INSTRUCTION MANUAL
OPM510 • OPM520
Fiber Optic Power Meter
SLS520 • SLS530 • SLS535 • SLS536
Laser Source
SLS525
LED Source
Read and understand all of the instructions and
safety information in this manual before operat-
ing or servicing this tool.
Register this product at www.TempoCom.com
52040482 REV11
© 2020 Tempo Communications Inc.
05/20
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Tempo Communications OPM510
Summary of Contents for Tempo Communications OPM510
- Page 1 SLS520 • SLS530 • SLS535 • SLS536 Laser Source SLS525 LED Source Read and understand all of the instructions and safety information in this manual before operat- ing or servicing this tool. Register this product at www.TempoCom.com 52040482 REV11 © 2020 Tempo Communications Inc. 05/20...
-
Page 2: Table Of Contents
Table of Contents Description ..................3 Safety ..................... 4 Purpose of This Manual ..............4 Important Safety Information ............5–7 Introduction ................8–9 Model Designations ..............8 Unpacking and Inspection ............9 Specifications ................. 10–11 OPM ..................10 SLS ..................11 General Information .............. -
Page 3: Description
OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 Description The Tempo Communications fiberTOOLS™ instruments are handheld fiber optic tools designed to measure optical power levels and link loss on multi-mode and single-mode fiber optic cabling networks. -
Page 4: Safety
Observe all of the safety information provided. Purpose of This Manual This instruction manual is intended to familiarize all personnel with the safe operation and maintenance procedures for the Tempo Communications OPM510, OPM520, SLS520, SLS525, SLS530, SLS535 and SLS536 fiberTOOLS instruments. -
Page 5: Important Safety Information
OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 Important Safety Information SAFETY ALERT SYMBOL This symbol is used to call your attention to hazards or unsafe practices which could result in an injury or property damage. The signal word, defined below, indicates the severity of the hazard. - Page 6 Important Safety Information The SLS520, SLS530, SLLS535 and SLS5336 instruments are a laser device conforming to the requirements of CDRH, CFR 1040. While there is no potential for eye damage due to unaided direct exposure, users should always avoid looking directly into the output port. The use of optical viewing instruments, such as microscopes, magnifiers, etc., should always be avoided.
- Page 7 OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 Important Safety Information Electric shock hazard: • Do not insert batteries with the polarity reversed. • Do not open the case of the unit for any reason. It contains no user-serviceable parts.
-
Page 8: Introduction
SM DUAL KIT OPM510 & SLS520 SM DUAL KIT HP OPM520 & SLS520 MM DUAL KIT OPM510 & SLS525 SM T PON KIT OPM510 & SLS530 SM T 1625 KIT OPM510 & SLS535 SM T 1650 KIT OPM510 & SLS536 SM T PON KIT HP OPM520 & SLS530 SM T 1625 KIT HP OPM520 &... -
Page 9: Unpacking And Inspection
OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 Tempo Communications SLS Adapters SC-Source SC/UPC Adapter LC-Source LC/UPC Adapter FC-Source FC/UPC Adapter ST-Source ST/UPC Adapter Tempo Communications Accessories CC-1 Carry Case, Single Instrument PS-100 External Power Supply CC-2-3 Carry Case, Dual & Triple Instrument... -
Page 10: Specifications
IP Rating IP54 Vibration 5Hz to 150Hz, Amplitude = 0.15mm Shock Peak acceleration 25g at a pulse duration of 6ms Compliance CE, FCC (1) The lower limit of 850nm measurement is -60 dBm for OPM510. Specifications subject to change without notice. -
Page 11: Sls
OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 Specifications MODEL SLS520 SLS525 SLS530 SLS535 SLS536 1310/ 1310/ 1310/ Wavelength (±20nm) 1310/1550 850/1300 1490/ 1550/ 1550/ 1550 1625 1650 Range of Use Singlemode Multimode Singlemode Emitter Type Spectral Width ≤... -
Page 12: General Information
Tempo Communications for technical assistance. Battery The OPM510, OPM520, SLS520, SLS525, SLS530, SLS535 and SLS536 instruments are powered by one 9V alkaline battery or one 9V Lithium battery. The external power supply can be used to power and charge all OPM and SLS versions. -
Page 13: Battery Installation Or Replacement
Installation or Replacement (cont’d) OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 ace the batteries, follow these steps: Battery Installation or Replacement n instrument off. To replace the batteries, follow these steps: move battery cover by sliding down. -
Page 14: Operation
(Interchangeable LC/ST/FC). Ext. AC Power Jack ② ② OPM510 & OPM520 can be operated with an DC@250mA. Cleaning the OPM and SLS Interfaces Make sure that the instrument is powered off. Do not look into the output of any SLS port. Unscrew the OPM adapter and use a clean lint fee wipe to clean the exposed OPM detector window. -
Page 15: Sls
】 】 Push the power button to turn the OPM on 【 【 OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 turn the OPM off after five minutes of inactivity. SLS Operations seconds to place the OPM into a constant on mo... -
Page 16: Applications
seconds to place the OPM into a constant on m again for two seconds will revert to the auto off mo 【 【 dB/dBm】 】 Press this key to switch the measu Applications power (dBm) and relative loss (dB). Hold the key u The following applications for the fiberTOOLS instruments are 【... - Page 17 OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 One Test Jumper Method: Connector Loss (cont’d) 4. Disconnect the reference cable end from the optical power meter and insert the cable to be tested using an appropriate ...
-
Page 18: Two Test Jumper Method: Link Loss
Two Test Jumper Method: Link Loss Test jumper 1 Source Power meter Cable plant Test jumper 2 Source Power meter... - Page 19 OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 Two Test Jumper Method: Link Loss (cont’d) 1. If a complete test set (light source and optical power meter) is available at each end, it is advisable to test the output power of ...
- Page 20 Two Test Jumper Method: Link Loss (cont’d) 2. Connect a light source and optical power meter to the respective patch panel ports using the test jumpers, as shown on the left. 3. Using the formula shown above, take the dBm reading on the ...
-
Page 21: Warranty
OPM510 • OPM520 • SLS520 • SLS525 • SLS530 • SLS535 • SLS536 Limited Warranty Tempo Communications Inc. warrants to the original purchaser of these goods for use that these products will be free from defects in workmanship and material for three years, excepting normal wear and abuse.
