Related Manuals for Ilife ILIFE-V20
Summary of Contents for Ilife ILIFE-V20
- Page 1 ILIFE-V20 Robotic vacuum cleaner User Manual For more details, please visit www.iliferobot.com...
- Page 3 English Dear Customer, Thank you for purchasing ILIFE V20 robotic vacuum cleaner! You've joined the millions of people who clean with robots - the smarter way to get it done. Please take a few moments to read this manual and get acquainted with your robot, to get the best performance from your robot.
-
Page 4: Table Of Contents
English Table of Contents Safety Instruction .......................3 Product Composition ......................5 List of accessories ..........................5 Host introduction ..........................6 Sensor and structure ........................6 Charging dock ..........................7 Remote control ..........................7 Product Operation ......................9 Precautions ............................9 Charging ............................10 Power on/off ...........................11 Sweep/Pause ..........................11 Charge ..............................11 Automatic sweeping ........................12 App Download ........................13... -
Page 5: Safety Instruction
English Safety Instruction Warnings 1. This robot should not be used by children under 8 years old or people with mentally challenged, unless they are under supervision. Do not let children sit on the robot or use it as a toy. 2. - Page 6 English Safety Instruction 16. Do not lift up the robot or the charging dock by the power cord, and keep the power cords away from heat and avoid it being trapped around doors, sharp edges or corners. 17. Damaged power cords must be repaired by manufacturer’s repair service or certified technicians.
-
Page 7: Product Composition
English Product Composition List of accessories Main Body Charging Dock 2-in-1 Dustbin and Water Tank Duster Component Mop Cloth Remote Control Cleaning Tool Extra Side Brush User Manual Power Adapter Filter For more details, please visit www.iliferobot.com... -
Page 8: Host Introduction
English Product Composition Host introduction Point laser sensors Power on/off/clean/pause Short press to start cleaning/pausing ● Long press 3 seconds to power on/off ● Recharge/pause Short press to recharge/pause ● Light White light: Normal operation/recharging ● Red light: Abnormal status ●... -
Page 9: Charging Dock
English Product Composition Face cover Bumper Charging pins Pull-back dustbin Charging dock Charging pins Signal transmitting area Cable slot Remote Control Auto charge button Start/Pause Direction Adjustable suction Path mode Edge mode Spot mode For more details, please visit www.iliferobot.com... - Page 10 English Product Composition Clean/Pause button Press the button to switch the robot from sleep mode to idle mode. Press the button when in idle mode to start cleaning. Press the button to Pause the robot during its operation. Direction buttons A.
-
Page 11: Product Operation
English Product Operation Precautions Before starting the vacuum cleaner, clean up wires and sundries scattered on the ground, and remove easy-to-fall, fragile, valuable and potentially dangerous items. Avoid being entangled, stuck, dragged or knocked down by the main unit; otherwise, personal injury or property damage may be caused. When used in a suspended circumstance, it shall be protected by rails to avoid accidental falling or pushing other articles from falling;... -
Page 12: Charging
English Product Operation Charging 1.Connect the power cord, Place the charging dock against a and collect the redundant cable. wall, and connect the power supply. Please ensure a space of at least Wrap the excess wire around the 0.5m on both the left and right sides spool and plug it in. -
Page 13: Power On/Off
English Product Operation Power on/off Press “ ” and hold the button for 3 seconds, the indicator light will light up, and the power on will be successful. When the machine is standby, press “ ” and hold the button for 3 seconds, the indicator light will be off, and the machine will be turned off. -
Page 14: Automatic Sweeping
English Product Operation Automatic sweeping After starting, the machine will first plan the cleaning path along the edge, and then plan the cleaning path in the way of bow-shaped filling, and clean the whole house in an orderly and eficient manner, and the device will automatically return to the charging dock for charging after the cleaning is completed (the default cleaning mode of the machine). -
Page 19: Routine Maintenance
English Routine Maintenance Main brush (weekly cleaning recommended) Flip the machine and hold down the Remove the main brush. buckle on the main brush cover and take out the main brush. Use the matching cleaning brush to sweep away the dust in the main brush and the main brush cavity, and then clean up the tangles on the main brush. -
Page 20: Dustbin And Filters
English Routine Maintenance Dustbin and filters (recommended after each cleaning) From the back of the machine, Press and hold the dustbin switch press and hold and take out the to open the dustbin and dump the dustbin. garbage. Clean the dustbin (it is recommended to clean it once a week) 1. -
Page 21: Water Tank Use
English Routine Maintenance Water tank use Do not use the mopping function on the carpet, after mopping the floor, please empty the water tank and remove the rag in time. Add water Install the tank assembly Install the rag Start mopping For more details, please visit www.iliferobot.com... -
Page 22: Other Spare Parts
English Routine Maintenance Other spare parts Cleaning spot laser detection sensor Clean the main unit charging (monthly cleaning recommended) contacts (it is recommended to clean them once a month) Cleanup cliff sensor Clean the charging contacts of (monthly cleaning is recommended) the charging dock (it is recommended to clean them once a month) -
Page 23: Maintenance Of The Battery
English Routine Maintenance Clean the signal emission area of the charging dock (it is recommended to clean it once a month) Maintenance of the battery 1. The device has a built-in rechargeable lithium battery pack, in order to maintain the battery performance, please keep the host in a charged state for daily use, which is conducive to the best performance of the battery and does not consume excessive power. -
Page 24: Normal Questions
English Normal questions The type of question Resolution If the battery is low, place the device on the charging dock, align it with the contact point, and the device will automatically power on. If the ambient temperature is lower than 0°C, Crashed/Won't turn on please use it in an environment of 0~40°C. -
Page 25: Product Specification
English Product Specification Main unit Product model Dimensions 330 x 330 x 83mm Battery Li-ion Rated voltage 14.4V Rated power Charging time Capacity of 2 in 1 water tank & dustbin 300ml + 250ml Charging dock Dimensions 149.5 x 52 x 100mm Rated inputs 0.6A Rated outputs...
