LUCCI LEDLux Desi Series Installation Instructions

Led 12v step light

Advertisement

Installation Instructions
NOTE:
This fitting is 12V extra-low voltage and can be DIY.
This installation instruction applies to the 12V side of the fitting only.
When working with 240V, a licensed electrician is required.
Lucci wiring kit (SKU# 220826, 220827) and Lucci transformer (SKU# 220818, 220819, 220829) sold separately.
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before using the product. Please keep instructions for future reference.

Warranty

This light fitting is covered by a 3 year warranty.
Please retain proof of purchase.
Warranty will be void if there is any damage due to improper usage or modification to the fitting.
Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void
warranty.

Installation requirements

All wiring and installation of the light fitting must adhere to local and national wiring rules.
eg. AS/NZS 3000:2007/Amendment 2:2012 Electrical installations.
Do not exceed the maximum wattage rating.
This fitting is rated IP54. This must be maintained during installation.
Replace any cracked protective lamp shade to maintain IP rating when using this fitting.
Select a suitable location for installation:
-
This fitting is rated IP54 which is protected against splashes of water.
-
The wiring kit is not suitable for underground installation without protection from water or damp conditions. It is
not designed to be immersed in water.
DO NOT cover the LED fitting with thermal insulation material.
Take care not to pull any electrical wires during unpacking as this may damage the connection.
Lay out all the components on a smooth surface and make sure there are no components missing before
assembling. If parts are missing, return the complete product to the place of purchase for inspection or replacement.
Check whether the fitting has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
Ensure power to the circuit you are working on has been switched OFF, before commencing any electrical work.

Installation directions

1.
Remove all packaging material from the product and be careful not to throw away accessories that may be hidden
within the packaging material.
2.
Turn OFF the power to Lucci transformer (sold separately). Fig.1
3.
Take out the moulded box from the fitting.
4.
Cut the hole in the wall. Refer to the specification section for cut-out size if using springs or if using moulded box.
Ensure all the clearance values are maintained for the LED fitting. Fig.2
If using springs – Proceed to step 6.
5.
1 | P a g e
DESI LED 12V STEP LIGHT
SKU# 239320, 239321, 239322, 239323, 239324, 239325
Rated Voltage 12V
The warranty is from date of purchase, not the date of
installation.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LEDLux Desi Series and is the answer not in the manual?

Questions and answers

Summary of Contents for LUCCI LEDLux Desi Series

  • Page 1 Lucci wiring kit (SKU# 220826, 220827) and Lucci transformer (SKU# 220818, 220819, 220829) sold separately. Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all instructions carefully before using the product. Please keep instructions for future reference.
  • Page 2 If using moulded box - Secure the moulded box into the wall. Fig. 3 Remove the cover from the connector on the Lucci wiring kit (SKU# 220826, 220827 – sold separately).Connect the fitting to the wiring kit. NOTE: The wiring kit is rated for Max. 80VA load only. Fig. 4 Connect the Lucci wiring kit (SKU# 220826, 220827 –...
  • Page 3 Installation Instructions Specifications Square Round SKU # 239320 239321 239322 239323 239324 239325 Color White Silver Charcoal White Silver Charcoal Rated Voltage Rated Wattage HOYOL LEDS, 4000K, 40lm IP Rating IP54 Weight 0.17kg When using springs : Dia: 74mm Cut Out Size When using moulded box : Dia:78mm Dimensions H: 80mm W: 80mm Ext: 54mm...
