Total TG513326 Original Instructions Manual

Mini grinder 130w

Advertisement

Available languages

Available languages

MINI GRINDER
TG513326,UTG513326,TG513326-4,TG513326-7,
TG513326E
EN
Mini Grinder
ES
Mototool
TOTAL TOOLS WORLD
SCAN FOR VIDEO
130W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TG513326 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Total TG513326

  • Page 1 MINI GRINDER TG513326,UTG513326,TG513326-4,TG513326-7, TG513326E Mini Grinder Mototool TOTAL TOOLS WORLD SCAN FOR VIDEO 130W...
  • Page 2 “Original Instructions" To ensure safe operation when using your Rotary Tool, make sure you follow basic safety principles to reduce risk of personal injury, electric shock, and fire. Please read the following instructions prior to operating this product and keep for future use.
  • Page 3 24. Keep work area clean. Cluttered areas and benches invite injuries. Remove adjusting keys and wrenches. Form the habit of checking to see that wrenches are removed from the tool before turning it on. Ensure that the abrasive product is correctly mounted and tightened before use and run the tool at no-load for 30 s in a safe position, stop immediately if there is...
  • Page 4: Parts List

    Parts List Collet Nut Speed Selector Spindle Lock Button Power Cable Carbon Brush Holder On/Off Switch Accessories with 110pcs Accessories with 1pcs Flexible Shaft Dia 1 Environmental protection Recycle unwanted materials instead of disposing of them as waste. All tools and packaging should be sorted, taken to the local recycling centre and disposed of in an environmentally Safe way.
  • Page 5 Technical Specifications Model No. UTG513326 TG513326 TG513326E TG513326-4 (IRAM Plug) TG513326-7 (CHILE Plug) Rated power input 130W 130W Rated voltage 220-240V~50/60Hz 110-120V~50/60Hz No-load speed 10000-35000/min 10000-35000/min Weight 680g 680g Max collet diameter 3.2mm Double insulation Level of sound pressure measured A weighted level LP: 72 dB Vibration does not exceed: 0.5m/s...
  • Page 6: Maintenance

    Switching On and Off OFF ON Caution Setting the speed Fast Dia. 8 Note: Slow Holding the tool t to cover the ventilation slots. Note: MAINTENANCE Warning! Replacing the carbon brushes The carbon brushes must be checked on a Dia. 9 regular basis.
  • Page 7 The chart below lists the description, use speed and scope for some of the small articles supplied together with the tool by category. To achieve best performance of the tool, it is strongly recommended that you read it prior to operation, failure to adhere to this may cause accessories to fail.
  • Page 8 TG513326,UTG513326,TG513326-4,TG513326-7, TG513326E Exploded view...
  • Page 9 TG513326,UTG513326,TG513326-4,TG513326-7, TG513326E Spare part list Part Description Housing cap Collet nut Collet 698Z Bearing Rotor Carbon set Spindle lock set Spindle lock set Housing Hanger cord and plug Circuit board Stator Circuit board 696Z Bearing Screw ST3*15...
  • Page 10 Para asegurar la operación al usar su herramienta rotatoria, cerciórese de leer el manual y seguir principios básicos de seguridad para reducir el riesgo de daños corporales, de descarga eléctrica, y de fuego. Lea por favor las instrucciones siguientes antes de hacer funcionar este producto y guarde para el uso futuro.
  • Page 11 24 .Mantenga el área de trabajo limpia. Las áreas estorbadas y los bancos invitan a lesiones. 25 .Revise que ajusta los botones y las llaves. Forme el hábito de la comprobación para ver si las llaves se quitan de la herramienta antes de girarla.
  • Page 12: Lista De Partes

    Lista de partes 1 Tuerca collet Selector de velocidad 2 Boton de pare de giro Cable de poder 3 Soporte de brocha de carbono Interruptor encedido / apagado Accessorios con 110pcs Accessorios con 1pcs Eje flexible Dia 1 protección medioambiental Recicle los materiales indeseados en vez de disponer de ellos como basura.
  • Page 13: Instrucciones De Operación

    Especificaciones TG513326-7 (CHILE Plug) TG513326 TG513326E TG513326-4 (IRAM Plug) UTG513326 tecnicas 110-120V~50/60Hz 220-240V~50/60Hz Entrada de potencia nominal: 130W 130W Tension nominal: Sin velocidad de carga: 10000-35000/min 10000-35000/min 680g 680g Peso: 3.2mm Diametro máximo del collet Aislamiento doble: Niveles de presión de sonido registrados...
  • Page 14: Mantenimiento

    Cambiando de encendido a apagado. OFF ON Precaució n: Ajuste a la velocidad má s lenta, antes de prenderla. Para poner la herramienta en encendido poner en 'l', vé ase dia7. Para cambiar la herramienta a apagado, marcalo en posición «O» Ajustando la velocidad La herramienta tiene un control de velocidad variable Fast...
  • Page 15 El cuadro de abajo muestra la descripció n, uso de velocidad y el alcance de algunos de los pequeños objetos que se suministran junto con la herramienta por categorí a. Para lograr el mejor rendimiento de la herramienta, se recomienda encarecidamente que lo lea, antes de la operació...
  • Page 16 TG513326,UTG513326,TG513326-4,TG513326-7, TG513326E VISTA DESARROLLADA...
  • Page 17 TG513326,UTG513326,TG513326-4,TG513326-7 ,TG513326E LISTA DE REPUESTOS Part Description Housing cap Collet nut Collet 698Z Bearing Rotar Carbon set Spindle lock set Spindle lock set Housing Hanger cord and pluy Circuit board Stator Circuit board 696Z Bearing Screw ST3*15...
  • Page 18 MINI GRINDER www.totalbusiness.com TOTAL TOOLS CO., PTE. LTD. No. 45 Songbei Road, Suzhou Industrial Park, China. MADE IN CHINA T1022.V03...
