- Page 1 ILIFE-A12 Pro Robotic vacuum cleaner User Manual For more detailed information, please visit: www.iliferobot.com...
- Page 3 English Dear Customer, Thank you for purchasing the ILIFE A12 Pro Robotic Vacuum Cleaner! You've joined the millions of people cleaning with robots - the smartest way to do it. Please take a few moments to read through this manual and familiarize yourself with your robot to achieve the best performance.
-
Page 4: Table Of Contents
English Table of Contents Safety Instructions ......................3 Product Composition ....................5 List of accessories ........................5 Host introduction ........................6 Robot anatomy .........................7 Self-empty station ........................8 2-in-1 dustbin and water tank ....................9 Remote control .........................9 Product Specifications .....................11 Product Operating ......................12 Attentions ..........................12 Quick guide ..........................14 Select cleaning modes ......................18 Water tank operation ......................19... -
Page 5: Safety Instructions
English Safety Instructions Warnings 1. This robot should not be used by children under 8 or people with mentally challenged, unless they are under supervision. Do not let children sit on the robot or use it as a toy. 2. Attend to the robot promptly if an error occurs during cleaning. Before using the robot, remove all power cords and small objects on the floor. - Page 6 English Safety Instructions 17. Damaged power cords must be repaired by manufacturer’s repair service or certified technicians. 18. Install dustbin and filters properly before using the robot. 19. Do not use the robot in rooms where babies are sleeping. 20. Do not use damaged power cords or charging dock to recharge the robot. Do not use the robot if it’s damaged by falling down, or soaking in water.
-
Page 7: Product Composition
English Product Composition List of accessories Main body Self-empty station Dust bag Remote Control Mopping support Mop cloth Extra side brush X2 High performance filter User manual AAA Battery X2 For more detailed information, please visit: www.iliferobot.com... -
Page 8: Host Introduction
English Product Composition Host introduction Bumper Auto button Laser radar Robot status Operation Functional description Button Press and hold for 2 seconds Turn on the robot Turn off Press the button once Start/Stop cleaning Auto Button Turn on Press and hold for 3 seconds Turn off the robot Green Electricity ≥12%... -
Page 9: Robot Anatomy
English Product Composition Robot anatomy Cliff sensors Nose wheel Side brushes Battery lid Suck passage Side wheels 2-in-1 dustbin and water tank Charging pins Dustbin release button 2-in-1 dustbin and water tank For more details, please visit www.iliferobot.com... -
Page 10: Self-Empty Station
English Product Composition Self-empty station Cover Dust bag Signal light Infrared sensor Charging pins Dust collecting Solid on - Robot vacuum fully charged Green Breathing - Self-emptying station powered on Flashing - Dust bag not installed Power indicator light Flashing - Self-emptying station starting to collect dust Orange Breathing - Charging in progress Sleep mode... -
Page 11: 2-In-1 Dustbin And Water Tank
English Product Composition 2-in-1 dustbin and water tank Primary filter High-efficiency filter Water tank plasticplug Dustbin button Dust ports Mopping support Mop cloth Note: When the water tank is filled with water, the robot's ability to overcome obstacles and climb hills may be affected. Remote Control Auto charge button Start/Pause... - Page 12 English Product Composition Clean/Pause button Press the button to switch the robot from sleep mode to idle mode. Press the button when in idle mode to start cleaning. Press the button to Pause the robot during its operation. Direction buttons A.
-
Page 13: Product Specifications
English Product specifications Main unit Overall dimension 315x315x93mm Net weight 2.4kg Battery type Li-ion Rated voltage 14.4V Rated power Charging time <300mins Capacity of dustbin 0.2L Capacity of water tank 0.2L Self-empty station Overall dimension 285x145x253mm Net weight 2.0kg Rated Input 220-240V~50/60Hz Rated Output 0.6A... -
Page 14: Product Operating
English Product Operation Attentions The robot may skip over some areas due to the complexity of the home environment. To achieve the best result, we suggest using it as daily routine and clearing up the obstructions on the floor before starting the robot. Please move away the power cords Please fold up the edges of the and other objects that may tangle... - Page 15 English Product Operation Attentions Please do not stand at somewhere Please do not stand by downstairs with narrow space like the door sill when the robot is working upstairs or hallway in case of blocking the in case of getting injured by any robot and skipping over some areas.
