Installation and service manual
CH-299
CH-399
CH-499
This manual must be
left with owner and
must be hung on or
adjacent to the
boiler for reference.
Low NOx certified to SCAQMD 1146.2
AVERTISSEMENT. Assurez-vous de
bien suivre les instructions données dans
cette notice pour réduire au minimum le
risque d'incendie ou d'explosion ou pour
éviter tout dommage matériel, toute
blessure ou la mort.
— Ne pas entreposer ni utiliser d'essence
ou ni d'autres vapeurs ou liquides
inflammables à proximité de cet appareil
ou de tout autre appareil.
— QUE FAIRE SI VOUS SENTEZ UNE
ODEUR DE GAZ :
•Ne pas tenter d'allumer d'appareils.
•Ne touchez à aucun interrupteur. Ne pas
vous servir des téléphones dans le bâtiment
où vous vous trouvez.
•Appelez immédiatement votre fournisseur
de gaz depuis un voisin. Suivez les
instructions du fournisseur.
•Si vous ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
L'installation et l'entretien doivent être
assurés par un installateur ou un service
d'entretien qualifié ou par le fournisseur
de gaz.
This manual must be
left with owner and
must be hung on or
adjacent to the boiler
for reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CH-299 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ECR International CH-299

Summary of Contents for ECR International CH-299

  • Page 1 Installation and service manual CH-299 CH-399 This manual must be left with owner and must be hung on or CH-499 adjacent to the boiler for reference. Low NOx certified to SCAQMD 1146.2 AVERTISSEMENT. Assurez-vous de WARNING: If the information in this bien suivre les instructions données dans...
  • Page 3 Customer must register unit within thirty (30) days of installation in order to gain warranty coverage. See Warranty Card for details NOTICE Leave all documentation received with appliance with the owner for future reference. WARNING: To maintain the safety & longevity of your appliance, read and follow the maintenance schedule information throughout this manual.

  • Page 4: Table Of Contents

    TABLE OF CONTENTS IMPORTANT WARNINGS ..............................8 SAFETY GUIDELINES ..............................10 INTRODUCTION................................16 TECHNICAL DATA CH BOILERS ..........................17 BOILER DIMENSIONS ..............................21 UNPACKING AND ACCESSORIES ..........................24 INSTALLATION LOCATION OF THE CH ........................25 CONNECTIONS................................28 8.2.1 Gas line connection ............................28 8.21.1 Example of a single boiler heating circuit with low loss header ...............
  • Page 5 9.5.1 Delta temperature modulation ......................... 41 9.5.2 PID calculation scaling ............................ 41 FLUE GAS AND AIR SUPPLY SYSTEM ........................42 10.1.1 Vent sizing..............................42 10.1.2 Vent and air inlet resistance table (twin pipe) ....................43 10.1.3 Vent and air resistance table (concentric) ....................... 43 10.2.1 Approved manufacturers ..........................
  • Page 6 13.7.1 Circulator start every 24 hours ........................88 13.7.2 Frost protection ............................... 88 13.7.3 Flue temperature protection ..........................88 13.8.1 Control functions ............................. 90 13.8.2 On board HMI and LED colors ........................91 13.8.3 Flame detection ............................... 91 13.8.4 Flame recovery ............................... 91 13.9.1 CH with room thermostat only;...
  • Page 7 INSPECTION, MAINTENANCE AND SERVICE......................134 20.3.1 Mounting the burner door ..........................142 20.3.2 Boiler room check ............................142 USER INSTRUCTIONS ..............................144 INSTALLATION EXAMPLES ............................144 SPARE PARTS................................148 CH Installation manual...

  • Page 8: Important Warnings

    1 IMPORTANT WARNINGS Definitions IMPORTANT READ ALL OF THE FOLLOWING WARNINGS AND STATEMENTS BEFORE READING THE INSTALLATION INSTRUCTIONS DANGER Danger Sign: indicates the presence of an imminently hazardous situation that will cause death, serious personal injury or substantial property damage. WARNING Warning Sign: indicates the presence of a hazardous situation which can cause death, serious personal injury or substantial property damage.

  • Page 9: General Warnings

    General warnings WARNING This Boiler must be installed by a licensed and trained Heating Technician, a qualified installer, service agency, or the gas supplier or the Warranty is void. Failure to properly install this unit could result in property damage, serious injury to occupants, or possibly death.

  • Page 10: Safety Guidelines

    2 SAFETY GUIDELINES English version Use only your hand to turn the manual shutoff valve. Never use tools. If the manual valve will not turn by hand, don’t try to repair it, call a qualified sevice technician. Force or attempted repair may result in a fire or explosion STOP! Read the safety information above on Wait five (5) minutes to clear out any gas.
  • Page 11 Version français N’utilisez que votre main pour tourner la vanne d’arrêt manuelle. N’utilisez jamais d’outils. Si la vanne manuelle ne tourne pas à la main, n’essayez pas de la réparer, appelez un technicien sevice qualifié. La force ou la tentative de réparation peut entraîner un incendie ou une explosion.

  • Page 12: Entretien Et Inspection

    Avertissement Une installation, un réglage, une modification, une réparation ou un entretien non conforme aux normes peut entraîner des dommages matériels, des blessures (exposition à des matières dangereuses) ou la mort. L'installation et l'entretien doivent être effectués par un installateur ou un service d'entretien qualifié ou le fournisseur de gaz (qui doivent avoir lu les instructions fournies avant de faire l'installation, l'entretien ou l'enlèvement de la chaudière et les respecter.

  • Page 13: Specific Warnings

    Specific warnings This boiler is equipped with a pressure switch in the event of a blocked vent; the boiler will lockout. No attempt by the user/owner shall be made to put the boiler back into operation. A qualified service technician must be notified of the issue. The boiler should only be reset by a qualified service technician after they have diagnosed and corrected the issued that caused CAUTION the safety lockout of the boiler.

  • Page 14: To Avoid Injury

    To meet commercial hot water requirements, the tank setpoint is adjustable up to 185°F. However, water temperatures over 125°F can cause severe burns instantly or death from scalds. This is the preferred starting point for setting the control for supplying general purpose hot water. WARNING: Water temperatures over 125 °F (52 °C) can cause severe burns instantly or death from scalding.

  • Page 15: For Installations In The Commonwealth Of Massachusetts

    for installations in the Commonwealth of Massachusetts The following local requirements apply in addition to all other applicable NFPA requirements: For direct- vent boilers, mechanical-vent heating appliances or domestic hot water equipment, where the bottom of the vent terminal and the intake is installed below four feet above grade the following requirements must comply: 1) If not present on each floor level where there are bedrooms, a carbon monoxide detector and alarm must be placed in a living area outside the bedrooms.

