I-View ANYCAM DM-2MIPJ04 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
5/3/2-mega Pixels Network camera
Camera
dm-2MipJ04/5mipJ04 nETWORK
operation Menu
Version: V1.2
Doc. No.: 113012501

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ANYCAM DM-2MIPJ04 and is the answer not in the manual?

Questions and answers

Related Manuals for I-View ANYCAM DM-2MIPJ04

Summary of Contents for I-View ANYCAM DM-2MIPJ04

  • Page 1 5/3/2-mega Pixels Network camera Camera dm-2MipJ04/5mipJ04 nETWORK operation Menu Version: V1.2 Doc. No.: 113012501...

  • Page 2: Safety Information

    Safety information This symbol indicates that dangerous voltage consisting a risk of electric shock is present within this unit. Megapixels This exclamation point symbol is intended to alert the user to the presence of important operating and maintenance (servicing) instructions in the literature accompanying the appliance.
  • Page 3 fire or electric shock. 8. If this product fails to operate normally, contact the nearest service center and never disassemble or modify this product in any way. (I-View is not liable for problems caused by unauthorized modifications or attempted repair.) 9.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS  Read these instructions.  Keep these instructions.  Heed all warnings.  Follow all instructions.  Do not use this apparatus near water.  Clean only with dry cloth.  Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
  • Page 5 SAFETY INFORMATION FCC STATEMENT This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received including interference that may cause undesired operation.

  • Page 6: About This Guide

    If technical problems arise with the use of our products in which you and your vendor cannot resolve, please try the following: If you have an Internet connection, visit the I-View website http://www.i-view.com.tw (Taiwan) for any software or product updates, or email to support@i-view.com.tw (Taiwan) or Tel: 886-3-510-3001 Fax: 886-3-510-3002 (Taiwan).

  • Page 7: Table Of Contents

    Table of Contents Chapter 1. Introduction ---------------------------------------------------------------------------------------- 8 1-1. Highlights of your new Network IP Camera ----------------------------------------------- 8 1-2. Packaging Contents -------------------------------------------------------------------------- 15 1-3. Product Dimension --------------------------------------------------------------------------- 15 1-4. Product Parts Description ------------------------------------------------------------------- 16 Chapter 2. Camera Installation------------------------------------------------------------------------------ 18 2-1. Ceiling Mount installation ------------------------------------------------------------------ 18 Chapter 3.

  • Page 8: Chapter 1. Introduction

    Chapter 1. Introduction 1-1. Highlights of your new Network IP Camera Congratulates on purchasing this 2/5Mega pixels Network Dome Camera! This IP Camera provides 2/5-Mega pixels high-resolution video quality, with its advanced megapixel lens; you can view remote images in more detail than conventional close-circuit cameras. Other highlights of this network IP Camera include: ☆...

  • Page 9: Product Specification

    ☆ Product Specification DM-2MIPJ04 Series System Platform: Mstar DSP chipset; 512MB Flash; 1024MB DDR II RAM and Linux 2.6 Embedded O.S. Image Device 1/2.8" 2MP Sony progressive scan CMOS sensor. Video Setting Compress: H.265+/ H.265 / H.264, CBR/VBR mode Frame Rate: 30fps @2MP, 20fps @4MP, 25fps for the rest resolution; Frame, Bit Rate, Quality, I-Frame (1-200s) items adjustable.
  • Page 10 Overlay: Text / Time Stamp / Frame rate/ Bit Rate display. OSD: Text supports more than OSD 80 characters on-screen display, Front type, Front size, position & Color adjustable by user. Audio Setting *G.711/ G.71a/ACC audio encoding, 8K/16K sample rate, 6400 Bit Rate. *Support two-way audio.

