LUCCI 229414 Installation Instructions

Installation Instructions
NOTE: This installation instruction applies to the 12V side of the luminaire only.
This luminaire is rated 12V and is classified as ELV (Extra Low Voltage).
This luminaire can be DIY and does not require any electrical connection or disconnection.
Do not plug this luminaire directly into 240V.
When working with 240V, a licensed electrician is required.
The assistance of a technical person with the correct tools may be required to complete the install.
The Lucci wiring kit (SKU# 220826, 220827) and Lucci transformer (SKU# 220818, 220819, 220829，
220843) are sold separately.
To ensure correct function and safety, please read and follow all instructions carefully before assembly, installation and
use of this luminaire. Please keep instructions for future reference.
Warranty
• This luminaire is covered by a 5 year warranty. The warranty is from date of purchase, not the date of installation.
• Please retain proof of purchase for any warranty enquiries.
• This luminaire is not suitable for use with dimmer switches.
• Warranty will be void if the luminaire is used on the same circuit which has a dimmer switch.
• Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
• Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void
warranty.
Installation Requirements
• All wiring and installation of the luminaire must adhere to the latest local and national wiring rules.
eg. AS/NZS 3000 Electrical installations. If unsure, please contact a licensed electrician.
• Replace any cracked protective lamp shade to maintain IP rating when using this luminaire.
• Select a suitable location for installation:
This luminaire is suitable for deck installation only. Not suitable for ceiling or wall installations.
-
This luminaire is protected against water penetration to IP65 standards, which is jets of water from any
-
direction. This must be maintained during installation.
The wiring kit and connectors are not suitable for underground installation without protection from water or
-
damp conditions. Ensure they are positioned in a location where the water can be easily drained away. They are
not designed to be immersed in water.
The installation location may require a gravel substrate to help with water drainage, to prevent the wiring kit and
-
connectors being submerged in water after heavy rain or from watering the garden.
- The mounting point must support 2 times the weight of the luminaire.
• Take care not to pull any electrical wires during unpacking as this may damage the connection.
• Lay out all the components on a smooth surface and make sure there are no components missing before
assembling. If parts are missing, return the complete product to the place of purchase for inspection or replacement.
• Check whether the luminaire has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
• Ensure power to the circuit you are working on has been switched OFF, before commencing any electrical work.
1 | P a g e
PIER LED 12V DECK LIGHT
with VERSION 2 connector
SKU# 229414,229415,229416
Rated Voltage 12V
v 1. 0 ( 12/ 2 0 23 )