  • Page 16: Introduction

    3 INTRODUCTION This manual is written for the installer and service Ce manuel est écrit pour l'installateur et le technicien technician. d'entretien. The supplier accepts no liability for any damage, Le fournisseur décline toute responsabilité pour tout injury, or loss of life resulting from incorrect dommage, blessure ou perte de vie résultant d’une installation, alteration of any factory supplied parts, installation incorrecte, d’une modification de toute...

  • Page 17: Technical Data Ch Boilers

    4 TECHNICAL DATA CH BOILERS Functional introduction The CH boilers are central heating boilers with a maximum high efficiency. Such a performance can be reached by, amongst other things, using a special heat exchanger made of stainless steel. This allows the flue gases to cool down below the condensation point, and so release extra heat.

  • Page 18: Installation

    Technical specifications datasheet GENERAL Boiler category IV, direct vent BOILER MODEL CH–299 CH–399 CH–499 Dimensions (h x w x d) inch (mm) 33.3 x 17.3 x 21.2 (845 x 440 x 539) Gallon Water content 1.77 (6.7) 2.19 (8.3) 2.74 (10.4) (liter) Weight (empty) Lbs (kg)

  • Page 19: High Altitude Operation

    Model boiler CH–299 CH–399 CH–499 ELECTRIC Maximum power consumption Power supply V/Hz 120 / 60 Protection class IPX4D NOTES Power consumption is measured without circulator For room air installations only class IPX4D with special air inlet (see § 6.2 "Accessories"), otherwise the protection class is IP20.

  • Page 20: Ahri Specifications

    AHRI Specifications CH series AHRI Thermal Combustion Input, MBH Model Output AFUE Net Ratings Efficiency, Efficiency, number Water, MBH CH–299 46.0 95.1 CH–399 72.0 95.5 95.4 CH–499 83.0 95.6 95.1 Listed Input and Output ratings are at minimum vent lengths at Sea Level. Numbers will be lower with longer venting and/or altitudes greater than 2000 feet [610 m].

  • Page 21: Boiler Dimensions

    5 BOILER DIMENSIONS CH–299 Vent connection – Connections NPT 1½” Supply NPT 1½” Return Condensate Flexible hose Ø 1.06” (26.9 mm) NPT 1” Table 5.1 Figure 5.1 CH Installation manual...
  • Page 22 CH–399 Vent connection Connections – NPT 1½” Supply NPT 1½” Return Condensate Flexible hose Ø 1.06” (26.9 mm) NPT 1” Table 5.2 Figure 5.2 installation manual...
  • Page 23 CH–499 Vent connection – Connections NPT 1½” Supply NPT 1½” Return Condensate Flexible hose Ø 1.06” (26.9 mm) NPT 1” Table 5.3 Figure 5.3 CH Installation manual...

  • Page 24: Unpacking And Accessories

    6 UNPACKING AND ACCESSORIES Unpacking The CH boiler will be supplied with the following documents and accessories:  One “Installation, and service instructions” manual for the installer (inside the boiler, at the sidepanel)  One User Manual (inside the boiler, at the sidepanel) ...

  • Page 25: Installation Location Of The Ch

    7 INSTALLATION LOCATION OF THE CH Installation Clearances On all sides of the boiler at least 2” of clearance must be applied to walls or wall units, 14” above the top side of the boiler and 10” from the bottom of the boiler. Clearances to wall, ceiling and floor Distances –...

  • Page 26: Boiler Installation Location Requirements

    Boiler Installation Location Requirements:  The installation of this boiler when installed using room air must comply to the latest edition of ANSI Z223.1/NFPA 54 and/or the CAN/CSA B149.1 Natural gas and propane installation code.  The flue gas exhaust pipes must be connected to the outside wall and/or the outside roof. (“Flue gas instructions”...

  • Page 27: Mounting The Boiler

    Mounting the boiler Before mounting and installing the boiler the following connections must be considered:  Flue gas system and the flue gas pipe connections  Air supply system and connections  Supply and return pipe connections  Condensate and pressure relief valve drainage ...

  • Page 28: Connections

    8 CONNECTIONS Boiler connections 1 – Water outlet / Flow 2 – Water inlet / Return 3 – Gas 4 – Condensate trap clean out. 5 – Condensate drain 6 – Automatic air drain. Figure 8.1 4 5 6 3 4 5 6 Gas pipe connection The gas supply piping must conform to all local codes and regulations and/or National Fuel Gas Code, ANSI Z223.1/NFPA 54.
  • Page 29 Create an installation layout such that the piping does not interfere with the vent pipe, or any other serviceable components. The appliance shall be installed such that the gas ignition system components are protected from water (dripping, spraying, rain etc.) during installation, operation and servicing. No appreciable drop in line pressure should occur when any unit (or in the instance of a cascade installation when all of the installed units) lights or runs.

  • Page 30: Condensate Drain Connection

    Condensate drain connection The condensate drain is placed at the center and at the bottom of the boiler and has a ¾ inch hose discharge. Connect this flexible hose to the sewer system. Use only plastic parts with the condensate drain. Metal lines are not allowed.
  • Page 31 Flow and return connections Use T-pieces for externally mounting the pressure relief valve and the boiler drain valve for servicing the boiler. We advise to install two service ball valves in the flow and return pipes underneath the boiler, so the boiler can be isolated from the heating system and eventually disconnected, when needed.

  • Page 32: Circulator Functionality

    Chilled Water and Refrigeration Systems The boiler, when used in connection with a refrigeration system, must be installed so the chilled medium is piped in parallel with the boiler with appropriate valves to prevent the chilled medium from entering the boiler The boiler piping system of a hot water boiler connected to heating coils located in air handling units where they may be exposed to refrigerated air circulation must be equipped with flow control valves or other automatic means to prevent gravity circulation of the boiler water during the cooling cycle.

  • Page 33: Boiler Water Quality

    Boiler water quality The pH value is reached with the steady Contaminant Maximum allowable level Units conditions. These steady conditions will 7.5 to 9.5 occur, when after filling the heating system Hardness 50 to 150 ppm CaCo3 (pH about 7) with fresh water, the water 2.9 to 8.8 Grains/gallon loses its air because of air bleeding...

  • Page 34: Chemical Water Treatment

    The use of 50% glycol in the boiler system will result in an increase in the viscosity of the water/glycol mixture and a decrease in the heat transfer. When the boilers are used in a system with 50% glycol the following requirements must be followed at all times.

  • Page 35: Flush The System With Fresh Water

    Flush the system with fresh water The water of the boiler and heating circuit must be free of any particles, debris and pollution. Therefore, the complete installation must always be thoroughly flushed with clean water before installing and using the boiler(s). Plastic piping in the heating system When plastic pipes without oxygen barrier are used in the central heating system, these must be separated from the boiler system by using a plate heat exchanger.

