Continuity Test - multicomp pro MP730424-US User Manual

3. Set the range.
Press the Range softkey to set the range. Auto range automatically selects the range for the measurement based on the
input.
Note:
• 1000 V input protection is available in all ranges.
• 10% over range for all ranges except 50 MΩ range. If the reading exceeds 55 MΩ in 50 MΩ range, "overload" will be
displayed.
4. Set the measurement speed.
Press the Speed softkey to switch between Low, Mid or High. See Measurement Speed.
5. Set the relative value.
Press the Rel softkey to turn on or off the relative operation. For relative operation, the multimeter subtracts the
pre-specified value of REL operation from the actual measurement result and displays the result. See the "Relative Value".
Position.
Tip:
• If the measured resistance is small, relative operation is recommended in order to reduce the error caused by test lead.
• Both ends of the measured resistance should be placed far away from your hands and desks that can conduct electricity;
otherwise, the measurement result might be inaccurate. The greater the measured resistance is, the greater the affect will
be.

Continuity Test

This section describes how to configure continuity test.
Operating Steps:
1. Enable the continuity test.
Press on the front panel, press it again to enter continuity test mode.
2. Connect the test lead.
Newark.com/multicomp-pro
Farnell.com/multicomp-pro
sg.element14.com/b/multicomp-pro
Page <18> 19/01/25 V1.0
