PP-6906 Series
THERMAL PRINTER
USER'S MANUAL
FCC Notes:
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the user's manual, may cause interference
to radio communications. It has been tested and found to comply with limits for a Class A digital
device pursuant to subpart J of Part 15 of FCC Rules, which are designed to provide reasonable
protection against interference when operated in a commercial environment. Operation of this
equipment in a residential area is likely to cause interference which case the user at his/her
expense will be required to take whatever measures to correct the interference.
CE manufacturer's Declaration of Conformity
(EC Council Directive 89/336/EEC of 3 May 1989)
This product has been designed and manufactured in accordance with the International Standards
EN50081-1/01.92 and EN50082-1/01.92 following the provisions of the Electro Magnetic
Compatibility Directive of the European Communities as of May 1989
Warranty Limits:
Warranty terminates automatically when any person other than the authorized technicians opens
the machine. The user should consult his/her dealer for the problem having happened. Warranty
voids if the user does not follow the instructions in application of this merchandise. The
manufacturer is by no means responsible for any damage or hazard caused by improper application.
About This Manual:
Posiflex has made every effort for the accuracy of the content in this manual. However, Posiflex
will assume liability neither for any technical inaccuracies or editorial or other errors or omissions
contained herein, nor for direct, indirect, incidental, consequential or otherwise damages, including
without limitation loss of data or profits, resulting from the furnishing, performance, or use of this
material.
This information is provided "as is" and Posiflex Technology, Inc. expressly disclaims any
warranties, expressed, implied or statutory, including without limitation implied warranties of
merchantability or fitness for particular purpose, good title and against infringement.
The information in this manual contains only essential hardware concerns for general user and is
subject to change without notice. Posiflex reserves the right to alter product designs, layouts or
drivers without notification. The system integrator shall provide applicative notices and
arrangement for special options utilizing this product. The user may find the most up to date
information of the hardware from web sites: http://www.posiflex.com or
http://www.posiflex.com.tw or http://www.posiflexusa.com
A backup of all data should be kept prior to installation of a drive unit or storage peripheral.
Posiflex will not be responsible for any loss of data resulting from the use, disuse or misuse of this
or any other Posiflex product.
All rights are strictly reserved. No part of this documentation may be reproduced, stored in a
retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying,
or otherwise, without prior express written consent from Posiflex Technology, Inc. the publisher of
this documentation.
© Copyright Posiflex Technology, Inc. 2014
All brand and product names and trademarks are the property of their respective holders.
P/N: 19780902010
Rev.: Original
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PP-6906 series and is the answer not in the manual?

Questions and answers

Summary of Contents for POSIFLEX PP-6906 series

  • Page 1 A backup of all data should be kept prior to installation of a drive unit or storage peripheral. Posiflex will not be responsible for any loss of data resulting from the use, disuse or misuse of this or any other Posiflex product.
  • Page 2: Getting Started

    These printers serve the stand-alone desktop application as well as the application within a Posiflex integrated POS system equally perfect. PP-6906 series supports 2 types of interface inputs and is also provided with a USB port. The standard model of PP-6906 is designed with a USB interface, a LAN interface, and a Wi-Fi interface (optional).
  • Page 3 UNPACKING The following items are what you may find when carefully unpacking the carton of the PP-6906 series printer. If there is any discrepancy or problem, contact your dealer immediately. Be sure to save the packing materials in case the printer needs to be shipped at some point in the future.
  • Page 4 Tour of the PP-6906 Top View Paper Cover Top Cover Roll Paper Exit Hood Release Button Power LED Feed Button Paper-Out LED Error LED Front View Bottom Cover Power Button Page 4...
  • Page 5 Bottom View Wall Mount Hanging Hole Rubber Rubber Foot Foot Setup Window Plate Window Plate Screw Rear View LAN Port Cash Drawer Port WIFI LED Indicator Reset Button Ground Terminal USB Port (Type A) Power Connector INDICATORS • Power LED: green •...
  • Page 6: Quick Start-Up

