Summary of Contents for Fortinet FortiCam FD51
- Page 1 FortiCam FD51 QuickStart Guide...
- Page 2 Nothing herein represents any binding commitment by Fortinet, and Fortinet disclaims all warranties, whether express or implied, except to the extent Fortinet enters a binding written contract, signed by Fortinet’s SVP Legal and above, with a purchaser that expressly warrants that the identified product will perform according to certain expressly- identified performance metrics and, in such event, only the specific performance metrics expressly identified in such binding written contract shall be binding on Fortinet.
-
Page 3: Table Of Contents
Table of Contents Package Contents Hardware Installation Status LEDs Buttons Camera Connection Technical Specifications Register for Support and Cloud Access Cautions and Warnings Regulatory Notices... -
Page 4: Package Contents
Package Contents • FortiCam camera • 4 Mounting screws (M4 x 25 mm) • 4 Wall anchors (7 x 26 mm) • 2 2-pin terminal blocks • Star (T10 Torx) key wrench • Waterproof connection kit • Side lid • Screw (M4 x 6 mm) for the ground wire •... -
Page 5: Hardware Installation
Hardware Installation Caution: Only remove the protective wrap from the lens once installation is complete to avoid damage and scratches. Before installation, store the camera in a dry, well ventilated place. Hire qualified technicians to carry out maintenance and repairs. Disconnect power from the unit when performing maintenance. - Page 6 To install the camera Before installing cameras, carefully design your system. Verify coverage of each camera. Decide whether to run cables through the wall/ceiling (drilling required) or along it, through the notch on the base. Choose a location that is not easily accessible, away from impacts and heavy vibrations.
- Page 7 Loosen the T10 anti-tamper screws and dome cover. Do not touch the electronics. Page 4...
- Page 8 4. Pull the cables through the mounting hole. Assemble the waterproof connection kit around the Ethernet cable. Connect the Ethernet cable to the camera’s RJ-45 connector. If you use 12 V DC power, wrap the cable connections with electrical tape to make a waterproof seal. Page 5...
- Page 9 Page 6...
- Page 10 Attach the ground wire to the included screw. Page 7...
- Page 11 Mount the camera to the wall or ceiling. Either run the cables directly into the mounting hole, or through an opening at the side of the camera base by removing the side lid. Page 8...
- Page 12 Allow slack in the cable so that any condensation drips away from the waterproof seal, not towards it. Adjust pan, tilt, and lens rotation to get the best field of view. Page 9...
- Page 13 Replace the desiccant inside of the dome cover. Verify that there is no moisture trapped inside of the dome cover. Page 10...
- Page 14 Gently wipe the inside of the dome cover with a clean, lint-free cloth to remove all dust and particles. Install the dome cover. Remove protective wrap from the dome cover. Page 11...
-
Page 15: Status Leds
Status LEDs Note: Status LEDs can be disabled through software. Operation Red solid/green flashing Power on/Network OK Red only Power on/Network failure Red fast flashing/green slow flashing Firmware updating Red fast flashing/green fast flashing Factory reset Bootup Sequence Red/green flashing once Bootup beginning Red solid System booting... -
Page 16: Buttons
Buttons Reset Button Operation Press Time Action < 5 seconds No change in color Reboot > 10 Red/green flashing Factory reset seconds Note: The default IP address of the camera is 192.168.1.245. Page 13... -
Page 17: Camera Connection
Camera Connection Caution: This device complies with IEEE 802.3af PoE specification. Do not use any PoE injectors that are not IEEE 802.3af compliant as they may damage your device. Attention: Cet appareil est conforme à la spécification PoE IEEE 802.3af. N’utilisez pas d’injecteurs PoE non conformes à la norme IEEE 802.3af car ils pourraient endommager votre appareil. - Page 18 To use FortiRecorder to connect the camera Connect the Ethernet port of the camera to the FortiRecorder NVR via a PoE switch. The camera automatically gets its IP address from the DHCP server on FortiRecorder. Else the default IP address of the camera is 192.168.1.245.
-
Page 19: Technical Specifications
Technical Specifications Camera Format Fixed dome, day/night, in/outdoor, vandal Sensor Type 5 Mp, 1/2.7” progressive CMOS Iris F1.6, fixed Focal Length f=2.8mm, fixed Rotation Pan = 350°, Tilt = 80°, Rotation = 350° View Angle H:111°/V:59°/D:133° Minimum Illumination 0.055 Lux (color 30 IRE) @ F1.6 <0.005 Lux (B/W 30 IRE) @ F1.6 0 Lux (BW 30 IRE) @ F1.6 DOL WDR (>120 dB) - Page 20 Camera Video Compression MJPEG/H.264/H.265(HEVC) Audio G.711, line in, line out, 3.5 mm stereo jack x 2 Alarm DI x 1, DO x 1 Image Resolution WDR off: 5 Mp at 30 fps/2 Mp at 20 fps/720p at 20 fps WDR on: 5 Mp at 20 fps/2 Mp at 20 fps/720p at 20 fps Mounting Wall, ceiling, 3-axis, accessories...
- Page 21 Compliance FCC Class A, ICES, CE, IP66, IK10, ONVIF Profile S, G, T Page 18...
-
Page 22: Register For Support And Cloud Access
Register for Support and Cloud Access Register your Fortinet product to receive: • Technical support • New product features • Protection from new threats Vous devez enregistrer le produit pour recevoir: • Support technique • Nouvelles fonctionnalitées du produit • Protection contre de nouvelles... -
Page 23: Cautions And Warnings
Cautions and Warnings Environmental Specifications Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature, Storage Temperature, Humidity, and Altitude). Référez à la Fiche Technique de ce produit pour les caractéristiques environnementales (Température de fonctionnement, température de stockage, humidité et l’altitude). Safety Caution: This equipment is to be used in a Network Environment 0 per IECTR 62101. - Page 24 Leaving a battery in an extremely hot environment can result in leakage of flammable liquid, gas, or an explosion. If a battery is subjected to extremely low air pressure, it may result in leakage of flammable liquid, gas, or an explosion. WARNUNG: Lithium-Batterie Achtung: Explosionsgefahr bei fehlerhafter Batteriewechsel.
-
Page 25: Regulatory Notices
Regulatory Notices Federal Communication Commission (FCC) – USA This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
