Bridge Mode - ZyXEL Communications PM Series User Manual

Table 12 Network Setting > Broadband > Add New or Edit WAN Interface (Routing Mode) (continued)
LABEL DESCRIPTION
Use Following Select Use Following Static IPv6 DNS Address to have the PM Device use the IPv6 DNS server
Static IPv6 DNS addresses you configure manually.
Address
Primary DNS Enter the first IPv6 DNS server address assigned by the ISP.
Server
Secondary Enter the second IPv6 DNS server address assigned by the ISP.
DNS Server
IPv6 Routing Feature (This is available only when you select IPv4 IPv6 DualStack or IPv6 Only in the IPv4/IPv6 Mode
field. You can enable IPv6 routing features in the following section.)
MLD Proxy Select this checkbox to have the PM Device act as an MLD proxy on this connection. This allows
Enable the PM Device to get subscription information and maintain a joined member list for each
multicast group. It can reduce multicast traffic significantly.
Apply as Default Select this option to have the PM Device use the WAN interface of this connection as the system
Gateway default gateway.
This is available only when you select IPv6 Only in the IPv4/IPv6 Mode field. Enable
DS-Lite
Dual Stack Lite to let local computers use IPv4 through an ISP's IPv6 network. See
Stack Lite on page 41
Click this switch to enable DS-Lite to let local computers use IPv4 through an ISP's IPv6 network.
DS-Lite Relay Specify the transition router's IPv6 address.
Server IP
DHCPv6 Option (This is available only when you select IPv6 Only or IPv4 IPv6 DualStack in the IPv4/IPv6 Mode field.)
IPv6 Address Click the switch to let the PM Device send DHCP requests to the DHCPv6 server to obtain an IPv6
From DHCPv6 address.
Server
Other Click the switch to have the PM Device get other information, such as DNS information, from
Information DHCPv6 packets sent from the DHCPv6 server.
From DHCPv6
This will be enabled if IPv6 Address From DHCPv6 Server is enabled.
Server
Cancel Click Cancel to restore your previously saved settings.
Apply Click Apply to save your changes.

Bridge Mode

Click the Add new WAN Interface in the Network Setting > Broadband screen or the Edit icon next to the
connection you want to configure. The following example screen displays when you select Bridge
mode.
Chapter 6 Broadband
for more information.
PM Series User's Guide
48
Dual