    QUICK START-UP LOADING A PAPER ROLL 1. Press down the hood release button to release the paper cover. 2. Raise the released paper cover manually and drop the thermal paper roll inside the printer as shown in the right figure. 3.
  • Page 7 CONNECTION USB Connection (to Posiflex Pole Display) The USB port of PP-6906 is a host interface to a Posiflex POS display only, such as PD26UE. LAN Connection The LAN connector is an 8-PIN RJ45 type modular connector. Please use a LAN cable of CAT 5 of a proper length to connect the LAN connector on the printer to a LAN hub as appropriate.
  • Page 8 Power Connection The power connector is a 3-pin jack to which a Posiflex power adaptor is inserted. Either a Posiflex power adaptor or a printer power cable connecting from a Posiflex POS system can be connected to the power connector to supply power to this printer.
  • Page 9 SPECIAL ADJUSTMENT OF PAPER ROLL SENSOR Near-End Sensor for Paper Roll Paper Roll Shaft Hold Thumb Wheel Sensor Block Sensor Position Adjust Support Roller The near-end sensor for paper roll in the printer is able to have the printer work with a paper roll of several bobbin sizes.
  • Page 10 Before installing the 58mm-width paper roll, please refer to the figure shown at the right for mounting the spacer plate to the paper roll compartment of the printer. Note that the smooth side is toward the paper roll. Insert the noted corners of the spacer plate into the 3 dents inside the paper roll compartment as arrowed in numeric order.
  • Page 11 PP-6906’s IP ADDRESS is 192.168.192.168, the default WIFI MODE is Adhoc, the printer’s default SSID is POSIFLEX, and the default AUTHENTICATION MODE is open; 9. completing in setting up the PP-6906, click the SAVE button; and Page 11...
  • Page 12 1. adjust the DIP switch position 2 to ON, leaving the rest unchanged as factory default setting; and 2. through the Microsoft zero configuration tool on you host terminal, locate the wireless printer of which the SSID is POSIFLEX, and click Connect. Be aware, however, DHCP is supported in LAN connection only.
  • Page 13: General Cleaning

    OPERATION GUIDE MAINTENANCE GUIDELINE • Always turn off the power before opening the cover. • Do NOT touch the areas around the print head and motor that become very hot during and just after printing. • When handling the interior of the printer, please pay attention to each sharp edge of the metal parts to avoid accidents of injury.
  • Page 14 Printing Problems Nothing can be printed with ERROR LED flashing – Most possible cause for the flashing Error LED is that the printer has been printing for quite a period of time and the temperature of print head becomes too high. After few minutes under normal ventilation, the print head should be able to cool down and the Error LED will stop flashing.
  • Page 15: Useful Tips

    • Please note that only those qualified technicians may adjust several jumpers for some technical settings. Please visit our web site http://www.posiflex.com or http://www.posiflex.com.tw for details of the technical information such as driver installation, DIP switch settings and command sets etc., if required.
  • Page 16: Further Technical Information

    These switch settings are described below. Setup through Hardware DIP Switch On the bottom cover of the PP-6906 series thermal sensitive printer, there is a screwed metal plate for setup window. In this window, there is an 8- position DIP switch for printer setup. Please use a proper tool to change the switch setting, if necessary.
  • Page 17 Setup through software switch: Another method of setting up PP-6906 series is implemented through the software switch setting, which means that software utility must be used for setup of other functions. Please visit our web site http://www.posiflex.com/up/Download/downlaod...
  • Page 18 Switch OFF (Default) position Print width allowable – 576 dots Print width allowable – 512 dots Paper feed back disable Paper feed back enable Raster bitmap printing – batch Raster bitmap printing – line print print Parity check – EVEN Parity check –...
  • Page 19 Switch position Reduction of line space (Refer to the setting guide made below for the details.) Reduction of line feed (Refer to the setting guide made below for the details.) (Reserved) Users may save paper by of the original size. reduction of barcode height Please refer to the following table to change the switch settings.
  • Page 20: Specifications

    SPECIFICATIONS PRINTER UNIT ITEM DESCRIPTION Communication LAN / WLAN_IEEE 802.11 b/g (optional) Effective paper width 80 or 58 +0/-1 mm (max.) Paper spacing plate size 80 or 58 mm paper width paper guide adaptor 80 & 58mm Print width 64 mm (512 dots / line) / 72 mm (576 dots / line) 8 dots / mm, Print resolution 512 (default) or 576 (max.) dots / line...
