VIN (VIN_5V) is the 7 to 12 V DC power source from the ARDUINO
morpho connector (CN7) pin 24. The 5V jumper selection (JP3) must be on pin [3‑4] to select the VIN_5V power
source. In that case, the DC power can come from the ARDUINO
®
Adafruit PowerBoost 500 shield).
An LDO (U16) is used to provide a fixed 5 V from VIN (7-12 V).
VIN_5V configuration: 5V jumper selection (JP3) [3-4] must be connected as shown in
ST morpho connector
ARDUINO ® Power connector
UM3062 - Rev 2
Figure 11. 5V jumper selection JP3[3-4]: VIN_5V power source
(CN7 – Pin 24)
(CN6 – Pin 8)
Hardware layout and configuration
®
connector (CN6) pin 8 (VIN), or from the ST
®
Uno V3 battery shield (compatible with the
Figure
STM32
microcontroller
UM3062
11.
5V LED
(LD3)
VIN/VIN_5V
selection
(JP3 [3-4])
