Prestige 202H Plus
ISDN Internet Access Router

Quick Start Guide

Version 3.40
12/2004

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISDN Internet Access Router 202H Plus and is the answer not in the manual?

Questions and answers

Related Manuals for ZyXEL Communications ISDN Internet Access Router 202H Plus

Summary of Contents for ZyXEL Communications ISDN Internet Access Router 202H Plus

  • Page 1: Quick Start Guide

    Prestige 202H Plus ISDN Internet Access Router Quick Start Guide Version 3.40 12/2004...

  • Page 2: Table Of Contents

    1 Introducing the Prestige...3 2 Hardware Installation ...4 2.1 Rear Panel ...4 2.2 The Front Panel LEDs ...4 3 Setting Up Your Computer’s IP Address ...5 3.1 Windows 95/98/Me...6 3.2 Verifying Your Computer’s IP Address...8 3.3 Windows 2000/NT/XP ...8 3.4 Checking/Updating Your Computer’s IP Address...9 4 Configuring Your Prestige...10 4.1 Accessing Your Prestige Via Web Configurator ...10 4.2 Common Screen Command Buttons ...12...

  • Page 3: Introducing The Prestige

    1 Introducing the Prestige The Prestige 202H Plus is an ISDN Internet access router that offers a complete Internet access solution. The prestige is equipped with two integrated phone ports for connecting analog phones and fax devices. It also provides advanced calling features, such as call waiting, three-way calling, call transferring and forwarding.

  • Page 4: Hardware Installation

    2 Hardware Installation 2.1 Rear Panel LABEL ON/OFF Turn the router on and off by pushing the power button (in is ON, out is OFF). POWER 12VAC Connect to a power source using the power adapter for your region (see your User’s Guide). LAN 1-4 Connect to computer(s) / external hub(s) using an Ethernet cable.

  • Page 5: Setting Up Your Computer's Ip Address

    COLOR STATUS PWR/SYS Green Blinking LAN 1-4 Green Blinking Amber ISDN LNK Green ISDN B1, B2 Green Phone 1-2 Green Blinking 3 Setting Up Your Computer’s IP Address Skip this section if your computer is already set up to accept a dynamic IP address. This is The Prestige is already set up to assign your computer an IP address.

  • Page 6: Windows 95/98/Me

    3.1 Windows 95/98/Me Click Start, Settings, Control Panel and double-click the Network icon to open the Network window. The Network window Configuration tab displays a list of installed components. You need a network adapter, the TCP/IP protocol and Client for Microsoft Networks. If you need the adapter: In the Network window, click Add.
  • Page 7 Restart your computer so the changes you made take effect. In the Network window Configuration tab, select your network adapter's TCP/IP entry and click Properties. Click the IP Address tab. -If your IP address is dynamic, select Obtain an IP address automatically.

  • Page 8: Verifying Your Computer's Ip Address

    Click the Gateway tab. -If you do not know your gateway’s IP address, remove previously installed gateways. -If you have a gateway IP address, type it in the New gateway field and click Add. Click OK to save and close the TCP/IP Properties window. Click OK to close the Network window.

  • Page 9: Checking/Updating Your Computer's Ip Address

    The Internet Protocol TCP/IP Properties screen opens (the General tab in Windows XP). - To have your computer assigned a dynamic IP address, click Obtain an IP address automatically. If you know your DNS sever IP address(es), type them in the Preferred DNS server and/or Alternate DNS server fields.

  • Page 10: Configuring Your Prestige

    4 Configuring Your Prestige Choose one of these methods to access and configure the Prestige. This Quick Start Guide shows you how to use the web configurator wizard only. See your User’s Guide for background information on all Prestige features and SMT configuration. Click the web configurator online help for screen-specific web help.
  • Page 11 Prestige 202H Plus Quick Start Guide If you do not change the password, the following screen appears every time you log in. You should now see the Site Map screen. Click Wizard Setup to begin a series of screens to help you configure your Prestige for the first time. Click a link under Advanced Setup in the navigation panel to configure advanced Prestige features, such as Password setup, WAN and LAN settings, NAT, Dynamic DNS, Firewall, and VPN.

