DO NOT
HANDHELD
THIS TOOL
USE MANUAL and SPARE PARTS
IMPORTANT DO NOT DESTROY !
Read carefully this manual before using the tool and
respect the security norms herewith enclosed.
Via Foresto 42 - 31058 SUSEGANA TV ITALY
®
3G.16 ROA1
1144350ROA1_3G16ROA1_6_rev21 26/06/2024 DV
Tel.0438455318 Fax 0438455530
cod. 1144350ROA1
E-mail: omer@omer.it
www.omer.it
MADE
IN
ITALY
Advertisement
Table of Contents
Related Manuals for Omer 3G.16 ROA1
Summary of Contents for Omer 3G.16 ROA1
- Page 1 ® 3G.16 ROA1 cod. 1144350ROA1 DO NOT MADE HANDHELD ITALY THIS TOOL USE MANUAL and SPARE PARTS IMPORTANT DO NOT DESTROY ! Read carefully this manual before using the tool and respect the security norms herewith enclosed. 1144350ROA1_3G16ROA1_6_rev21 26/06/2024 DV Via Foresto 42 - 31058 SUSEGANA TV ITALY Tel.0438455318 Fax 0438455530...
-
Page 2: Technical Data
Technical data Suitable staple series : 0,55x0,75 1/4" 5/8" Crown: .350” (3/8") Thickness: .022" Width: .030" Gauge: 6÷16 Usable lenghts mm 1/4"÷5/8" Usable lengths inch Magazine capacity No. of fasteners 5,5÷6,5 Working pressure bar Working pressure psi 80÷95 0,58 Air consumption litres/shot 0,0204 Air consumption ft /shot 3,94... -
Page 3: Conformity Declaration
INTRODUCTION In order to assure top working reliability, OMER has made a careful choice of the materials and components to be used in the manufacture of the tool and has tested it before delivery. Proper performance of the tacker in time also depends on its correct use and on adequate servicing according to the instructions contained in this manual. - Page 4 OMER spa does not answer for damage to the gun due to the use of staples or...
- Page 5 To do so, unscrew the head screws with the hex spanner supplied, open the gun and remove the different components. Check carefully the state of wear of the O-rings and of the rubber parts. Replace the worn parts with OMER original spare parts.
- Page 6 INTRODUCTION In order to assure high reliability, OMER has made a careful choice of the materials and components to be used in the manufacturing process of the tool and has tested it before delivery. Proper performance of the tacker in time also depends on its correct use and on adequate servicing according to the instructions contained in this manual.
- Page 7 OMER spa does not answer for damage to the gun due to the use of staples or...
- Page 8 To do so, unscrew the head screws with the hex spanner supplied, open the gun and remove the different components. Check carefully the state of wear of the O-rings and of the rubber parts. Replace the worn parts with OMER original spare parts.
- Page 9 Loading 1 - Pull the pusher all the way back and lock it 2 - Load staples 3 - Release the slider...
-
Page 10: Jam-Clearing
Jam-clearing In case of jamming, proceed as follows: 1 - Pull the pusher all the way back and lock it. 2 - Remove the staples from the magazine. 3 - Open the slider closing trigger. 4 - Pull the slider all the way back by acting on the pusher and holding it in such a position. 5 - Pull the jammed staple out from the firing channel. -
Page 11: Spare Parts
04.20 08.16.6Z 3G.16 ROC-C1 c o d . 1 1 4 4 3 5 0 R O C - C 1 3G.16 ROA1 Upgrade c o d . 1 1 4 4 3 5 0 R O A 1 Number... -
Page 12: Spare Parts List
Racc. “L” 6 - G1/4 Conn. “Elbow” 6 - G1/4 91.05.43 Testina Nose plate 18.02 Cilindro Pneumatico Pneumatic Cylinder Boccetta olio Oiler 3G.16 ROA1 Upgrade c o d . 1 1 4 4 3 5 0 R O A 1 Number... - Page 13 Accessories 07.50 07.40 07.30 07.25 O-Ring 01.21.3 00.27 01.21.1 28.00 00.70.5 00.35 01.33 01.29 00.26 01.10 00.14 00.12 00.13 00.06 00.04 3G.16 ROA1 Upgrade c o d . 1 1 4 4 3 5 0 R O A 1 Number...
- Page 14 Notes...