  • Page 36: Automatic Feed Valve

    The following scheme below shows the behavior of the 3-way valve and boiler circulator during one whole cycle of De-Air sequence with a DAir_Repetition_OnOff set to 2. Boiler Circulator Figure 8.8 Relevant variables: Specific Parameters Level (Default) Value Range De_Air_Config 2: Installer 0…1 0 = DAir disabled;...

  • Page 37: Example Of A Single Boiler Heating Circuit With Low Loss Header

    Installation examples 8.21.1 E XAMPLE OF A SINGLE BOILER HEATING CIRCUIT WITH LOW LOSS HEADER Boiler circulator valve Heating circulator air separator Flow/System temperature sensor BOILER dirt separator strainer (water filter) pressure relief valve HEATING ZONE T & P condensate trap circulator automatic air vent expansion vessel...

  • Page 38: Circulator Characteristics

    9 CIRCULATOR CHARACTERISTICS Hydraulic graphs 9.1.1 B CH–299 OILER RESISTANCE GRAPH ∆T=35ºF ∆T=25ºF ∆T=20ºF Figure 9.1 9.1.2 B CH–399 OILER RESISTANCE GRAPH ∆T=25ºF ∆T=35ºF ∆T=20ºF Figure 9 2 installation manual...

  • Page 39: Boiler Resistance Graph Ch-499

    9.1.3 B CH–499 OILER RESISTANCE GRAPH ∆T=35ºF ∆T=25ºF ∆T=20ºF Figure 9.3 CH Installation manual...

  • Page 40: Minimum Required Circulator Head

    Minimum required circulator head The hydraulic graphs presented in §9.1 show the pressure loss of the boiler only. When selecting a circulator, it is important to take also into account the piping to and from the low loss header. Also tees and bends add to the total pressure loss. NOTICE Grundfos Circulator Sizing Boiler type / ΔT...

  • Page 41: Delta Temperature Modulation

    9.5.1 D ELTA TEMPERATURE MODULATION The variable speed control is designed to ensure that the delta T across the boiler’s heat exchanger matches the set delta T in the boiler control ensuring efficient temperature control and maximizing both electrical energy efficiency and the percentage of time the boiler operates in a condensing mode.

  • Page 42: Flue Gas And Air Supply System

    10 FLUE GAS AND AIR SUPPLY SYSTEM General venting. The boiler has a positive pressure vent system. The boiler is for either direct vent installation or for installation using indoor combustion air, category IV, appliance with sealed combustion requiring certain venting systems. All combustion air is drawn from outdoors or indoor. All products of combustion are vented directly outdoors.

  • Page 43: Vent And Air Inlet Resistance Table (Twin Pipe)

    45 ft 65 ft Table 10.3 10.1.3 V ENT AND AIR RESISTANCE TABLE CONCENTRIC Maximum allowed length concentric flue, feet CH-299 CH-399 CH-499 3” / 5” 4” / 6” 5” / 8” Table 10.3a Pipe, elbows, terminals equivalent feet (concentric) 3”...

  • Page 44: Vent And Air Intake Pipe Material

    Vent and air intake pipe material Items Materials Venting System Standards Warning United States Canada Flue piping and CPVC Schedule 40 ANSI/ASTM F441 All venting All Vent and Air-Inlet Fittings material in materials installed on PVC Schedule 40 ANSI/ASTM D1785 Canada must be gas fired appliances in Stainless Steel SS...
  • Page 45 PVC / CPVC This product has been approved for use with the PVC / CPVC vent materials listed in this manual. All terminations must comply with listed options in this manual and be a single-wall vent offering. For support and special connections required, see the manufacturer's instructions. All vent is to conform to standard diameter and equivalent length requirements established.

  • Page 46: Instructions For Cementing Pvc/ Cpvc Pipe Connections

     In Canada, CPVC and PVC vent pipe, fittings and cement/ primer must be ULC-S636 certified.  Use only cleaners, primers, and solvents that are approved for the materials which are joined together. NOTICE  All PVC vent pipes must be glued, properly supported, and the exhaust must be pitched a minimum of 1/4 inch per foot back to the boiler (to allow drainage of condensate).
  • Page 47 TERMINATION WATER TERMINATION HEATER 4” UV resistant tee 4” Twin Pipe Side Wall 4” Bird guard screen CH–299 4" Termination Tee CH-299 CH–399 4" concentric roof 4" Termination Pipe CH-399 CH–499 4” Bird Screen 4" concentric wall CH-499 4" Concentric roof termination 4”...

  • Page 48: Reducer

    • Rigid polypropylene vent pipe must be installed with approved locking band clamps or connector rings and supports (wall strap or clamp, elbow or base, etc.). Consult vent manufacturer for complete list of required parts. • Maintain 1/4 in. [6 mm] per foot slope back toward appliance on all horizontal runs. •...
  • Page 49 • Approved for vertical installations only, where a clean, structurally sound unused chimney or chase is used as a raceway. • Vertical offsets must not exceed 45° and are limited to a maximum number of 2. • Requires rigid polypropylene vent pipe with approved locking band clamps or connector rings and wall straps or support clamps from the appliance to the entrance of the chimney or chase.
  • Page 50 BOILER TERMINATION TERMINATION TERMINATION TERMINATION termination tee termination tee termination tee termination tee screen termination screen termination CH-299 bird screen wall screen termination rain cap elbow termination CH–399 rain cap roof rain cap exit cone rain cap termination tee termination tee...

  • Page 51: Sealed Combustion Air Supply

    Sealed Combustion Air supply When an air supply pipe is connected from the outside of the building to the boiler, the boiler will operate as a sealed combustion boiler. The air supply duct can be made of PVC, CPVC, PP or Stainless steel. 10.6.1 C OMBUSTION AIR QUALITY Combustion air must be free of contaminants.

  • Page 52: Air Inlet Pipe Materials

    10.6.4 A IR INLET PIPE MATERIALS The air inlet pipe(s) must be sealed. Choose acceptable combustion air inlet pipe materials from the following list: - PVC, CPVC or PP - Flexible propylene air intake - Galvanized steel vent pipe with joints and seams sealed as specified in this section. - Type “B”...

  • Page 53: Air Contamination

    Indoor air components: Duravent, Polypro / FasnSeal Centrotherm Termination Boiler Termination Boiler 4” Termination tee 4" Termination Tee CH-299 CH–299 4” Rain cap CH-399 4” Bird Screen CH–399 4” Termination tee 5" Termination Tee CH–499 6" Termination Tee 4”...