  • Page 12: Common Screen Command Buttons

    4.2 Common Screen Command Buttons The following table shows common command buttons found on many web configurator screens. Back Click Back to return to the previous screen. Apply Click Apply to save your changes back to the Prestige. Reset/Cancel Click Reset or Cancel to begin configuring this screen afresh. 4.3 Using the Wizard to Configure for Internet Access Click Wizard Setup in the main menu to display the first wizard screen.
  • Page 13 Click the Next button to continue. The second wizard screen helps you set up your Prestige for Internet access. In the Transfer Type drop-down list box, choose the type of connection between the router and this remote node. Select 64K, or Leased. If you selected 64K, select a PPP Multilink protocol. In the Max Idle Timeout field, enter the amount of time (in seconds) after which you want the connection to timeout if the line remains consistently idle.
  • Page 14 Prestige 202H Plus Quick Start Guide To change the LAN information on the Prestige, click Change LAN Configuration. Otherwise click Save Settings to save the configuration and skip to step 5.
  • Page 15 Enter the LAN IP address of your Prestige in dotted decimal notation in the LAN IP Address field. For example, 192.168.1.1 (factory default). If you change the Prestige’s LAN IP address, you must use the new IP address if you want Enter a subnet mask in dotted decimal notation in the LAN Subnet Mask field.

  • Page 16: Test Your Internet Connection

    4.4 Test Your Internet Connection Launch your web browser and navigate to www.zyxel.com. You don’t need a dial-up program such as Dial Up Networking. Internet access is just the beginning. Refer to the User’s Guide for more detailed information on the complete range of Prestige features.
  • Page 17 Prestige 202H Plus Quick Start Guide Figure 1 NAT: Mode Click Edit Details. Figure 2 SUA/NAT Server The following table describes the labels in this screen.

  • Page 18: Firewall Overview

    LABEL Start Port No. Type a port number in this field. To forward only one port, type the port number again in the End Port field. To forward a series of ports, type the start port number here and the end port number in the End Port field.

  • Page 19: Enabling The Firewall

    Prestige 202H Plus Quick Start Guide 5.4 Enabling the Firewall From the main screen, click Advanced Setup, Firewall and then Config to open the Configuration screen. Enable (or activate) the firewall by selecting the Enable Firewall check box as seen in the following screen. Figure 4 Enabling the Firewall 5.5 Procedure for Configuring Firewall Rules From the main screen, click Advanced Setup, Firewall and then Rule Summary (for either local network to Internet...
  • Page 20 The following table describes the labels in this screen. LABEL The default action Should packets that do not match the following rules be blocked or forwarded? Make your choice for packets not from the drop down list box. Note that “block” means the firewall silently discards the packet. matching following rules Default Permit Log...
  • Page 21 LABEL Source IP This drop-down list box displays the source addresses or ranges of addresses to which this firewall rule applies. Please note that a blank source or destination address is equivalent to Any. Destination IP This drop-down list box displays the destination addresses or ranges of addresses to which this firewall rule applies.
  • Page 22 Prestige 202H Plus Quick Start Guide Figure 6 Creating/Editing A Firewall Rule The following table describes the labels in this screen. Table 3 Creating/Editing A Firewall Rule LABEL DESCRIPTION Source Address Click SrcAdd to add a new address, SrcEdit to edit an existing one or SrcDelete to delete one.

  • Page 23: Configuring Source And Destination Addresses

    LABEL Destination Address Click DestAdd to add a new address, DestEdit to edit an existing one or DestDelete to delete one. Please see the following section on adding and editing destination addresses. Services Available/ Selected Highlight a service from the Available Services box on the left, then click >> to add it to the Services Selected Services box on the right.

  • Page 24: Troubleshooting

    Table 4 Adding/Editing Source and Destination Addresses LABEL Address Type Do you want your rule to apply to packets with a particular (single) IP address, a range of IP addresses (e.g., 192.168.1.10 to 192.169.1.50), a subnet or any IP address? Select an option from the drop down list box Start IP Address Enter the single IP address or the starting IP address in a range here.
