PP-9000
THERMAL PRINTER
USER'S MANUAL
Rev.: B0
FCC NOTES
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement résidentiel, cet
équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than the
authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
LIMITES DE GARANTIE
La garantie prend fin automatiquement lorsque la machine est ouverte par une personne autre que
les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le problème qui se produit.
La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise.
Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé par une mauvaise
application.
警告使用者
為避免電磁干擾,本產品不應安裝或使用於住宅環境。
SAFETY INSTRUCTIONS
This equipment is not suitable for use in locations where children are likely to be present.
CONSIGNES DE SÉ CURITÉ
Cet équipement ne convient pas à une utilisation dans des endroits où des enfants sont susceptibles
d'être presents.
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP-9000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for POSIFLEX PP-9000

  • Page 1 PP-9000 THERMAL PRINTER USER’S MANUAL Rev.: B0 FCC NOTES This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 2 WARNING Power cord shall be connected to a socket-outlet with earthing connection. ATTENTION Le cordon d'alimentation doit être connecté à une prise de courant avec mise à la terre. CAUTION Please pull the center of cover release in order to open the cover correctly.
  • Page 3: Product Briefing

    GETTING START PRODUCT BRIEFING Posiflex Aura-9000 series is a super fast speed, easy loading, low noise, high reliability, and trustworthy thermal printer. The printing speed of Aura-9000 series is able to reach 300 mm/sec for text and graphic mode. This series printer has been elegantly design for Point-Of-Sale, kitchen &...
  • Page 4: Product Pictures

    1). An Aura-9000 printer. 2). One tests thermal paper roll 80 mm wide. 3). 83/80/58 mm paper spacing plate. 4). One of the interface cables: Serial cable with 9 pin D sub Female to 9 pin D sub Male connectors for Aura-9000S model Parallel cable with 25 pin D sub Male to 25 pin D sub Female connectors for Aura-9000P parallel model No interface cable for Aura-9000L or Aura-9000W...
  • Page 5 Front View Cover Release Paper Exit Power Switch Bottom Cover Bottom View Rubber Foot Setup Window Plate Mounting Hole Window Plate Screw Rubber Foot Rear View (I/O Area for Aura -9000P) (I/O Area for Aura-9000) Parallel Adaptor Parallel Port Fixation Screw CR Port (I/O Area for Aura -9000L) Power Connector...
  • Page 6: Quick Start-Up

    (I/O Area for Aura -9000S) (I/O Area for Aura -9000W) Frame Ground Screw Reset Button Wi-Fi Indictor Serial Port INDICATORS * Power LED: Green. * Error LED: Red (brief lit indicates printer busy). * Paper out LED: Red. QUICK START-UP POWER SWITCH Please open the protect cover as show in the right picture when first time to switch on the printer.
  • Page 7: Connecting Cables

    front end; and leaving the tail of the paper roll coming out of the opening between the hood and the top cover as in Pix. 3. 4. Excessive paper will cut automatically. When to Replace Paper Whenever the printer gives paper out signal or a red line appears on the thermal paper, it is the proper timing for replacing the paper.
  • Page 8 Posiflex cash drawer CR3100 or CR3200 or CR4000 or CR4100 or CR-6310. If a Posiflex special split cable is used instead, this port can control two cash drawers of above models. When the printer is used as a kitchen printer, please use this port for kitchen bell connection instead.
  • Page 9: Special Adjustments

    Power On When all the above cable connections are made correctly, you may connect your power adaptor to the wall outlet. Make sure that the type of power cord to meet the local power conditions. Now the printer is ready for power on. Self Test Press and hold down the feed button while turning on the power switch.
  • Page 10 Match Dents 58 mm Compartment Please pull up the spacing plate which in the most left end and which show in the upper picture. Next, take the plate insert to the noted corners of the spacing plate into the 2 dents inside the paper roll compartment. After fixed the spacing plate and checking the switch setting, this printer can start to use 58mm paper roll.
  • Page 11: Item Description

    INSTALLING DRIVER There will be a Posiflex Product Information CD or DVD or a separate CD of similar nature, which is specifically create for the Aura-9000U, Aura-9000W and Aura-9000L. Please find the appropriate subfolder from the non-specific Posiflex Product Information CD or DVD and please find the information document such as “read me”...
  • Page 12: General Cleaning

    “TCP/IP” with the printer IP address then uses the same Windows printer driver of Aura-9000L. Posiflex Wi-Fi POS Printer Manager for Aura-9000W When set the host system by AD-HOC mode; please set the host system IP in the same network segment with Aura-9000W which in the 192.168.192.XXX.
  • Page 13: Troubleshooting

    sensor gently using a cotton swab moistened with isopropyl alcohol solvent. Before putting back the paper roll for printing, alcohol solvent must be dry completely. NOTE: Never do this when print head is still hot. Do not touch the print head thermal elements and scratch the print head Thermal Elements Paper Sensor...
  • Page 14: Useful Tips

    USEFUL TIPS Please note that only those qualified technicians may adjust several jumpers for some technical settings. Please visit our web site http://www.posiflex.com or http://www.posiflex.com.tw for details of the technical information such as driver installation, DIP switch settings and command sets etc. if required.
  • Page 15: Driver Download

    20º and 65% RH when not installed in the printer. Avoid extended exposure to direct light. Use only products made from polyethylene, polypropylene or polyester for storage of thermal paper. DRIVER DOWNLOAD Please download the relevant driver that you need from the Posiflex website (http://www.posiflex.com/en-global/Download/download). SPECIFICATIONS PRINTER...
  • Page 16: Media Handling

    Paper cutting method Slide cutting Full cut or Partial cut (1.5±0.5mm tab Type of paper cutting left at the center) φ18mm Minimum paper core diameter Minimum paper cutting length 20mm Activation 200 million pulses or more pulse resistance Life Span (at Abrasion 。...
  • Page 17: Further Technical Information

    addition to Parallel port. For Aura-9000S, there are 2 connectors for host connection: USB Port and in addition to the Serial port. For Aura-9000L, there are 2 connectors for host connection: USB and in addition to the LAN port. Please always connect only one interface at a time. Simultaneous multiple host connections could result in unexpected results! UPOS CONCERNS The UPOS compliance and WEPOS compliance ability of the Aura-9000...
  • Page 18 Another method to setup Aura-9000 series is through the software switch setting, which means other functions must be change by software utility. Please visit our web site http://www.posiflex.com or http://www.posiflex.com.tw to download the Aura-9000 software switch utility. Software switches has divided into SW1, SW2, SW3 and SW4.
  • Page 19 Full-cut mode. Partial-cut mode. Cut without paper feed Cut with auto paper feed Busy on “buffer full” Busy on “buffer full” and/or “off line” CR code (0Dh) effective CR code (0Dh) invalid Even parity None parity XON/XOFF handshaking DSR/DTR handshaking Software switch 2-1 controlled the retractable function.
  • Page 20 In Aura-9000, it is selectable between even and none. For switch position 8 can choice the handshaking method in serial interface. When it is set to ON, the printer transmits an “XOFF” for busy and sends an “XON” for not busy. When it is set to OFF, the printer signifies the busy status over hardware signals that can be detected by the host as “DSR”...
  • Page 21 SW4-1 switch controlled the “Beep” sound after printing. Please select “ON” if this beep sound is required and it will not make any sound after “OFF” is selected. Software switch SW4-2&3 is helping user to saving paper by reduce the barcode height to 25%, 50% or 75% of the original size.
