Page 1: Table Of Contents
January, 2025 NA - S1RII For Panasonic Lumix S1R II Camera PN 17722 User Manual Housing FF- MIL Introduction Package Contents Important Instructions Part Names and Functions Housing Mount Opening the housing Closing the housing Preparation for Use Optional Accessories Care/Storage Warranty Specifications... -
Page 2: Introduction
PACKAGE CONTENTS Make sure that you have all the included items listed below before using this product. If some items are missing or damaged, contact your local Nauticam dealer. NA-S1RII Padded Travel Case... -
Page 3: Important Instructions
O-ring renewal between the atmosphere and inside the and port change. housing. Only the accesories specified by Use only Nauticam lubricant on silicone Nauticam must be used. Third-party rubber O-ring. accessories may result in malfunctions or damage to the product. -
Page 4: Part Names And Functions
PART NAMES AND FUNCTIONS Rear View Viewfinder LVF lever Unlock lever AF mode button REC button Focus mode lever Quick control button Joystick - Center Right button Down button Display button Moisture alarm window Up button Left button Delete button Menu/Set button... - Page 5 PART NAMES AND FUNCTIONS Top + Front Views M24 Accessory port Optical fiber cable connection M16 Accessory port Still/movie/S&Q lever Drive mode dial Mode dial M10 Accessory port WB button Exposure compensation button ISO button Main switch Rear dial M16 Accessory port Accessory mounting ball Port lock safety button Port locking lever...
- Page 6 PART NAMES AND FUNCTIONS Back + Side Views Sacrificial zinc anodes 1/4” Threaded tripod holes Zoom/Focus knob release Zoom/Focus knob Playback lever AF-ON lever Shutter release lever Housing unlock button Front dial...
-
Page 7: Housing Mount
HOUSING MOUNT Housing mount Compatible accessories 1/4” -20 mounting threads 17959 Housing Mounting ball with 1/4’’ screws M16 Accessory port 25625 M16 Vacuum Valve II (Optional) M10 Accessory port 25221 M10 Strobe mounting ball 25224 M10 Strobe mounting ball with hole M16 Accessory port 25033 Standard HDMI bulkhead with M16 thread... -
Page 8: Opening The Housing
OPENING THE HOUSING * drawings as illustrations only depress housing unlock button turn housing lock latch anti-clockwise to open the housing flip open the back housing when lock latch is aligned to ‘open’ position... -
Page 9: Closing The Housing
CLOSING THE HOUSING * drawings as illustrations only before closing the housing, clean and lubricate the main O-ring make sure nothing is caught between front and back housing and that they are fully aligned before locking main O-ring insert the housing shaft into the shaft hole and then rotate the lock latch clockwise until you hear and feel it click into place... -
Page 10: Preparation For Use
PREPARATION FOR USE * drawings as illustrations only Installing the Camera - housing tray attachment unlock camera tray lever and remove the tray from the housing * tilt the flip screen as shown before screwing the camera onto the camera tray * when the monitor is open, the eye sensor does not work, hence this housing does not support the use of... - Page 11 PREPARATION FOR USE * drawings as illustrations only Port Mounting depress safety button and rotate anti-clockwise lubricant the port O-ring before mounting align index mark push port assembly straight in until it cannot go further rotate locking lever clockwise to lock Do not operate the red lever with force, make sure the...
- Page 12 PREPARATION FOR USE * drawings as illustrations only Coating housing O-ring Main O-ring remove the main O-ring using an O-ring remover clean the O-ring groove with a cloth and ensure that it is free from salt or other foreign materials lightly coat it with provided lubricant return the main O-ring by slowly pressing from one corner to the whole perimeter...
- Page 13 PREPARATION FOR USE * drawings as illustrations only Setting up moisture alarm Alarm ON/OFF CR2032 Battery remove battery press the battery down until it insulation film click into place switch on the alarm test the alarm - the moisture alarm - connect the wires with a window will flash in dampened cotton bud;...
- Page 14 PREPARATION FOR USE * drawings as illustrations only Changing lens/port without opening the housing If using with vacuum valve : remove the cap from the vacuum valve and press the red button to release pressure before unlocking port lock If using without vacuum valve, please follow from step 2 unlock port lock and remove port assembly...
-
Page 15: Optional Accessories
OPTIONAL ACCESSORIES * drawings as illustrations only Vacuum valve system remove the plug of M16 accessory port from the housing remove the cap from the vacuum valve hand pump vacuum valve slightly lubricate the o-ring and make sure the o-ring is in place accesory port on housing then tighten the vacuum valve to... - Page 16 OPTIONAL ACCESSORIES * drawings as illustrations only Installing Surface USB-PD Power Bank unscrew the M24 accessory port cap from the camera housing and M24-M16 Adaptor screw the M24-M16 adaptor into the housing port * M24-M16 Adaptor is not needed if installing the USB-C Bulkhead into the M16 accessory port plug the USB-C Bulkhead into the accessory port, gently push the...
- Page 17 OPTIONAL ACCESSORIES * drawings as illustrations only Strobe Mounting Ball Installing M5 Strobe Mounting Ball - RECOMMENDED M5 screw remove M5 screw with the allen key provided in the screw #25228 M5 Strobe mounting ball directing onto housing package the M5 thread * the anti-corrosion screw may also be Anti-corrosion unscrewed while removing M5 screw, if this...
- Page 18 OPTIONAL ACCESSORIES Installing Viewfinder firstly remove the pre-installed 0.66x viewfinder gently push the 0.66x viewfinder from the inside of from the housing by removing the retainer o-ring the housing inside rear housing remove the retainer o-ring from the viewfinder align the viewfinder alignment pins with the LCD lightly lubricate the retainer o-ring and place it back display window and push the viewfinder into the from inside the housing...
-
Page 19: Care/Storage
CARE/STORAGE Gently rinse the housing system in fresh Use a microfiber towel to dry the water after dives. Operate all controls and housing system to prevent water buttons at least 3 times while immersed stains on glass and metal finsihing. in fresh water. -
Page 20: Warranty
NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/or poor maintenance; it is the responsibility of the own- er to carefully follow the instructions in our manuals. -
Page 21: Specifications
SPECIFICATIONS Construction Viewfinder Housing body Hard Anodized Aluminium Alloy 32211 Nauticam Full Frame Straight Viewfinder 32°/ 1:1 32212 Nauticam Full Frame Straight Viewfinder 40°/ 0.8:1 Display window Abrasion Resistant Polycarbonate 32213 Nauticam Full Frame Angle Viewinder 32°/ 1:1 Dimensions 32214 Nauticam Full Frame Angle Viewfinder 40°/ 0.8:1 87213 Reverse Angled Viewfinder for EMWL 40°/ 0.8:1... - Page 22 WET LENS COMPATIBILITY *please refer to Nauticam port charts for more setup information Nauticam optical lenses Optional accessories Macro 81203 Super Macro Convertor 3 25101 M67 Flip Diopter Holder for M67 Macro ports 81202 Super Macro Convertor 2 25108 M67 Double Flip Holder for M67 Macro Ports...
- Page 23 Nauticam Internationl Ltd. Rm 2203, CCT Telecom Bldg, 11 Wo Shing St, Fo Tan, Hong Kong Tel. +852 - 26902711 Fax. +852 - 26909778 URL. www.nauticam.com Gallery. www.nauticam.smugmug.com...