-
Page 16: Quick Guide
English Product Operation Quick guide Self-emptying station installation Place the self-emptying station on a hard surface against the wall, plug in the power cord, and turn on the power. Ensure there are no obstacles within approximately 1.5 meters in front of and 0.5 meters above the self-emptying station's infrared signal range. -
Page 17: Robot Charging
English Product Operation Robot charging 1. Place the robot unit on the self-emptying station, aligning it with the charging electrodes. 2. During charging, the AUTO button will breathe orange; after charging is complete, all lights will turn off. 3. Charge for 6 hours for the first time. Reminder: 1. -
Page 18: Start Cleaning
English Product Operation Start cleaning After waking up the robot, you can press the AUTO button once, and the robot will start the automatic cleaning. Before starting cleaning, you need to make sure the indicator light is flashing and the robot is in a wake-up state. If the robot is sleeping, please press the AUTO button once to wake up the robot. - Page 19 English Product Operation Pause When the robot is working, you can pause the robot by pressing the robot‘s AUTO button or the “standby” button in the App. Reminder: 1. The Robot will automatically enter the Sleep Mode if no action is taken for 10 minutes.
-
Page 20: Select Cleaning Modes
English Product Operation Select cleaning modes This product can set a variety of cleaning modes through the App to adapt to different ground conditions and achieve deep cleaning. Auto charge The robot can sense lower power during the cleaning process and automatically activate Self-charge Mode and search for the charging dock. -
Page 21: Water Tank Operation
English Product Operation Water tank operation The water tank with a mopping cloth is installed into the device. Please kindly add water to the water tank before mopping. It is recommended to vacuum the floor before mopping. For daily maintenance, please check out the tips on the corresponding chapter in this manual. Note: 1. - Page 22 English Product Operation Place the mopping support Paste a mopping support. Install water tank components Slide it forward, align it with the clip, and when you hear a "click" sound, it is installed in place, and then you can press the sweep button to automatically execute the corresponding mopping mode.
-
Page 27: Maintenance
English Maintenance Clean up dustbin and filters Please turn off the robot before cleaning any spare parts, and remember to cut off the power. 1. Open the cover, take out the dustbin and high-performance filter, and press the button on the dustbin to release all dust, then wipe clean the dustbin. -
Page 28: Cleaning Of Water Tank Components
English Maintenance Cleaning of water tank components Clean the mop cloth Remove: after mopping, please remove Maintenance: rinse and air dry the the water tank components and the mop cloth. mop cloth. Clean the water tank Remove: after mopping, remove the Maintenance: dry the water tank by mop cloth and the components, drain hand and then air dry it. -
Page 29: Replacing The Dust Bag
English Maintenance Replacing the dust bag Open the top cover of the dust charging base, remove the dust bag, dispose of it in the trash, take out a new dust bag, check for any damage, place it in the dust bag slot, and cover it with the lid. Open the top cover of Remove the dust bag Replace with a new... -
Page 30: Clean Up The Side Brushes
English Maintenance Clean up the side brushes • Remove side brushes. Wipe clean with a clean cloth. • When replacing the side brush, please distinguish the corresponding installation position of the "L" "R" side brush. Check side wheels When a buzzer sounds, turn off the power, and then clear any objects blocking the side wheels. - Page 31 English Maintenance Periodically wipe the sensor with a dry cloth to keep it clean. Clean the charging pins on the robot and the charging dock regularly with dry cloth. When the battery is in the depth of discharge state or not in use for a long time, its capacity will be reduced.
-
Page 32: Troubleshooting
English Troubleshooting Alert Reference In case of errors, red light stays on with voice annoucement. Voice announcement Possible causes What to do Please check the Remove and clean the Side brush error. side brushes side brushes. Check and clean left Please check left wheel.
