- Page 1 Classic Series 30-Watt Cathode-Biased Tube Amplifier Head or 2x12 Combo Owner’s Manual www.sonictoneamps.com Made in the USA...
-
Page 2: Table Of Contents
Table of Contents Introduction ............... Safety Instructions ............Features ................Front Panel ................. Rear Panel ................Warranty ................Specifications ..............SonicTone Amplification, LLC P.O. Box 24456 New Orleans, LA 70184 contact@sonictoneamps.com www.sonictoneamps.com Made in the USA... -
Page 3: Introduction
Introduction I’d like to personally thank you for purchasing the SonicTone Royal Crown 30 (RC30) tube amplifier. I know how important every player’s tone is to them and that consideration goes into every amp. Carefully designed and hand-built here in the U.S., the RC30 is an influential circuit that has been used to power classic rock for decades. -
Page 4: Features
Features The Royal Crown 30 (RC30) is a 30-watt, cathode-biased tube amplifier that uses four (4) 12AX7 preamp tubes, four (4) EL84 power tubes and one (1) GZ34 rectifier tube. Its features include: 2 independent channels with separate EQs Bright switch on channel 1 Hot/cool control on channel 2 Tone cut control No negative feedback... -
Page 5: Front Panel
Front Panel Pilot Light – illuminates when the amp is turned on. Power Switch – turns the amp on. Standby Switch – allows the amp to be played. When the standby is off, the tubes are kept warm, but the amp will not make any sound. -
Page 6: Rear Panel
Rear Panel 30-watt cathode-biased amplifier S / N : C S 0 5 0 0 0 0 0 0 0 0 0 0 4 x 12AX7; 4 x EL84; 1 x GZ34 SPEAKERS IMPEDANCE SERIES/ FOOTSWITCH FX RETURN FX SEND PARALLEL RETURN SEND... -
Page 7: Warranty
Rear Panel (continued) 30-watt cathode-biased amplifier GZ34 S / N : C S 0 5 0 0 0 0 0 0 0 0 0 0 MAINS 4 x 12AX7; 4 x EL84; 1 x GZ34 (0.5A SB) (2A SB) FULL POWER RECT HALF... -
Page 8: Specifications
Specifications Product Series: Classic Series Product Model: Royal Crown 30 (RC30) Head or 2x12 Combo AC Input & Fuses: U.S. Standard IEC jack rated for 120V @ 60Hz 2A slo-blo mains fuse 0.5A slo-blo high voltage (B+) fuse Tubes: Four (4) 12AX7 preamp tubes Four (4) EL84 power tubes One (1) GZ34 rectifier tube Power Output:...
