SOLDERING IRON SET

PLBS 30 B2

SOLDERING IRON SET

Operating and safety instructions

IAN 103977

Table of Contents

Need help?

Do you have a question about the 103977 and is the answer not in the manual?

Questions and answers

Summary of Contents for Parkside 103977

Page 1 SOLDERING IRON SET PLBS 30 B2 SOLDERING IRON SET Operating and safety instructions IAN 103977...
Page 2 GB / IE Operational and safety instructions page...
Page 3 ✔ ✘...
Page 4: Table Of Contents
Table of contents Symbols used ......................................1. Introduction ............................2. Technical specifications ........................ Pack contents ......................................Features ........................................Technical specifications for mod. no. PLBS 30 B2 ....................Scope of use ......................................3. Before using the tool ........................Assembling the soldering stand (fig. A/B) ........................
Page 5: Symbols Used
Symbols used Follow the warnings and safety instructions! Read the operating manual Wear eye protection Wear protective gloves Wear protective clothing Wear a dust mask Electric shock Caution hot! No eating or drinking No smoking Do not inhale poisonous fumes Avoid contact with your skin 1.
Page 6 Safety instructions for your soldering iron CAUTION! RISK OF ELECTRIC SHOCK! Do not use the soldering iron if the handle, the mains cable or the mains plug are damaged. Never open the soldering iron's housing! - Do not expose the soldering iron to moisture or rain. - We recommend that you work in the vicinity of the mains socket so that you can quickly pull the plug from the socket in the event of an emergency.
Page 7 CAUTION RISK OF FIRE! To reduce the risk of fire, place the soldering iron only in to its holder or on to a non- flammable surface when it is not in use. Avoid contact between the hot parts of the soldering iron and the plastic parts of the soldering iron stand.
Page 8: Technical Specifications
The soldering iron is fitted with a special mains cable, which may not be damaged. When working, take care not to touch the mains cable with the hot soldering iron. If the mains cable is damaged it may only by replaced by the manufacturer or by the manufacturer's customer service.
Page 9: Technical Specifications For Mod. No. Plbs 30 B2
Technical specifications for mod. no. PLBS 30 B2 Rated voltage 230 V ~ / 50 Hz Rated power 30 W Solder Ø max. 2 mm Protection category I Scope of use The soldering iron is designed for soldering of electrical wires and circuit boards as well as use as a wood burning pen.
Page 10: Before Using The Tool
3. Before using the tool Assembling the soldering stand (fig. A/B) • Fit the soldering iron holder (15) to the soldering stand (1) before you use the soldering iron for the first time. Start by inserting the soldering iron holder's (15) locating pin into the the slot provided in the stand's housing.
Page 11: Accessory Compartment
Accessory compartment • The soldering stand is fitted with a useful accessory compartment for storage of spare soldering tips etc. 4. Using the device Switching on and off • Connect the soldering iron to the mains to switch it on and to heat it up. •...
Page 12: Additional Information On Soldering
occasionally with the cleaning sponge (2) and re-tin the tip if necessary. Use a de- soldering braid (not supplied) to clean the joint, to de-solder and to remove excess solder from the joint. Cover the excess solder with the de-soldering braid and heat up the soldering tip (9).
Page 13: Cleaning
Cleaning CAUTION - DANGER OF BURNS! Allow the soldering iron to cool completely before cleaning. To avoid damage, do not use aggressive cleaning material, metal brushes or sharp objects such as knives, etc. • Clean the device with a soft, slightly damp cloth if required. Ensure that no moisture enters the device.
Page 14: Disposal
This product was manufactured and tested with care. In the unlikely event of a fault the machine must be repaired by an authorised customer service centre. 5. Disposal This symbol indicates that this product may not be disposed of together with domestic waste in compliance with the (2012/19/EC) directive pertaining to waste electrical and electronic devices (WEEE).
Page 15: Warranty
6. Warranty Warranty provided by Walter Werkzeuge Salzburg GmbH Dear customer, This device comes with a 3 year warranty from the date of purchase. In case of defects in the product you may be entitled to legal claims against the seller of the product. These legal claims are not restricted by the following warranty.
Page 16 Service Walter Tools (GB) Ltd. E-Mail: service-uk@walter-werkzeuge.com Tel.: 00800 925 837 88 IAN 103977 Supplier: Please note that the following address is not a service centre address Please contact the above-mentioned service centre first. Walter Werkzeuge Salzburg GmbH Gewerbeparkstraße 9...
Page 20 Walter Werkzeuge Salzburg GmbH Gewerbeparkstrasse 9 5081 Anif, Austria V. 1.0 Version: 01/2015 IAN 103977...

This manual is also suitable for:

Plbs 30 b2
