LUCCI SENTINEL Installation Instructions

Installation Instructions
To ensure correct function and safety, please read and follow all instructions carefully before assembly, installation and
use of this luminaire. Please keep the installation instructions for future reference.
NOTE: This installation instruction applies to the 12V side of the luminaire only.
This luminaire is rated 12V and is classified as ELV (Extra Low Voltage).
This luminaire can be DIY and does not require any electrical connection or disconnection.
Do not plug this luminaire directly into 240V.
When working with 240V, a licensed electrician is required.
The assistance of a technical person with the correct tools may be required to complete the installation.
The Lucci wiring kit (SKU# 220826, 220827) and Lucci transformer (SKU# 220818, 220819, 220829)
are sold separately.
Warranty
•
This luminaire is covered by a 12-month warranty valid for in-store replacement or refund only.
•
The warranty period starts from the date of purchase, not the date of installation.
•
Please retain the proof of purchase for any warranty enquiries.
•
Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
•
Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void the
warranty.
Installation Requirements
•
All wiring and installation of the luminaire must adhere to the latest local and national wiring rules.
e.g. AS/NZS 3000 Electrical installations. If unsure, please contact a licensed electrician.
•
The luminaire must not be used if the protective lamp shade has been cracked or damaged.
•
Do not exceed the maximum wattage rating.
•
Select a suitable location for installation:
− This luminaire is suitable for step light or recessed in-ground installation only. Not suitable for ceiling
installations.
− This luminaire is protected against water penetration to IP65 and IP67 – Ground recessed luminaires Standards.
This is resistance to water jets for 15mins from all directions by means of a hose and nozzle from 3m away and
temporary immersion in 150mm depth of water for 30mins.
NOTE: Ensure the luminaire is positioned in a location where the water can be easily drained away.
The luminaire is not designed to be immersed in water for long periods.
− The wiring kit and connectors are not suitable for underground installation without protection from water or damp
conditions.
NOTE: Ensure the wiring kit and connectors are positioned in a location where the water can be easily
drained away. They are not designed to be immersed in water.
NOTE: The installation location may require a gravel substrate to help with water drainage, to prevent the
wiring kit and connectors being submerged in water after heavy rain or from watering the garden.
−
The mounting point must support 2 times the weight of the luminaire.
−
Thermal insulation material must NOT be abutted or cover the luminaire.
−
Ensure there is no thermal insulation, loose fill insulation, loose combustible materials, leaves etc. near or
covering the luminaire inside the wall. If there is, a barrier or guard is required to prevent anything from covering
or abut to the luminaire.
1 | P a g e
SENTINEL GROUND LIGHT
with VERSION 2 connector
SKU# 220308
Rated Voltage 12V
v 3 . 0 ( 1 1 / 2 0 2 3 )