  • Page 54: Proper Vent Installation And Type Of Gas Vent Or Vent Connector

    Corrosive Contaminants and Sources Products to avoid: Spray cans containing chloral/fluorocarbons Permanent wave solutions Chlorinated waxes/cleaners Chlorine-based swimming pool chemicals Calcium chloride used for thawing Sodium chloride used for water softening Refrigerant leaks Paint or varnish removers Hydrochloric acid/muriatic acid Cements and glues Antistatic fabric softeners used in clothes dryers Chlorine-type bleaches, detergents, and cleaning solvents found in household laundry...

  • Page 55: Requirements For Installation In Canada

     The boiler must be vented and supplied with combustion and ventilation air as described in this section. Ensure the vent and air piping and the combustion air supply comply with these instructions regarding vent system, air system, and combustion air quality. See also sections "Determine vent location"...

  • Page 56: Direct Venting Options

    Direct venting options Two pipe wall Two pipe vertical See § 10.11 for more details. See § 10.12 for more details. Figure 10.6 Figure 10.5 Single pipe wall (room air) Single pipe roof (room air) See § 10.7 for more details See §...
  • Page 57 Concentric wall - two pipe to boiler Concentric wall - concentric to boiler Boilers CH–299, CH–399 only. Boilers CH–299, CH–399 only. See § 10.11 for more details. See § 10.11 for more details. Note: Minimum short pipe lengths required. Air intake – 7”, Exhaust Outlet: 12.5”. Figure 10.9 Figure 10.10 Concentric vertical - two pipe to boiler.

  • Page 58: Wall (Horizontal) Direct Venting

    Wall (Horizontal) direct venting. 10.11.1 V AIR TERMINATION WALL Follow instructions below when determining vent location to avoid possibility of substantial property damage, severe personal injury, or death. A gas vent extending through an exterior wall shall not terminate adjacent to a wall or below building extensions such as eaves, parapets, balconies, or decks.

  • Page 59: Positions

    3. The installer must use a galvanized metal thimble for the vent pipe penetration and properly seal the PVC/CPVC vent pipe to the vent termination plate using silicone sealant. 4. Properly support the PVC/CPVC using pipe metal strap hangers or equivalent pipe hangers suitable for plastic pipe.
  • Page 60 note 1: In accordance with the current ANSI Z223.1 / NFPA 54 National Fuel Gas Code note 2: In accordance with the current CAN/CSA-B149.1 Installation Codes note 3: Maintain 12” of clearance above the highest anticipated snow level or grade or, whichever is greater. Please refer to your local codes for the snow level in your area note 4: For clearances not specified in ANSI Z223.1 / NFPA 54, clearance is in accordance with local installation codes and the requirements of the gas supplier.

  • Page 61: Multiple Vent/Air Terminations

    Two pipe sidewall termination assembly. Figure 10.17 Multiple vent/air terminations 1. When terminating multiple boilers, terminate each vent/air connection as described in this manual (Figure 10.18). All vent pipes and air inlets must terminate at the same height to avoid possibility of severe personal injury, death, or substantial property damage.
  • Page 62 Wall termination – low profile Description and usage: Two pipe termination. Both combustion air and exhaust vent pipes must attach to the termination kit. The termination kit must terminate outside the structure and must be installed as shown below in Figure 10.19.
  • Page 63 Ensure termination location clearance dimensions are as shown in Figure 10.21. NOTICE DO NOT use field-supplied couplings to extend concentric terminations. Airflow restriction will occur and could cause intermittent operation. CAUTION CAUTION Multi venting wall terminations When two (2) or more direct vent appliances are vented near each other, each appliance must be individually vented.

  • Page 64: Roof (Vertical) Direct Venting

    Roof (Vertical) direct venting. 10.12.1 V – AIR TERMINATION VERTICAL Follow instructions below when determining vent location to avoid possibility of severe personal injury, death or substantial property damage. WARNING 10.12.2 D ETERMINE LOCATION Locate the vent/air terminations using the following guidelines: 1.
  • Page 65 Multiple vent/air terminations 1. When terminating multiple boilers, terminate each vent/air connection as described in this manual (figures 10.23, 10.24 and 10.25). Terminate all exhaust vent pipes at the same height and all air intake pipes at the same height to avoid recirculation of flue products. Failure to comply with the requirements can result in substantial property damage, serious injury, or death.
  • Page 66 Concentric Vertical Termination: Minimum clearance above snow level (18” for Canada) Maximum 24” above roof or snow level Figure 10.26 Do Not Install U-Bend or elbow on a concentric termination Figure 10.27 Do not operate the appliance with the rain cap removed on the concentric terminations or recirculation of combustion products can occur.
  • Page 67 Concentric vent and combustion air vertical termination multiple boilers. NOTICE: a minimum distance of 24 in. (61 cm) to wall or parapet. Figure 10.28 60“ MIN Figure 10.29 CH Installation manual...

  • Page 68: Common Vent Cascading

    100 ft (30 m) 100 ft (30 m) 100 ft (30 m) 100 ft (30 m) 100 ft (30 m) CH-299 36 ft (11 m) 100 ft (30 m) 100 ft (30 m) 100 ft (30 m) 100 ft (30 m)

  • Page 69: Additional Safety Advice

    Safety measures Common Flue Systems Above is described that CH boilers can be used with an overpressure common flue system from Duravent. In case CH boilers are installed with a common flue system and the combustion air is drawn directly from the room, safety measures have to be taken.
  • Page 70 Figure 11.3 Use an extra 120V relay with 4 poles. In case of power failure on the CO alarm system and modules the boilers will shut down. Mount, install, test and maintain the CO detector according to the manufacturer’s instructions. Test the system at least monthly, to ensure the boilers will switch off in case of a CO alarm.

  • Page 71: Existing Common Venting Guidelines

    Existing Common Venting Guidelines. Do not common vent the CH boiler with the vent pipe of any other boiler or appliance. However, when an existing boiler is removed from an existing common venting system, the common venting system is likely to be too large for proper venting of the appliances remaining connected to it.

  • Page 72: Electrical Installation

    12 ELECTRICAL INSTALLATION General  For operation, the boiler needs a dedicated 120 Vac / 60Hz / 15A service.  The boiler mains supply connection is polarity sensitive. L-120 Vac, N-Neutral, PE-Earth ground (Figure 12.2)  The wiring for the connections should be routed at the bottom of the boiler through the wiring knockouts. Separate knockouts are provided for both line voltage and low voltage wiring.

  • Page 73: Additional Safety Limits

    CH call connections to the boiler require a dry contact with no external voltage present. Ensure no external voltage is present on each set of wires before connecting to the boiler. If external voltage is present, the use of an isolation relay is required to prevent damage to the boiler management module.

