- Page 1 Mercenary Mercenary Modern Series Fixed-Biased High-Gain Tube Amplifier (Mark II) 50W Head or 2x12 Combo 60W Head or 2x12 Combo 100W or 120W Head Owner’s Manual www.sonictoneamps.com Made in the USA...
-
Page 2: Table Of Contents
Table of Contents Introduction ............... Safety Instructions ............Features ................Front Panel ................. Rear Panel ................Warranty ................Sample Settings ............... Specifications ..............SonicTone Amplification, LLC P.O. Box 24456 New Orleans, LA 70184 contact@sonictoneamps.com www.sonictoneamps.com Made in the USA... -
Page 3: Introduction
Introduction I’d like to personally thank you for purchasing the SonicTone Mercenary tube amplifier. I know how important every player’s tone is to them and that consideration goes into every amp. Part of the flagship Modern Series line up, the Mercenary is a pure no-frills, purpose-built high gain amp. -
Page 4: Features
Features The Mercenary is a fixed-biased tube amplifier that uses four (4) 12AX7 preamp tubes. The 50-watt model uses two (2) EL34 power tubes and the 60-watt model uses two (2) 6L6 power tubes. The 100-watt model uses four (4) EL34 power tubes and the 120-watt model uses four (4) 6L6 power tubes. -
Page 5: Front Panel
Front Panel Pilot Light – illuminates when the amp is turned on. Power Switch – turns the amp on. Standby Switch – allows the amp to be played. When the standby is off, the tubes are kept warm, but the amp will not make any sound. Master –... -
Page 6: Rear Panel
Rear Panel Footswitch Jack – 5-pin DIN jack to plug the provided footswitch cable into. FX Loop Send Jack – mono input jack for the FX loop instrument level send signal. FX Loop Bypass Switch – switch to fully bypass the FX loop circuit. FX Loop Return Jack –... -
Page 7: Warranty
Rear Panel (continued) Parallel Speaker Jacks – mono input jacks to plug the speaker(s) into. PLEASE NOTE: The jacks are in parallel, so if you plug two equal impedance speaker loads into them, you must set the impedance switch to half their impedance. -
Page 8: Sample Settings
Sample Settings Channel 1 - Chimey Clean: STANDBY MASTER RESONANCE PRESENCE BASS MIDDLE TREBLE VOL 2 LEAD VOL 2 RHYTHM GAIN 2 GAIN 1 CH 1 INPUT CH 2 BOOST LEAD RHYTHM BRIGHT NORMAL Channel 1 - Edge of Breakup: Channel 1 - Blues Crunch: Channel 2 - Hard Rock: Channel 2 - Modern Rock/Metal:... -
Page 9: Specifications
2x12 Combo Width: 30 in Width: 30 in Height: 10.75 in Height: 20.75 in Depth: 9 in Depth: 10 in Weight: 33lbs/42 lbs Weight: 56lbs www.sonictoneamps.com Made in the USA The SonicTone logo is a registered trademark of SonicTone Amplification, LLC.
