MikroTik wAP LR2 kit Quick Manual

EN - English - Quick Guide:
This device needs to be upgraded to RouterOS v7.7 or the latest version to ensure compliance with local authority regulations!
It is the end users' responsibility to follow local country regulations, including operation within legal frequency channels, output power, cabling
requirements, and Dynamic Frequency Selection (DFS) requirements. All MikroTik radio devices must be professionally installed
This "wAP LR2" series Quick Guide covers models: RBwAPR-2nD&R11e-LR2 (wAP LR2 kit).
This is a Wireless Network Device. You can find the product model name on the case label (ID).
Please visit the user manual page on
Technical specifications, brochures, and more info about products at
The most relevant technical specifications for this product can be found on the last page of this Quick Guide.
Configuration manual for software in your language with additional information can be found
MikroTik devices are for professional use. If you do not have qualifications please seek a
First steps:
Make sure your ISP is allowing hardware change and will issue an automatic IP address;
Open the bottom lid;
Connect an external antenna to the SMA connector;
Connect the device to the power source;
Connect with your device to the MikroTik wireless network;
Open https://192.168.88.1
The user name: admin and there is no password by default
Find your LR Gateway ID on the label within the product and register it in your Network Server;
Use the check for updates option and update your RouterOS software to the latest version, the device needs to have an active Internet connection;
After the update set your country, to apply country regulation settings;
Set your wireless network password;
Set the router password;
The following RouterOS "npk" packages are required for the core functionality of the product: lora, system.
Safety Information:
Before you work on any MikroTik equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents. The installer should be familiar with network structures, terms, and concepts.
Use only the power supply and accessories approved by the manufacturer, and which can be found in the original packaging of this product.
This equipment is to be installed by trained and qualified personnel, as per these installation instructions. The installer is responsible for making sure, that the
Installation of the equipment is compliant with local and national electrical codes. Do not attempt to disassemble, repair, or modify the device.
This product can be installed outdoors. Please read the mounting instructions carefully before beginning installation. Failure to use the correct hardware and
configuration or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
We cannot guarantee that no accidents or damage will occur due to the improper use of the device. Please use this product with care and operate at your own
risk!
In the case of device failure, please disconnect it from power. The fastest way to do so is by unplugging the power adapter from the power outlet.
This is a Class A product. In a domestic environment, this product might cause radio interference in which case the user might be required to take adequate
measures.
Exposure to Radio Frequency Radiation: This MikroTik equipment complies with the FCC, IC, and European Union radiation exposure limits set forth for an
uncontrolled environment. This MikroTik device should be installed and operated no closer than 20 centimeters from your body, occupational user, or the general
public.
Manufacturer: Mikrotikls SIA, Brivibas gatve 214i Riga, Latvia, LV1039.
Note: For some models, check the user and wireless passwords on the sticker.
BG - Български. Бързо ръководство:
Това устройство трябва да бъде надстроено до RouterOS v7.7 или най-новата версия, за да се гарантира спазването на местните регулаторни
разпоредби.
Крайните потребители са отговорни за спазването на местните разпоредби, включително работата в рамките на законни честотни канали,
извеждане на продукция изисквания за захранване, окабеляване и изисквания за динамичен избор на честота (DFS). Всички радиоустройства
на MikroTik трябва да бъдат професионално инсталиран.
Това бързо ръководство за серия "wAP LR2" обхваща модели: RBwAPR-2nD&R11e-LR2 (wAP LR2 kit).
Това е устройство за безжична мрежа. Можете да намерите името на модела на продукта на етикета на регистъра (ID).
Моля, посетете страницата с ръководството за потребителя на
Или сканирайте QR кода с мобилния си телефон.
Най-важните технически спецификации за този продукт могат да бъдат намерени на последната страница на това Кратко ръководство.
Технически спецификации, брошури и повече информация за продуктите
Ръководство за конфигуриране на софтуер на вашия език с допълнителна информация можете да намерите на
Устройствата MikroTik са за професионална употреба. Ако нямате квалификация, моля, потърсете
Първи стъпки:
https://mt.lv/um for the full up-to-date user manual. Or scan the QR code with your mobile phone.
in your web browser to start the configuration;
https://mikrotik.com/products
at https://mt.lv/help
consultant https://mikrotik.com/consultants
;
https://mt.lv/um-bg за пълното актуализирано ръководство за употреба.
на https://mikrotik.com/products
https://mt.lv/help-bg
консултант https://mikrotik.com/consultants