  • Page 74: Outdoor Sensor

    Explanation of the low voltage connections, Figure 12.1. Low Voltage Terminals 1-2 OUTDOOR SENSOR If an outdoor temperature sensor is connected, the boiler will control the supply water temperature by using a calculated setting based on outdoor reset curve, which is related to the outdoor temperature. An outdoor sensor accessory, part number S022.500.020 is available.

  • Page 75: Boiler Circulator

    Explanation of the line voltage connections, Figure 12.2. Line Voltage Terminals 1-2-3-PE DIVERTER VALVE DHW indirect tank / DHW CIRCULATOR If an indirect domestic hot water tank is installed, a 3-way valve or a circulator (P2) can be used to divert hot water to the heating coil of the tank.

  • Page 76: Electrical Schematics

    Electrical schematics Optional Figure 12.3 installation manual...
  • Page 77 Figure 12.4 CH Installation manual...

  • Page 78: Ladder / Logic Diagram

    Ladder / Logic diagram Figure 12.5 installation manual...

  • Page 79: Sensor Availability

    Sensor availability The following table shows the sensor availability for all CH and DHW control modes. Sensors not mentioned in the table are optionally available for other functions CH Mode T_Supply T_Return T_DHW T_Outdoor 0-10 Volt Water Flow DHW RT Switch M = Mandatory, O = Optional, --- = Disabled.

  • Page 80: Programmable In- And Outputs

    Programmable in- and outputs It is possible to re-program some in- and outputs to other functions. To do this use list below and go to: Menu\settings\boiler settings\"1122" (installer password)\boiler parameters boiler parameter name default setting description terminal (117) Prog. Input 2. DHW flow switch LV 16-17 (118)

  • Page 81: Boiler Controller And Display

    13 BOILER CONTROLLER AND DISPLAY. 100.0 °F 170.0 °F Figure 13.1 Explanation of the buttons ON/OFF. On/off switch. Switches electrical power to the boiler COMPUTER. Connector for computer cable RESET. Reset lockout error MENU. Enter the main menu ESCAPE. Escape / Return to the status overview RIGHT.

  • Page 82: Display Configuration

    Display configuration. The Status overview has three different sections that show specific information: 13:56 Figure 12.2 Header Standby Middle section T3:98 °F 55 Psi Footer 90 °F Actual setpoint Figure 13.3 Header Left: For cascade systems the cascade icon is shown, with the cascade manager indication (M) or the dependent number.

  • Page 83: Starting The Boiler

    Starting the boiler If the boiler is not on make sure the gas valve beneath the boiler is open and the power is wired into the mains, use the on/off button to switch the boiler on. The following screen will occur: Initializing Figure 13.4 This screen is active during power up until communication with the main Control has been established.

  • Page 84: Set The Setpoint By The Menu Button

    13.3.2 S MENU ET THE SETPOINT BY THE BUTTON Enter the menu by pressing the MENU button once. The header in the display shows you are inside the main menu. While scrolling through the menu you will see that the selected menu item is shown in a white rectangle. Central Heating (CH) Domestic Hot Water (DHW) Information...

  • Page 85: Language Settings

    Enter the password with the following steps: 1. Use the UP/DOWN ↑↓ button to adjust the first number 2. Press CONFIRM or RIGHT → to confirm and to go to the following number Repeat this action for all numbers to enter the password. After the password is entered in correctly press ENTER/RIGHT to confirm and access the menu item.

  • Page 86: Boiler History

    Boiler history The boiler history found in the information menu displays several history counters that keep track of the boiler usage. The history cannot be erased and will continue for the burner controller life cycle. The following boiler history data is available: (Sub) Menu item Description Successful Ignitions...

  • Page 87: Service Overdue Logging

    The error log screen will show on the first line: Boiler ID for which boiler the error was detected (cascade system only), Error Code, (internal) Error Number, Error Type (Lockout/Blocking). The second line will show the Error Description. The bottom line will show the Time Stamp (date and time) when the error was detected (in the format as configured in the Date Time Settings menu), and also the selected error index from the total number of errors in the (filtered) error log.

  • Page 88: Circulator Start Every 24 Hours

    General The boiler controller is designed to function as a standalone control unit for intermittent operation on heating appliances with a premix (modulating) burner and a pneumatic air-gas system. Fuses Line input 1 x 5AT, 120V Flame establishing period 2 seconds Safety time 5 seconds Ignition attempts...

  • Page 89: Ignition Cycle

    Ignition cycle During the ignition cycle multiple safety checks are active Figure 13.16 The table below shows the states of the burner ignition cycle, as shown in the diagram above: Burner state Actions INIT  Controller initialization RESET Software reset (and initialization) ...

  • Page 90: Control Functions

    During the ignition cycle multiple safety checks are active, none of the initiation timing settings are adjustable: False flame detection If a flame is detected at the end of the pre-spark period (Pre_Ignit) a lockout error will occur. Re-ignition If at the end of the safety period no flame is detected the control will go to Post_Purge to remove any unburnt gas.

  • Page 91: On Board Hmi And Led Colors

    13.8.2 O N BOARD COLORS On the burner controller a basic on-board Human Interface (HMI) is available which consists of a push button (reset) and a 2 color (red/green) LED. These are used to indicate basic status information about the control. Status LED Reset button Figure 13.18...

  • Page 92: Control Functions

    Control functions Dependent on the required functions of the appliance and connected sensors and components, several operation modes for Central Heating (CH) and Domestic Hot Water (DHW) can be selected. 13.9.1 CH ; CH WITH ROOM THERMOSTAT ONLY MODE FACTORY DEFAULT SETTING For this mode no outdoor sensor is needed.

  • Page 93: Shutdown Temperature

    13.9.2 CH THERMOSTAT; CH WITH AN OUTDOOR TEMPERATURE RESET AND MODE If the parameter CH_Mode is set to 1, the “Outdoor temperature reset with room thermostat” mode is selected. This mode will only function when an outdoor temperature sensor is connected. If the outdoor sensor is not connected, the boiler automatically uses Design_Supply_Max._Limit (par.

  • Page 94: Setpoint Adjustment

    Setpoint adjustment It is possible to adjust the calculated setpoint with parameter CH_Setpoint_Diff. The calculated setpoint can be increased or decreased with a maximum of 18°F (10°C). The CH setpoint limits (Design_Supply_Min._Limit and Design_Supply_Max._Limit) are respected while adjusting the setpoint. Apart from the calculated setpoint the functionality is the same as described in §...

