W1077-840
Dining Chair
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent damage to the parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List
A. Backrest
1 piece
Hardware List
1.Flat Washer
Φ5/16*19*1.5mm
11 pieces
5.Short Bolt
Φ5/16" - 18 UNC*51mm
pieces
3
Tool(s) recommended for assembly: Level
t e e l
B. Seat Cushion
1 piece
2.Spring Washer
Φ5/16"
Φ5/16" - 18 UNC*89mm
11 pieces
6.Hex Key
110*25*4mm
1 piece
R
Assembly Instructions 1/3
3.Long Bolt
pieces
4
C. Front Leg
2 pieces
4.Medium Bolt
Φ5/16" - 18 UNC*64mm
pieces
4
