LUCCI 240812 Installation Instructions

Installation Instructions
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this product. Please keep instructions for future reference.

Warranty

•
This luminaire is covered by a 3 year warranty. The warranty is from date of purchase, not the date of installation.
•
If the luminaire is not assembled and installed by a licensed electrician the warranty will be void.
•
Please retain proof of purchase and evidence of installation by a licensed electrician.
•
Warranty will be void if there is any damage due to improper usage or modification to the luminaire.
•
Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void warranty.

Installation requirements

•
Must be assembled and installed by a licensed electrician.
•
All wiring and installation of the luminaire must adhere to latest local and national wiring rules.
eg. AS/NZS 3000 Electrical installations.
•
This luminaire is not suitable for use with dimmer switches and should not be used on a circuit which has a dimmer.
•
Select a suitable location for installation:
This luminaire is protected against water penetration to IP54 standards, which is splashing from every
-
direction. This must be maintained during installation.
It is suitable for indoor or outdoor use.
-
The mounting point must support 2 times the weight of the luminaire.
-
•
Take care not to pull any electrical wires during unpacking as this may damage the connection.
•
Lay out all the components on a smooth surface and make sure there are no components missing before assembling.
If parts are missing, return the complete product to the place of purchase for inspection or replacement.
•
Check whether the luminaire has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.

Installation directions

Remove all packaging material from the product and be careful not to throw away accessories that may be hidden
within the packaging material.
1. Switch off the power before commencing the installation. (Fig.1)
2. Remove the mounting bracket by loosening the screws from both sides using the Allen key provided. (Fig.2)
3. Adjust the colour temperature according to your needs by using the switch A. (Fig.3)
4. Install the mounting bracket on the wall by using appropriately sized mounting screws and anchors. Ensure the
screws and anchors used are suitable for mounting surface and the surrounding environment. (Fig.4, 5)
NOTE: It is recommended that a non-corrosive bead of silicone be applied before installation onto the wall
ensuring that no water can run down into the cabling.
5. Connect the mains supply wire to the luminaire using the terminal block provided. Ensure that the wires are secure
and no bare wires are exposed. (Fig.6)
1 | P a g e
WITNER LED WALL BRACKET with Sensor
SKU# 240812
Rated Voltage 220-240V~ 50Hz
v 1 . 0 ( 0 9 / 2 0 1 9 )
