Summary of Contents for Ilife W90
- Page 1 User Manual Cordless Wet & Dry Vacuum Cleaner English For more details, please Español visit www.iliferobot.com...
- Page 3 Dear Customer, Thank you for purchasing ILIFE W90 Cordless Wet & Dry Vacuum Cleaner! You've joined the millions of people who clean with robots-the smarter way to get it done. Please take a few moments to read this manual and get acquainted with your robot, to get the best performance from your robot.
-
Page 4: Table Of Contents
Contents 1. Important Safety Instruction ............1 2. Product Introduction ................4 2.1 Main Body ......................4 2.2 Charging Base ....................5 2.3 Accessories ......................5 2.4 Status Display ....................5 3. Product Assembly ..................7 3.1 Handle Installation ..................7 3.2 Removal of Handle ..................7 4. Product Use ....................8 4.1 Add clean water to the clean water tank ..........8 4.2 Floor Washing ....................9... -
Page 5: Important Safety Instruction
Important Safety Instruction Safety Warnings 1. Product disassembly is strictly prohibited; 2. Before cleaning or maintaining the Product, please unplug the power adapter and turn off the power source; 3. To prevent potential electric shock risk, plz don’t touch plug, power adapter or machine monitor when your hand is attached with water ;... - Page 6 Important Safety Instruction 17. Do not use the Product to clean flammable, explosive or highly volatile liquids, such as gasoline, kerosene, paint and perfume, which may cause short circuit or explosion of the Product; 18. Do not use the Product to clean the toner or color blender used in the laser printer and copier to avoid fire or explosio;...
- Page 7 Important Safety Instruction To avoid electrocution, please do not press on the power cord while using the machine. Make sure any parts of the body or large objects such as clothes, etc. is far away from the roller. For more details, please visit www.iliferobot.com...
-
Page 8: Product Introduction
Product Introduction Main Body Switch Shift Sprinkler Self-cleaning Handle Handle Puller Clean Water Release Clean Water Tank Display Light Waste Water Release Waste Water Tank Build-in Battery Front Cover Release Front Cover Charger Roller For more details, please visit www.iliferobot.com... -
Page 9: Charging Base
Product Introduction Charging Base Charger Pin Power Port Accessories Power Adapter User Manual Sponge Filter Screen Status Display Solid – Fully Charged Automatic Green Powerful Mode Q>40% Solid – 10%<Q<40% Breathing – Charging Orange Solid – Low Battery Flashing – Abnormity warning For more details, please visit www.iliferobot.com... - Page 10 Product Introduction Status Display Status of Main Body Status of Display Light Low Battery Red Light On Fully Charged Green Light On It beeps, and the red light goes out after Battery Over-Heating being on for 5 seconds. It beeps, and the red light goes out after Short-circuit Protection flashing for 5 seconds.
-
Page 11: Product Assembly
Product Assembly Handle Installation As shown in Figure 3-1, insert the handle into the corresponding top position of the main part, which includes buckles for positioning. You will hear a "click" after inserting. The completion of assembly is shown in Figure 3-2. Removal of Handle Poke a dull auxiliary tool (such as a bamboo stick) into the small hole as shown in the figure up to the handle puller button, then pull the handle... -
Page 12: Product Use
Product Use Add clean water to the clean water tank Open the soft rubber cover: lift and turn clockwise Add clean water, but do not exceed the MAX line. Press the button to Put the clean water tank back onto the take out the clean water tank. -
Page 13: Floor Washing
Product Use Floor Washing Switch Shift Sprinkler Press the switch button. The power is on with the default setting to start the automatic mode. Press the switch button again to stop the machine; When the machine is running, press the shift button to switch between the "automatic/powerful"... -
Page 14: Charge
Product Use Charge Connect the power adapter to the Put the whole machine into charging base, as shown in the the charging base, figure and insert it into the power as shown in the figure. stripe. Insert direction At this point, the display light on the main part turns orange, and the machine enters the charging stat e. -
Page 15: Regular Cleaning Of Products
Regular Cleaning of Products Clean-up of Waste Water Tank Press down the water tank button Take out the lid of the waste water and take out the tank. tank. Pour the wastewater Take out the filter holder. Install the water tank's lid, and put Take out the solid waste the wastewater tank back onto the machine. -
Page 16: Removal And Clean-Up Of The Sponge Filter Of The Waste Water Tank
Regular Cleaning of Products Removal and clean-up of the sponge filter of the waste water tank Take out the sponge filter assembly Open the lid of the holder. from the lid of the Waste Water Tank. Take out the sponge filter, and wash After washing the sponge filter, dry it, the sponge filter and the holder put it back onto the holder assembly,... -
Page 17: Clean-Up Of The Roller
Regular Cleaning of Products Clean-up of the Roller Pull up the roller handle to remove Pull the front cover button and take out the front cover. the roller. Wash the roller by hand. Open the side cover of the roller to remove tangled hair. -
Page 18: Technical Specification
Technical Specification ILIFE Cordless Wet & Dry Vacuum Cleaner Product: Model: Net Weight: 4.3kg 7.5kg Gross Weight: Waste Water Tank Capacity: 500ml Clean Water Tank Capacity: 700ml 255(L)*280(W)*1193(H)mm Product Size: Outside Box Size: 870(L)*183(W)*328(H)mm Rated Voltage: DC 22.2V 150W Rated Power:... -
Page 19: Troubleshooting
Troubleshooting When the Wet & dry vacuum cleaner does not work properly, please refer to the following information to handle the situation Abnormal Situations Reasons and Solutions 1. The battery is low. Please use it after charging. 2. The air channel and the roller get blocked. The machine does Please clean up the foreign objects in time and not work...