  • Page 95: With Full Outdoor Temperature Reset; Ch Mode 2

    13.9.3 CH ; CH WITH FULL OUTDOOR TEMPERATURE RESET MODE When CH_Mode is set to 2, full weather compensator is chosen. For this mode an outdoor sensor has to be connected. The CH_Setpoint is calculated on the same way as described in § 13.9.2. However, the demand does not depend on the Room Thermostat input but on the outdoor temperature and the outdoor reset setpoint.

  • Page 96: With Analog Input Control Of Setpoint; Ch Mode 4

    13.9.5 CH ; CH WITH ANALOG INPUT CONTROL OF SETPOINT MODE In mode 4 of operation, the boiler CH setpoint is controlled by an analog input signal provided by a remote means such as a Building Management System or a system controller. The analog input 0-10 Vdc is used to adjust the boiler setpoint between the CH_Min_Setpoint and the CH_Max_Setpoint settings.

  • Page 97: With Analog Input Control Of Power Output; Ch Mode 5

    13.9.6 CH ; CH WITH ANALOG INPUT CONTROL OF POWER OUTPUT MODE In this mode of operation, the temperature needs to be controlled by an external temperature controller. When the boiler has reached a supply temperature of 203⁰F (95⁰C) the boiler switches off and shows the blocking code “High Temp Error”...

  • Page 98: No Domestic Hot Water; Dhw Mode 0 (Factory Default Setting)

    Demand for Domestic Hot Water HOT WATER CAN SCALD! Water temperature over 125ºF can cause severe burns instantly or death from scalds. - Children, disabled and elderly are at highest risk of being scalded. - Never leave them unattended in or near shower, bathtub or sink. - Never allow small children to use a hot water faucet or draw their own bath.

  • Page 99: Dhw Storage With Thermostat; Dhw Mode 2

    Store warm hold function Because of the presence of the tank sensor (T_Store) the control can detect demand for holding the indirect tank hot. If the tank sensor drops below DHW_Store_Setpoint minus DHW_Tank_Hold_Warm the boiler starts at minimum power. The boiler stops if the tank sensor is higher than DHW_Store_Setpoint plus DHW_Tank_Hyst_Up. Relevant variables Parameters Parameter number...

  • Page 100: Anti-Legionella Protection

    Based on a DHW temperature rise of 100 °F following minimum and maximum DHW flows are advised: Boiler model Minimum flow (gpm) Maximum flow (gpm) CH–299 CH–399 CH–499 Table 13.24 Relevant variables Parameters Parameter no. Level Default value Range DHW Setpoint 2: Installer 140ºF (60°C) 104 - 160°F (40 - 71°C)
  • Page 101 When the control is powered the anti-legionella algorithm will be initialized when enabled. The initial wait time before an anti-legionella cycle is started is initialized as following:  Anti-legionella enabled AND T_Store < Anti_Legionella_Setpoint – 5°F. Anti-legionella wait time initialized to 120 [min]. ...

  • Page 102: Display Menu Structure Summary

    Display menu structure summary. Access Description: Menu structure Display: level 1. Central Heating (CH) User Enter the Central Heating (CH) menu 2. Domestic Hot Water (DHW) User Enter the Domestic Hot Water (DHW) menu 3. Information User Enter the Information menu 4.
  • Page 103 3.2 Boiler status min. max. Default unit Access Description: level Flow Temperature °F (°C) User Actual supply flow temperature Flow 2 Temperature °F (°C) User Actual supply 2 flow temperature Return Temperature °F (°C) User Actual return temperature DHW Temperature °F (°C) User Actual DHW temperature...
  • Page 104 4.1 General settings min. max. Default unit Access Description: level 4.1.1 Language User Enter the Language menu 4.1.2 Unit Type User Enter the Unit Type menu 4.1.3 Date & Time User Enter the Date & Time menu 4.1.4 Cascade Mode User Enter the Cascade Mode menu 4.1.5 Other Settings...
  • Page 105 4.1.4 Cascade mode min. max. Default unit Access Description: level Full Full Installer Select full cascade mode for more data for max 8 boilers Basic Installer Select basic cascade mode for 9 to 16 boilers 4.1.5 Other settings min. max. Default unit Access...
  • Page 106 4.2.1 Boiler parameters min. max. Default unit Access Description: Dis- level play CH mode Installer Set the CH mode CH Setpoint °F Installer Set the CH setpoint (20) (90) (82) (°C) Calc. Setp. Offset °F Installer Set the offset for CH mode 1 / 2 (-10) (10) (°C)
  • Page 107 cont: min. max. Default unit Access Description: Dis- 4.2.1 Boiler parameters level play DHW Tank PID P 1275 Installer Set the DHW tank PID P factor DHW Tank PID I 1275 Installer Set the DHW tank PID I factor DHW Setpoint °F Installer Set the DHW setpoint...
  • Page 108 4.2.2 Module Cascade min. max. Default unit Access Description: Dis- Settings level play Burner Address Stand Installer Set the cascade burner address alone Permit Emergency Mode Yes / Installer Enable/disable the cascade emergency mode Emergency Setpoint °F Installer Set the emergency mode setpoint (90) (70) (°C)
  • Page 109 Parameters for cascade operation are found in the Module cascade settings menu, located in the Boiler settings menu. Parameters in the below Boiler cascade settings menu must not be used. NOTICE 4.2.3 Boiler Cascade Settings min. max. Default unit Access Description: Dis- level...

  • Page 110: Temperature Protection

    14 TEMPERATURE PROTECTION The difference between Supply temperature and Return Temperature is continuously monitored. A too big difference can indicate a defective circulator or a clogged heat exchanger. To protect the boiler, the burner controller reduces the input when this temperature difference ΔT becomes too high: At maximum boiler input ΔT is limited to 63°F (35°C) (Hx_Diff_DeltaT_Max).

  • Page 111: Lockout Codes

    Lockout codes Lock Error Description Cause Solving code EEPROM Read Error Internal software error wrongly programmed BCU reset BCU or replace BCU and or or PB display unit Ignition Error Five unsuccessful ignition no gas, wrongly adjusted check gas supply and adjust gas attempts in a row gas valve valve, reset BCU...
  • Page 112 Lock Error Description Cause Solving code Instruction Error Internal software error wrongly programmed BCU or reset BCU or replace BCU and or display unit Ion Check Failed Internal software error wrongly programmed BCU or reset BCU or replace BCU and or display unit Flame Out Too Late Flame still present 10...