  • Page 11: Operation

    Motorized Lens: f=3〜2.7~12mm/ F1.2〜F2.8 (DM-2MIPJ04-M0314 ) f=3〜2.7~12mm/ F1.2〜F2.8 P-IRIS (DM-2MIPJ04-M0314 ) IR Cut: Removable IR-cut filter; sensitivity and threshold at Day & Nighttime modes. support auto, manual, trigger, off modes. IR Illuminators: IR Illuminators effective up to 35 meters above. Surge Protector Power: 2KV @ 1.2/50μS Common mode.
  • Page 12 DM-5MIPJ22 Series System Platform: Mstar DSP chipset; 512MB Flash; 1024MB DDR II RAM and Linux 2.6 Embedded O.S. Image Device 1/2.8" 5MP Sony progressive scan CMOS sensor. Video Setting Compress: H.265+/ H.265 / H.264, CBR/VBR mode Frame Rate: 25fps @2592x1944 resolution , 30fps @ the rest resolution; Frame, Bit Rate, Quality, I-Frame (1-200s) items adjustable.
  • Page 13 Overlay: Text / Time Stamp / Frame rate/ Bit Rate display. OSD: Text supports more than OSD 80 characters on-screen display, Front type, Front size, position & Color adjustable by user. Audio Setting *G.711/ G.71a/ACC audio encoding, 8K/16K sample rate, 6400 Bit Rate. *Support two-way audio.
  • Page 14 Motorized Lens: f=3〜2.7~12mm/ F1.2〜F2.8 (DM-5MIPJ04-M0314 ) f=3〜2.7~12mm/ F1.2〜F2.8 P-IRIS (DM-5MIPJ04-M0314 ) IR Cut: Removable IR-cut filter; sensitivity and threshold at Day & Nighttime modes. support auto, manual, trigger, off modes. IR Illuminators: IR Illuminators effective up to 35 meters above. Surge Protector Power: 2KV @ 1.2/50μS Common mode.

  • Page 15: Packaging Contents

    1-2. Packaging Contents Check the contents of your new Network IP Camera when you unpack the package. If any item is missing, please contact your dealer of purchase for help. The package includes items as below:  Network Camera x 1ea ...

  • Page 16: Product Parts Description

    1-4. Product Parts Description A: RJ45 LAN port  A:Video ou IR LED IR Sensor Lens A+: Alarm out A-: Alarm out A1: Alarm in + C: Alarm in - Micro SD card slot A/B: Audio in/out AG: Audio ground Reset Button V+: DC12V(+) V -: DC12V(+)

  • Page 17: Power Block

    Power block Alarm I/O & Audio in/out port Fix hole Rubber Seal plug on the hole for Power & I/O & Audio in/out Cables Lens Rubber Seal plug on the hole for RJ45 Ethernet Cables Cabling Cutout & RJ45 Socket fixed bracket Cover Zoom screw...

  • Page 18: Chapter 2. Camera Installation

    Chapter 2. Camera Installation 2-1. Ceiling Mount installation  Preparation – Remove the dome cover 1. Use the supplied security torx key to loosen (not remove) the three cover screws. 2. Loosen the three screws (marked with the triangle icon) on the dome base.
  • Page 19  Fix the camera on the Ceiling & Wall 1) Paste the Mount hole sticker on the position that you want to install. 2) According to your needs, create 6mm (0.2”) holes at the T1/T2template positions. Then insert the screw anchors into the holes. If you want to feed wiring from the hole on the top of the back case, create a circular opening (bottom conduit hole) in the mounting surface.

  • Page 21: Chapter 3. Running Ip Camera By Witness Pro Nvr Software

    Chapter 3. Running IP Camera by Witness Pro NVR software 3-1. Network Deployment General Connection (without PoE) 1. Connect RJ45 Ethernet cable to a switch. Use a Category 5 Cross Cable when your network camera is directly connected to PC. 2.

  • Page 22: Install Witness Pro Nvr Software

    IP camera which allow you run 32/64 channels IP cameras on a PC. Please follow the steps below to complete the installation of Witness Pro NVR software.  While into Windows, and insert the I-View DVR software CD into a CD/DVD drive.  Select the NVR64 or NVR32 software Fig.
  • Page 23 Step 5. Click the “Browse” button to install into a different directory, otherwise click on the “Next” button to install the software into the proposed director. Fig. 1-3-1.5 Installation Directory Step 6. Select “No, I will restart my computer later” and press on the “Finish”...

