l e x
F
W1077-835
Friendship Table
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent damage to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A. Table Top
1 piece
Hardware List
1.Flat Washer
Φ5/16*19*1.5mm
44 pieces
5.Hex Key
110*25*4mm
1 piece
Tool(s) recommended for assembly: Level
t e e l
B. Table Leg
4 pieces
2.Spring Washer
Φ5/16"
44 pieces
R
Assembly Instructions 1/3
C. Connecting Panel
2 pieces
3.Long Bolt
Φ5/16" - 18 UNC*32mm
pieces
28
D. Metal Bar
1 piece
4.Short Bolt
Φ5/16" - 18 UNC*20mm
pieces
16