  • Page 113: Blocking Codes

    Blocking codes Blocking Error Description Cause Solving code WD Error Ram Internal software error wrongly programmed reset BCU or replace BCU and / BCU or PB or display unit WD Error Rom Internal software error wrongly programmed reset BCU or replace BCU and / BCU or PB or display unit WD Error Stack...
  • Page 114 Lockout Error Description Cause Solving code T Flue Open Flue sensor open malfunctioning flue check connection to BCU or sensor or not check resistance NTC sensor connected T Outdoor Open Outdoor sensor open malfunctioning outdoor check connection to BCU or sensor or not check resistance NTC sensor or connected or wrong...
  • Page 115 Warnings Error no. Error Description Cause Solving Comm. Lost with Cascade System: Managing connection between Check wiring between boiler or module cascade control lost cascaded boilers is distance between boilers is too big communication with one of the interrupted or wiring is Check cascade parameter 147 depending.

  • Page 116: Cascading

    16 CASCADING System setup NOTE: for proper functioning of the system, some settings have to be changed, see § 16.5.2 "Emergency mode". The boiler controller can control multiple boilers in a cascade setup. A system sensor is necessary to measure the cascade system supply temperature.

  • Page 117: Boiler Cascade Communication Setup

    Select correct CH mode on managing boiler only Parameter: Menu - Settings - Boiler settings - Boiler parameters - Parameter 1 (CH mode) CH mode 0 – Central Heating demand with thermostat control CH mode 1 – Central Heating with an outdoor temperature reset and thermostat control CH mode 2 –...

  • Page 118: Setting Of The Cascade Parameters

    This connection also provides the power for the communication bus. The depending boilers are all parallel connected to the managing boiler communication bus. The bus power is provided by the managing boiler on terminals 20-21, switch S1 must be set in the OFF position (all controls). Figure 16.5 16.3.2 S ETTING OF THE CASCADE PARAMETERS...

  • Page 119: Cascade - Heating Only Managing Boiler

    16.3.3 C – H ASCADE EATING ONLY ANAGING BOILER When a boiler is set as "Managing" (Address = 1), the controller of this boiler will drive the cascade. The CH mode of this managing boiler applies to all other boilers. It is only required to set the CH mode on the managing boiler. •...

  • Page 120: Cascade - Start/Stop Sequence

    16.3.6 C – S ASCADE TART STOP SEQUENCE The managing boiler sends the calculated Cascade_Setpoint to the dependent boilers. The power of the boilers is PID controlled based on the Calculated_Setpoint and T_Supply. Depending on the temperature difference between T_System and Cascade_Setpoint (CH or DHW) the dependent boilers will start or stop using different algorithms.

  • Page 121: Cascade Error Handling

    Cascade Error handling 16.5.1 C ASCADE ROST PROTECTION Frost protection on a cascade is active on two levels 1. Frost protection for burner cascade The ‘frost protection’ function for a module cascade is related to the system sensor temperature. When the sensor value is below: Spec.

  • Page 122: System Test

    17 SYSTEM TEST For testing the system at fixed power rates, a system test can be activated via the Installer menu. Via the system test the boiler can be started without CH or DHW being present. The system test has priority. The following modes are available: System test mode Description...

  • Page 123: Commissioning The Boiler

    18 COMMISSIONING THE BOILER First: flushing the boiler with water After installation of the boiler the first step, before commissioning, is to flush the boiler and the whole heating installation with fresh water to remove pollution, debris and other materials that might cause a blocking. This must also be done with heating installations, where only the boiler is replaced.

  • Page 124: Mounting Condensate Trap

    Mounting Condensate Trap When mounting the bottom part of the condensate trap, before commissioning the boiler and/or after maintenance, it must ALWAYS be completely filled with water. This is a safety measure: the water in the condensate trap keeps the flue gases from leaking out of the heat exchanger via the condensate drain.

  • Page 125: Firing For The First Time

    Firing for the first time After the commissioning of the boiler and the described previous actions, the boiler display will show the following: Initializing Figure 18.2 This screen is active during power up until communication with the main Control has been established. After communication has been established the Dair mode is running and the following screen appears: DAir Running Actual Setpoint...

  • Page 126: Adjusting And Setting The Boiler

    19 ADJUSTING AND SETTING THE BOILER Before carrying out any adjusting of the burner, carefully read this complete chapter. The initial lighting of the appliance must be performed by a licensed Gas Technician. Failure to follow these instructions can result in property damage, serious injury or death. As soon as the appliance has been fully installed (with regard to hydraulics, filling and de- aeration of installation, gas, flue gas, air intake, wiring etc.) according to the preliminary WARNING...

  • Page 127: Combustion Table Low Nox

    19.1.2 C OMBUSTION TABLE Table 2: O and CO values for maximum and minimum load, where NO values are less than 20 ppm at 3% O gas type boiler type / CO / CO High Fire Low Fire natural gas CH–299, CH–399, CH–499 5.3 / 8.8 5.3 / 8.8...

  • Page 128: Setting Screws Venturi- And Gas Valves: Drawings

    19.1.3 S ETTING SCREWS VENTURI AND GAS VALVES DRAWINGS Location of the setting screws: Gas pressure High Fire: nipple [3] screw [2] Low Fire: screw [1] Figure 19.1 High Fire: venturi adjustment screw: use hex key 4 mm (5/32 Allen wrench) High Fire: screw [2] Figure 19.2 Low Fire: gas valve adjustment screw: Torx T40.
  • Page 129 Adjustment procedures Procedure 1: adjust at High Fire Carry out the next steps: 1. From status screen, press MENU . Menu options are Central Heating / Information / Settings / System Test 2. Press UP/DOWN ↑↓ to select "System Test" 3.

  • Page 130: Venturi Replacement Adjustment

    Venturi Replacement Adjustment A new venturi is shipped with an unknown setting. It must be adjusted before it can be used in the boiler.  First, turn setting screw [2] on the venturi clockwise until you feel resistance. This means that the valve is fully open, do not try to turn the screw any further.

  • Page 131: Set Fan Speed

    2. Set fan speed The fan speed must be changed in the software of the boiler according to table 19.5: fan speed high fire Fan speed low fire parameter 92 parameter 93 Water heater type Propane G31 Nat. gas Propane G31 Nat.

  • Page 132: Condensate Drain

    Installation/start-up checklist Site information Installer information Site name Company Site contact Engineer name (owner/end-user) Address Address Postal code Postal code City City State/province State/province Telephone number Telephone number Boiler information After filling in form please send a copy to the distributor. Model Serial number Installation date...