  • Page 24: Setting Ip Camera For Witness Pro Nvr Software

    Fig B  Search IP camera: Click this icon will auto search IP cameras of I-View brand. You can refer to the Fig A diagram. Move the Mouse and click to the IP camera which you want to selected and...
  • Page 25 There is no conflict between the define IP address and the other device of the same LAN. b. The Username/Password of all IP cameras is the same. This function uses for the I-View’s IP camera only.  Change IP: Click “Change IP” icon to setup the DHCP or Static IP address for individual IP cameras.
  • Page 26 2. Setup the parameters of Individual IP camera Fig D This section will allow you setup the parameters for individual IP camera for I-View’s and the other brand.  Disable channel: This will disable the selected channel when enable this function.
  • Page 27 The Fig D diagram please refers to “1. Setup the parameters of All IP cameras (For I-View’s IP camera only)” Section  Advance setup: Click this icon will enable the detail parameters setting of IP camera. You need to load the Active X if this NVR is activated this process at first time.
  • Page 28  Reboot: Click this icon will reboot the IP camera.  Setup: Click this icon for detail setting of IP camera (refer to I-View’s IP camera; maybe there are some difference setting diagram when used difference models); you may not need to I.E. Browser for the detail IP camera setting.
  • Page 29 :Click this icon to save the video clips from SD card to HDD of your PC. c. Search: Click this icon and the search time period from SD card. The video clips information will list on the table list. You can playback the video clips of SD card without download them.

  • Page 30: Chapter 4. Accessing Ie, Chrome, Safari And Firefox Browser

    Chapter 4. Accessing IE, Chrome, Safari and Firefox Browser You can use your new Network IP Camera by its web user interface via IE, Chrome, Safari and Firefox. You must know the IP address of IP Camera before you can connect to it. The IP Camera will use DHCP server on your local network to obtain an IP address automatically by default.

  • Page 31: Install Plug-In On Ie, Chrome, Safari And Firefox Browser

    4-1. Install Plug-in on IE, Chrome, Safari and Firefox Browser You can connect to the IP camera by Internet Explorer or other web browsers for remote viewing by entering IP address in address bar. When you connect to IP Camera, the use login screen will appear when you get connected.

  • Page 32: Using Rtsp Players

    4-2. Using RTSP Players To view the video streaming media using RTSP players, you can use one of the following players that support RTSP streaming such as Quick Time Player, Real Player, VLC media player 1. Launch the RTSP player. 2.

  • Page 33: The Function Description Of Live Window

    4-3. The Function Description of Live Window After Plug-in is installed, you should be able to see the live video from IP camera as below. 1 2 3 12 13 14 15 This section introduces the function buttons of live window. You can test the IP camera function from your Brower.
  • Page 34 File: Click this icon to playback video clips or snapshot from the Hard disk or SD card. Snapshot: Click this icon to snapshot and save to the assign storage path. Click this button, to snap the current image and save it as JPG format automatically. The default save path is C:\User\Public\Documents, and the storage path is changeable Recording: Click this icon and the icon become to Red (Recording On), click this icon again the...

