Summary of Contents for Ilife A4
- Page 1 Robotic Vacuum Cleaner User Manual...
-
Page 2: Table Of Contents
Table of Contents Safety Instructions ..............1 Product Parts ................2 ............... 2 Main body and accessories ................3 Robot anatomy ..........4 Charging home base and display panel ................5 Remote control Product Operating ..............6 ................6 How to get started .............. -
Page 3: Safety Instructions
Safety Instructions Before using this product, please read the following safety instructions and follow all normal safety precautions. Read this user manual thoroughly and carefully before using this product. Save this user manual. Any operations that oppose to descriptions in this user manual may lead to harm to human or this product. -
Page 4: Product Parts
Product Parts Main body and accessories Description Q'ty Main Body Charging Home Base Remote Control(battery not included) Adapter Cleaning Tool User Manual Extra Side Brushes Extra HEPA Filter CLEAN... -
Page 5: Robot Anatomy
Product Parts Robot anatomy Bumper Clean Button Dust Bin Power Switch Dust Bin Switch Cliff Sensors Nose Wheel Charging Pin Left Brush Right Brush Battery Lid Right Wheel Left Wheel Main Brush Dust Bin Primary Filter Sponge HEPA Filter Dust Bin Cover Dust Bin... -
Page 6: Charging Home Base And Display Panel
Product Parts Charging home base Signal Light Top Cover Power Supply Socket Charge Connecting Points CLEAN button status Robot status Lights Status Charging Orange light flash Charging finished Green light turn solid In selected mode Green light flash When robot in error Red light flash Low battery Orange light flash... -
Page 7: Remote Control
Product Parts Remote control 1. “ ” Clean Press this button to start cleaning in selected mode Press this button to make the robot stop when it’s cleaning. Press this button to exchange from sleeping mode to selected mode. 2. Directional Buttons A. -
Page 8: Product Operating
Product Operating 1. How to get started 1>. Place charging home base, plug in adapter, signal light on charging home base will flash. Note: Put charging home base against the wall and remove obstacles about 1 meter at two sides and about 2 meters forward. 1>... -
Page 9: Starting Up/Pause/Sleeping
Product Operating 2. Starting up/Pause/Sleeping Sleeping mode: Robot is not working, light around main button are off and power switch is on; Selected mode: Robot is not working, greenlight around main button flash; Cleaning mode: Robot is working, green light around main button turn solid. 1>. -
Page 10: Cleaning Mode
Product Operating 4. Cleaning mode 1>. Auto cleaning The robot will clean a room automatically and adjust its cleaning according to the situation. Note: Press button on robot or button on remote control to start auto cleaning. 2>. Spot cleaning Put the robot near a dirty area and press SPOT on remote control to start spot cleaning. -
Page 11: Product Maintaining
Product Maintaining 1. Cleaning side brushes Clean the side brushes when it gets dirty and replace if it’s damaged. Note: Before replacing side brushes, check and match “L” “R” mark on both side brush and bottom of robot. 2. Cleaning dust bin and filter Clean and empty dust bin after each use, steps are as shown in below figures. -
Page 12: Troubleshooting
Troubleshooting 1. Error sheet When the robot meets with some routine troubles, it will remind you by beep. Short tone Tone Cause Solution Wheels no work Check wheels Clean cliff sensor and shake bumper slightly, Cliff sensor or bumper check whether there is sensor failure foreign matter Move main body and... -
Page 13: Product Specifications
Product Specifications Classification Item Detail Diameter 310mm Mechanical Height 76mm Specifications Weight 2.25kg Voltage 14.8V Electrical Specifications Battery specifications Lithium ion 2600mAH 0.45 L Dust bin capacity Auto Charging / Charging type Manual Charging Auto, Spot, Edge, Cleaning mode Cleaning Daily Schedule Specifications 300 min...
