W1077-826
Sideboard
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent damage to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A. Sideboard
B. Center Support Leg
1 piece
Hardware List
1.Flat Washer
Φ1/4*19*1.5mm
12 pieces
5.Hex Key
110*25*4mm
1 piece
Tool(s) recommended for assembly: Level and Screwdriver
t e e l
C. Right Legs
1 piece
2 pieces
2.Spring Washer
Φ1/4"
12 pieces
6.Shelf Support
12 pieces
R
Assembly Instructions 1/5
D. Left Legs
E. Left Shelf
2 pieces
2 pieces
3.Long Bolt
Φ1/4" - 20 UNC*57mm
8 pieces
Anti-tipping Restraint
Long Screw
Short Screw
Anti-Tipping Device
1 set
F. Right Shelf
1 piece
4.Short Bolt
Φ1/4" - 20 UNC*20mm
4 pieces
