Power Recliner with Power Headrest and Lumbar
IMPORTANT NOTE
Read these instructions carefully, and familiarize yourself with
each procedure before assembling the furniture. Check that you
have all the component parts, and familiarize yourself with each
part before proceeding.
Take all the fittings out of the plastic bag and separate them into
groups. Ensure you have enough space to lay out all the parts
before assembly. To prevent damage to the parts, we recommend
that you assemble the unit on a soft, level surface.
Part List
A. Back Cushion
1 piece
B. Seat Cushion
1 piece
Assembly Instructions
STEP 1
Detach the transformer which tied to the bottom rail. (See Figure 1.)
Figure 1
A
B
Advertisement
Related Manuals for FLEXSTEEL Power Recliner with Power Headrest and Lumbar
Summary of Contents for FLEXSTEEL Power Recliner with Power Headrest and Lumbar
- Page 1 Power Recliner with Power Headrest and Lumbar IMPORTANT NOTE Read these instructions carefully, and familiarize yourself with each procedure before assembling the furniture. Check that you have all the component parts, and familiarize yourself with each part before proceeding. Take all the fittings out of the plastic bag and separate them into groups.
- Page 2 Assembly Instructions STEP 2 Attach the Back (A) to the Seat (B). Ensure the latches fit well. (See Figure 2.) Figure 2 STEP 3 Flip up the back flaps, plug the lumbar and headrest connectors(If applicable).(See the Figure 3.) Figure 3 Lumbar Headrest Headrest...
