda Photometrics Limited Lambda House Batford Mill Harpenden Herts AL5 5BZ United Kingdom info@lambdaphoto.co.uk W: www.lambdaphoto.co.uk +44 (0)1582 764334 +44 (0)1582 712084...
