DEC-2
004804051
Compliance
MID Directive
Certificate number
Purpose
The DEC-2 is a static (electronic) calibrated electricity meter of
three-phase alternating current in a direct system.
Functioning
A special electronic system under the influence of current flow
and applied voltage in each phase, generates pulses in propor-
tion to the electricity consumed in this phase. Phase energy con-
sumption is indicated by flashing the corresponding LED (A, B,
C). The sum of the pulses of the three phases is indicated by a
flashing LED shall be converted to energy, taken throughout the
three-phase system, and its value is determined by the segment
LCD display.
Decimal represent the hundredths (0.01 kWh = 10 Wh).
ETI, d.o.o., Obrezija 5, SI-1411 Izlake
www.etigroup.eu/products-services
Electric energy meter,
2014/32/EU
0120/SGS/0169
- 1 -
3-phase

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 004804051 and is the answer not in the manual?

Questions and answers

Related Manuals for ETI 004804051

Summary of Contents for ETI 004804051

  • Page 1 ETI, d.o.o., Obrezija 5, SI-1411 Izlake www.etigroup.eu/products-services DEC-2 Electric energy meter, 3-phase 004804051 Compliance MID Directive 2014/32/EU Certificate number 0120/SGS/0169 Purpose The DEC-2 is a static (electronic) calibrated electricity meter of three-phase alternating current in a direct system. Functioning A special electronic system under the influence of current flow and applied voltage in each phase, generates pulses in propor- tion to the electricity consumed in this phase.

  • Page 2: Pulse Output

    Measured value Active energy consumed [kWh] Pulse output The indicator has a pulse output. This allows you to connect a pulse meter-reading pulses generated by the counter. For proper operation of the indicator is not required to connect additional devices. Meter number The meter is marked with individual serial number allowing its unambiguous identification.
  • Page 3 Sealing The meter has sealable input and output terminal covers to pre- vent any attempts to bypass the meter. - 3 -...

  • Page 4: Description Of Terminals

    Mounting 1. Disconnect the power supply. 2. The indicator mounted on a rail in the distribution box. 3. Using a screwdriver, remove the screws and remove the front shield meter terminals. 4. Connect power to terminals 1 (L1 IN), 3 (L2 IN), 5 (L3 IN). 5.

  • Page 5: Wiring Diagram

    Wiring diagram - 5 -...
  • Page 6 Technical data installation 4-wire rated voltage 3×230/400 V minimum measured current 0.04 A base current 0.25÷5 A maximum current 80 A voltage measuring range 160÷265 V measurement accuracy (EN50470-1/3) class B rated frequency 50 Hz insulation protection class housing PC+ABS material own power consumption <10 VA;...

  • Page 7: Warranty

    Dimensions Warranty ETI products are covered by a 24-month warranty from the date of purchase. The warranty is only valid with proof of purchase. Contact your dealer or contact us directly. CE declaration ETI declares that the device is in conformity with the essential...
  • Page 8 General work safety conditions » Please read the instructions carefully before installation. » The device should be installed and operated by qualified per- sonnel who are familiar with its design, operation, and asso- ciated risks. » Do not install a meter that is damaged or incomplete. »...
