I N S P I R I N G T H E W O R L D ' S K I T C H E N
30 IN. ELECTRIC FREESTANDING RANGE
COS-305AERC
IMPORTANT: READ AND SAVE THESE INSTRUCTIONS.
FOR RESIDENTIAL USE ONLY.
PLEASE RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
INSTALLATION INSTRUCTIONS
Rev.23.09
