  • Page 1 QuickStart Guide FortiCam FB85-CA...
  • Page 2 The Essentials Register for Updates & FortiCloud Access Register your Fortinet product to receive: • Technical support • New product features • Protection from new threats Vous devez enregistrer le produit pour recevoir: • Support technique • Nouvelles fonctionnalitées du produit • Protection contre de nouvelles...
  • Page 3 Fortinet Document Library Get deployment examples, administrator guides, and reference manuals: https://docs.fortinet.com Documentation feedback: techdocs@fortinet.com...
  • Page 4: Package Contents

    Package Contents • FortiCam camera • 4 Mounting screws (P4 x 38 mm) • 4 Wall anchors (7 x 26 mm) • Hex key (Allen wrench) • Waterproofing shell for Ethernet (RJ45) connection • Sun shield • 2 Sun shield screws (round head hex M6 1 x 10 mm) •...
  • Page 5: Camera Setup

    Camera Setup Caution: This device complies with IEEE 802.3at PoE specification. Do not use any PoE injectors that are not IEEE 802.3at compliant as they may damage your device. Attention: Cet appareil est conforme à la spécification PoE IEEE 802.3at. N’utilisez pas d’injecteurs PoE non conformes à la norme IEEE 802.3at car ils pourraient endommager votre appareil.
  • Page 6 To use FortiCamera Cloud to connect the camera To connect via FortiRecorder instead, see “To use FortiRecorder to connect the camera” on page Connect the Ethernet port of the camera to a PoE switch or PoE injector. The camera automatically gets its IP address from the DHCP server.
  • Page 7 4. Once the camera connects to the cloud and is claimed, its firmware will be updated automatically. This may take several minutes and multiple reboots. Do not power off the camera during this process. For connection troubleshooting, see FortiCamera Cloud Portal Guide.
  • Page 8: Hardware Installation

    Hardware Installation Caution: Only remove the protective wrap from the lens once installation is complete to avoid damage and scratches. Before installation, store the camera in a dry, well ventilated place. Hire qualified technicians to carry out maintenance and repairs. Disconnect power from the unit when performing maintenance.
  • Page 9 To install the camera Before installing cameras, carefully design your system. Verify coverage of each camera. Camera locations should not be easily accessible, away from impacts and heavy vibrations. Run cables through the wall/ceiling (drilling required). Avoid exposure to direct sunlight in outdoor locations for better image quality and longer service life.
  • Page 10 If installing the camera in a humid environment where there is risk of condensation, you can refresh the dry pack. Open the chassis. Do not touch the electronics. Replace the desiccant inside of the chassis. Verify that there is no moisture trapped inside of the chassis.
  • Page 12 Use the screws to attach the sun shield to the chassis.
  • Page 13 4. Put the drill template sticker on the wall/ceiling. Drill the mounting holes.
  • Page 14 Pull the cables through the mounting hole. Allow slack in the cable so that any condensation will drip away from the waterproof seal, not towards it.
  • Page 15 Plug in any required pigtail cables except for the power supply. (Do not connect the power supply until the ground wire is connected, as shown in the next step.)
  • Page 16 Connect the ground wire to an earthing rod or bar. For other connections, wrap them with putty or electrical tape to make a waterproof seal.
  • Page 17 Assemble the waterproof shell around the Ethernet cable. Connect the Ethernet cable to the camera’s RJ-45 connector.
  • Page 18 Mount the camera to the wall or ceiling. Caulk around the mount to waterproof it.
  • Page 19 10. Adjust pan, tilt, and lens rotation to get the best field of view.
  • Page 20: Status Leds

    Status LEDs Note: Status LEDs can be disabled through the software. Operation Green/Red Firmware updating (flashing) Bootup Sequence Red (solid) Hardware initialization ~15 seconds Green Network OK (flashes once) Ready (flashes twice)
  • Page 21 Buttons Reset Button Operation Action Press Time < 5 1. Off ~10 seconds Reboot seconds 2. Bootup sequence > 10 1. Off ~10 seconds Factory reset seconds 2. Solid ~15 seconds Note: The default IP address of the camera 3. Off ~40 seconds is 192.168.1.245.
  • Page 22: Technical Specifications

    Technical Specifications Camera Format Full bullet, day/night, in/outdoor, vandal Sensor Type 8 MP (4K), 1/2.8” progressive CMOS Iris F1.6(W), F2.9(T), P-iris Focal Length f=2.8-12 mm Rotation Pan = 350°, Tilt = 90°, Rotation = 180° View Angle H:116.4°~35.4°/V:59.6°~19.9°/D:145.2°~40.7° Minimum Illumination 0.085 Lux (color) @ F1.6 <0.005 Lux (B/W) @ F1.6 DOL HDR (>120 dB)
  • Page 23 Camera Audio Half duplex, line in, line out, cable Alarm DI x 2, DO x 2, cable Image Resolution 4K at 30 fps + 1080p at 30 fps 4K at 30 fps + 720p at 30 fps + 480p at 30 fps Mounting Wall, ceiling, accessories...
  • Page 24 Humidity <90% non-condensing Compliance FCC Class A, ISED, CE, IP66, IK10, ONVIF Profile S, G, T...
  • Page 25: Cautions And Warnings

    Cautions and Warnings Environmental Specifications Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature, Storage Temperature, Humidity, and Altitude). Référez à la Fiche Technique de ce produit pour les caractéristiques environnementales (Température de fonctionnement, température de stockage, humidité et l’altitude). Safety Caution: This equipment is to be used in a Network Environment 0 per IECTR 62101.
  • Page 26: Regulatory Notices

    Regulatory Notices Federal Communication Commission (FCC) – USA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 28 Copyright © 2025 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet, Inc., and other Fortinet names herein may also be registered and/ or common law trademarks of Fortinet. All other product or company names may be trademarks of their respective owners.