  • Page 35: The Function Description Of Setup Window

    4-4. The Function Description of Setup Window Click icon to start setup the parameters of IP camera. You can configure basic IP camera settings like data transfer protocol and data storage folder…etc.  Camera: Image: Click this button to setup the video parameters. ...
  • Page 36 application.  Horizon Flip: Disable/Enable to rotate horizontal image position to for difference installation application.  Vertical Flip: Disable/Enable to rotate Vertical image position to for difference installation application.  Defogging: Disable/Enable modes selectable, the default setting is disable.  WDR: Disable/Enable modes selectable, the default setting is disable. ...
  • Page 37 OSD: Click this button to setup the Time stamp and Text OSD position.  OSD: Enable this function to set up the Timestamp and Text OSD position and format..  Color Style: Choose the font style from this tab to suit for the filed application. ...
  • Page 38  Font Size: Select the font size, there is 3 kinds of size can be selected.  Content: Enter the text which you want display on the image.  Privacy Mask: Select this tab to enable and set up the Privacy Zones.
  • Page 39 Follow up the steps below to set up the Privacy mask function. 1. Press and drag the left button of Mouse to set up the detection areas in which you want to paste the mask on the image. 2. Repeat the step 1 process to make another mask on the video. (Maximum 4 mask zones) 3.
  • Page 40 Audio: Click this button to set up the audio parameters.  Encode: This section to setup the audio Encodes, sample rate and Bite rate.  Enable: Enable this function for audio recording and 2-way audio application.  Encode Type: Select the audio encoding types, G711, G711A, AAC mode. ...
  • Page 41  Network: Click this button to setup the Network parameters Basic: Click this button to setup the video parameters.  Mode: Get IP address automatically: Select this option to obtain an available dynamic IP address assigned by the DHCP server each time the camera is connected to the LAN. Use Static IP address: Select this option to manually assign a static IP address to the Network Camera.
  • Page 42 1. If the DHCP server is available, you can check to automatically obtain an IP address and other network settings from that server. 2. The valid value range of Maximum Transmission Unit (MTU) is 500 ~ 9676. 3. The Multicast sends a stream to the multicast group address and allows multiple clients to acquire the stream at the same time by requesting a copy from the multicast group address.
  • Page 43 P2P: Click this button to setup the P2P could storage service, you can choose the DANALE third party could service. You can call the local vendor to get this service.  SMTP (Mail setting): CClick this button to setup the email parameters. The system can be configured to send an Email notification to all designated receivers if an alarm event is detected, e.g., motion detection event, video loss, tamper-proof, etc.
  • Page 44 Before you start, please configure the SMTP Server settings before using the Email function. 1. Entry the email addresses (sender’s email address). 2. Entry the password and confirm the password again. 3. Entry the SMTP Server IP address or host name (e.g., smtp.gmail.com). 4.
  • Page 45 Connect Check: This is revised function.  PTZ Config: Click this tab to setup the IP camera configure with the Pan/Tile motor. AF (Auto Focus) Configuration: Click this tab to setup the Motorized Lens configuration of IP camera.
  • Page 46  Event: Motion Detection: Click this button to setup the video parameters.  Enable: Click “ Setup” icon to configure the schedule.  Schedule: Setup the brightness of video, the high value will get more brightness image. Add schedule: Press and drag the left of the Mouse button to add the schedule and it will show the yellow bar when setup is finished.
  • Page 47  Trigger Recording: Setup the video recording when alarm is triggered.  Trigger Snapshot: Setup the snapshot to send out via email or save into the FTP server when alarm is triggered.
  • Page 48  Trigger output: Trigger the alarm output when alarm is triggered.  Trigger Audio: The camera can enable the sound alarm from the speaker of the IP camera when the alarm is triggered. The sound alarm can work alone without need the NVR connection. You also can upload the MP3 format sound alarm file to the IP camera by yourself IO: Click this tab to setup the alarm input and alarm output.
  • Page 49  Storage:  Storage Config: Click this button to setup the video parameters.  Local Storage: Check “ Memory Card & USB “ to save the video or snapshot file on the selected storage device.  Network Storage: Check “ NFS “ to save the video or snapshot file on the selected NFS storage device.
  • Page 50  Enable: Check “Enable” icon to select the video recording or snapshot.  Record: Check “Record” icon to select the video recording or snapshot function. You can choose the Video stream mode with audio recording. The recording format is MP4. ...
  • Page 51  System: User Manage: Click this button to add or modify the right of authorized users.  User: Click this tab to setup the authorized users.  Add User: Click this icon to add the new authorized user. There are 3 levels authorized users, admonitor, operation and user.
  • Page 52  Date & Time: Click this button to setup the video parameters.  Update Method: There are 3 way for time synchronization, NTP, Manual, and P2p. Manual: Sync the timer with the connected PC. Press the “ PC Sync” icon the IP camera will time sync with the connected PC.
  • Page 53 adjusted according to the original time and the time difference between the two time zones. From the Time Zone drop-down menu to select the Time Zone in which the cameralocates. GMT: Adjust the time to make it more exactly.  Enable DST Setup the contrast of video, the high value will get stronger contract image. Check “...
  • Page 54  Upgrade: Click this tab to update the newest Firmware. You can visit www.i-view.com.tw to find put the newest Firmware when needed.  Select Firmware: Click “ Browse” icon to select the new Firmware file. Please save the Firmware at the C:\ or E:\ path directory to avoid the update failed, then click “Upgrade” icon to updates the Firmware, after select the correct Firmware file.

  • Page 55: The Function Description Of File Window

    4-5. The Function Description of File Window Click “ Playback “ section to playback the video clips or snapshot file of IP camera from the SD card or HDD of PC. The File Management interface as shown in the follow figure. Select the Recorded type, File type, Stream type, and entry the assign time period, then click “...

  • Page 56: The Function Description Of Alarm Log Window

    4-6. The Function Description of Alarm Log Window Click “ Alarm “ section to check the alarm log information and the interface shown as the below diagram. 4-7. Setup Local Recording Path Click “ Local Setup “ section to setup the saving path of PC for video recording, snapshot and snapshot file when playback.

  • Page 57: Chapter 5. Troubleshooting

    Chapter 5. Troubleshooting Before you send this IP Camera back to your dealer when you found this IP Camera is not working properly, please checks the table as below to save your time. Problem description Possible solution(s) Can’t connect to IP Camera ...