  • Page 133: Combustion Settings

    Water circulation & temperature regulation (for DHW) Piping diameter Total length of straight pipe between boiler & tank Number of elbows Number of tees Temperature rise between inlet and outlet after 5 min. cold-start operating max. power °C / °F Water temperature setpoint Test of Water Flow Switch (DHW) ? (YES / NO)

  • Page 134: Inspection, Maintenance And Service

    20 INSPECTION, MAINTENANCE AND SERVICE. General For a good, safe and long-time operation of the boiler and to maintain warranty it is mandatory to carry out inspection, maintenance and service on the boiler at least once a year and/or after 2000 burning hours maximum, whichever comes first.
  • Page 135 the gas supplier who must read and follow the Installation, Operation, and Service Manual before performing any work on this boiler. Improper installation, adjustment, alteration, service or maintenance may cause property damage, serious injury (exposure to hazardous materials) or death. AVOID Breathing Fiber Particulates and Dust Precautionary Measures: Do not remove or replace RCF parts or attempt any service work involving RCF without following the guidelines...

  • Page 136: Customer Comments

    Inspection, maintenance and service. Inspection, maintenance and service including the replacement of boiler parts must only be carried out by a licensed professional, service agency or the gas supplier. Apart from the maintenance proceedings it is required to maintain a service log for each boiler that includes all of the following information: ...
  • Page 137 Dismount complete burner unit The complete burner unit consists of the fan, venturi, gas valve, the burner plate and the internal burner. To make more space to transport the burner unit pull down the burner controller unit. To dismount this part for an internal heat exchanger check: remove the six M6 nuts, the ignition cable, the thermal fuse cables and the gas valve cable.
  • Page 138 Ignition / ionization electrode When the burner unit is removed, it is very easy to check the ignition electrode. First check if the distances between the electrodes and between the electrode and the burner are according to the figure below. When these are not correct, try to bend the electrodes into the right position.
  • Page 139 Burner door gasket If any part of the gasket has discolored, changed texture, or hardened, the rubber has cured and/or has damages, these gaskets must be replaced. Notice: only use the gaskets that are supplied by the boiler manufacturer. Burner door gasket replacement: Figure 20.5 - Remove the old gasket - Place a new gasket in its groove.
  • Page 140 Warning Crystalline Silica – Read instructions of § 20.2 carefully Rear wall insulation disk If the insulation disk has been degraded or damaged, it has to be replaced. - be sure the heat exchanger has cooled down, wait a few hours after burning. In this way, the protective film on the new insulation disk will not stick to the rear side of the heat exchanger.
  • Page 141 When the fan blades are polluted and dirty, carefully clean the blades with a soft brush. Notice: do not use too much force on the blades or else the fan might be out of balance and run irregularly, causing noises and fan failures.

  • Page 142: Mounting The Burner Door

    20.3.1 M OUNTING THE BURNER DOOR IMPORTANT: Before mounting the burner door, make sure that its gaskets and insulation are in excellent shape. If any signs of damage or ageing are present, these parts must be replaced. The burner door must be mounted back on the heat exchanger as follows: Place the burner door with its holes over the six threaded studs.

  • Page 143: Maintenance Checklist

    Maintenance Checklist Allowing the boiler to operate with a dirty combustion chamber will affect operation. Failure to clean the heat exchanger as required by the manual and dictated by the operating location could result in boiler failure, property damage, personal injury, or death. WARNING Such product failures ARE NOT covered under warranty.

  • Page 144: User Instructions

    21 USER INSTRUCTIONS After installing and commissioning of the boiler, the installer is obliged to do the following:  Demonstrate the operation of the entire heating system to the end-user;  Make the user familiar with all safety precautions of the boiler and the installation ...
  • Page 145 System Example 3 Low Voltage Connections BOILER Name Wire terminal HEATING Room thermostat 12-13 ZONE Outdoor temperature sensor System temperature sensor Low loss header Line voltage Connections Boiler circulator 6-7-PE System heating circulator 4-5-PE EHS.D0501.B Figure 22.3 System Example 4 Low Voltage Connections BOILER Name...
  • Page 146 System Example 5 Low Voltage Connections Name Wire terminal BOILER Room thermostat 12-13 HEATING ZONE System temperature sensor Outdoor temperature sensor DHW Tank thermostat or sensor Low loss header DHW indirect Tank Non-return valve (low resistance type) Line voltage Connections Boiler circulator 6-7-PE DHW primary circulator...
  • Page 147 System Example 7 BOILER 1 BOILER 2 BOILER 3 BOILER 4 managing depending 1 depending 2 depending 3 HEATING ZONE EHS.D0501.B Low Voltage Connections Name Wire terminal Room thermostat 12-13 Outdoor temperature sensor System temperature sensor DHW Tank thermostat or sensor DHW indirect Tank Non-return valve (low resistance type) Low loss header...

  • Page 148: Spare Parts

    23 SPARE PARTS. CH–299 and CH–399 Figure 23.1 installation manual...
  • Page 149 Figure 23.2 CH Installation manual...
  • Page 150 CH–499 Figure 23.3 installation manual...
  • Page 151 Figure 23.4 CH Installation manual...

  • Page 152: Part Numbers

    Part numbers POS. DESCRIPTION Part Number CH–299 CH–399 CH–499 Set. Universal maintenance kit S000.500.011.035 Set. Electronics holder S000.500.002.035 Set. Anchoring bar CH–299 S000.500.008 Set. Anchoring bar CH–399 S000.500.009 Set. Anchoring bar CH–499 S000.500.010 Clip for WPS 10bar S001.500.003 Water pressure sensor 10bar S001.500.004 Nipple for RPS D15 S001.500.005...
  • Page 153 POS. DESCRIPTION Part Number CH–299 CH–399 CH–499 Venturi CH–299 S008.500.004 Venturi CH–399 S008.500.008 Venturi CH–499 S008.500.009 Modulating gas valve VR4615 (120VAC) S008.500.005.035 Radial Blower RG148/300W (120VAC) S008.500.024.035 Mounting plate silencer S008.500.019 Wall mounting plate S009.100.001 Front panel S010.500.001.035 Side panel right S011.500.001 Side panel left S011.500.002...
  • Page 154 POS. DESCRIPTION Part Number CH–299 CH–399 CH–499 Ty-Rap Heat resistant 3,5x200 mm S033.500.006 Hose clamp Ø20,62 (DW13) S033.500.007 Hose clamp Ø12,7 (DW8) S033.500.015 Cable tie with rivet S033.500.009 PVC bracket Ø60 S033.500.010 NPT Male Connector 3/8 S033.500.012 NPT Female Connector 3/8 S033.500.013 Hose pressure switch S034.500.001...
  • Page 156 IN USA CONTACT: IN CANADA CONTACT: Granby Industries L.P. Industries Granby S.E.C. 98 des Industries, 2260 Dwyer Avenue, Utica, NY 13501 Cowansville, Qc. Tel. 800 325 5479 J2K 0A1. Canada. www.ecrinternational.com 450-378-2334 www.granbyindustries.com supporttechnique@granbyindustries.com...

This manual is also suitable for:

Ch-399Ch-499

Table of Contents
