- Page 1 BATTERY GRINDER...
-
Page 2: Security Instructions
Security instructions Caution Read all safety warnings and all instructions. Failure to follow all warnings and instructions may result in electrical shock, fire, and/or serious injury. The term “power tool” in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool. Note: Save all warnings and instructions for future reference. - Page 3 4) Use and care of tools a. Recharge the battery only with the charger specified by the manufacturer. An unsuitable charger can create a fire hazard. b. Use power tools only with specifically designated batteries. Use of other batteries may create a risk of injury or fire. c.
- Page 4 Do not expose battery to water Caution Only use original TOTAL batteries. The use of non-original batteries, or batteries that have been altered, may result in the battery exploding and causing fire, personal injury and damage. It will also void the ENTIRE warranty on the ENTIRE tool and ENTIRE...
-
Page 5: Additional Security Warnings
Tips to maintain maximum battery life: Charge the battery cartridge before it is fully discharged. Always stop tool • operation and charge the battery cartridge when you notice less power from the tool. Never recharge a fully charged battery cartridge. Overcharging shortens battery •... - Page 6 accessory can break loose and cause injury beyond the immediate area of operation. Hold the power tool by insulated gripping surfaces only, when performing an • operation where the tool or cutting tool may come into contact with cables and/or pipes (including its own cable). It may cause an accident or electric shock to the operator.
-
Page 7: Other Risks
Always use the proper flanges for the correct size and design of discs. Flanges • for cut-off wheels may be different from flanges for grinding wheels. Do not use worn wheels from larger power tools. The blade intended for a •... -
Page 8: Technical Data
Caution This power tool produces an electromagnetic field during operation. This field can, in some circumstances, interfere with active or passive medical implants. To reduce the risk of serious injury, we recommend that persons with medical implants consult their physician before using this power tool. If the cable is damaged or cut during work, do not touch the cable, immediately unplug the tool. - Page 9 Set up Functioning Always make sure the tool is turned off and the battery cartridge is removed before adjusting or checking the function on the tool. Installing or removing the battery cartridge 1. Button 2. Battery cartridge Attention • Always turn off the tool before installing or removing the battery cartridge. •...
- Page 10 1. Slide switch To start the tool, slide the slide switch to the “I” (ON) position by pressing the back of the slide switch. For continuous operation, press the front of the slide switch to lock it. To stop the tool, press the rear of the slide switch and then slide it to the “O” (OFF) position.
- Page 11 Firmly screw the side grip into the position of the tool as shown in the figure. NOTE: This handle must be used at all times to maintain full control of the tool. Installing or removing the blade guard (for depressed center blade, abrasive/multi-disc cut-off wheel, diamond blade) Attention When using a depressed center/multi-disc grinding wheel, wire wheel brush,...
- Page 12 For tool with locking screw type wheel guard 1. Disc guard 2. Bearing housing 3. Screw • Mount the blade guard with the protrusions on the blade guard band aligned with the notches in the bearing frame. Then rotate the wheel guard about 180° counterclockwise. •...
- Page 13 Installation or removal of abrasive disc (optional accessory) 1. Sanding the locknut 2. Abrasive disc 3. Rubber pad • Mount the rubber pad on the shaft. Place the disc on the rubber pad and screw the locknut onto the spindle. •...
- Page 14 During the break-in period with a new wheel, do not work the grinder in direction • B or it will cut the workpiece. • Once the edge of the wheel has rounded off with use, the wheel can be worked in both the A and B directions.
- Page 15 1. Wire cup brush Remove the battery cartridge from the tool and turn it upside down to allow • easy access to the spindle. Remove all accessories from the spindle. • Thread the wire cup brush onto the spindle and tighten with the wrench •...
-
Page 16: Maintenance And Troubleshooting
Dispose of old discs correctly and responsibly. If working with aluminum or the like, the disc will soon clog and will not sand • effectively. Note: If you cannot find the fault, contact your official Total dealer. -
Page 17: Exploded View
Environment • Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local authority for information on available collection systems. • If electrical appliances are disposed of in landfills, hazardous substances can • seep into the groundwater and enter the food chain, harming your health and well-being. - Page 18 BATTERY GRINDER...
