Thank you for purchasing this quality product. Be sure to check all packing materials
carefully for small parts, which may have come loose inside the carton during shipment.
ldentify and count all items and compare with the parts list and/or hardware list shown
below.
PARTS LIST
No.
DESCRIPTION
A
CHAIRBACK
B
CUSHION SEAT
FRONT LEG
C
DO NOT TIGHTEN LEGS UNTIL THE CHAIR IS FULLY ASSEMBLED
STEP 1:
Assemble the cushion seat (B) with the back legs of the chairback (A) by using Allen Key
(6) with hardware 3, 4, and 5.
**Attention: DO NOT TIGHTEN THE BOLTS.
A
STEP 2:
Place the chairback (A) on a soft and clean surface. Assemble the cushion seat (B) with
the chairback (A) by using Allen Key (6) with hardware 1,4, and 5.
**Attention: DO NOT TIGHTEN THE BOLTS.
B
A
Assembly Instruction
LYRA DINING CHAIR
D3765-20 LYRA DINING CHAIR (2 PER CARTON)
Q'TY
SKETCH
2
2
4
B
Page 1 of 2
HARDWARE LIST
No.
DESCRIPTION
1
2
3
4
Spring Washer (1/4 ")
5
Flat Washer (1/4 ")
6
Allen key M4
Q'TY
SKETCH
8
8
6
22
22
2
MADE IN VIETNAM
Created date : 2024-04-13
Advertisement
Related Manuals for New Classic Furniture LYRA D3765-20
Summary of Contents for New Classic Furniture LYRA D3765-20
- Page 1 Assembly Instruction LYRA DINING CHAIR D3765-20 LYRA DINING CHAIR (2 PER CARTON) Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. ldentify and count all items and compare with the parts list and/or hardware list shown below.
- Page 2 Assembly Instruction LYRA DINING CHAIR D3765-20 LYRA DINING CHAIR (2 PER CARTON) STEP 3: Assemble the front legs (C ) with the Cushion Seat (B) by using Allen Key (6) with hardware 2, 4, and 5. **Attention: DO NOT TIGHTEN THE BOLTS STEP 4: To level the chair, stand the chair up on a flat surface and tighten all the bolts by using Allen Key (6).
-
Page 3: Parts List
Assembly Instruction LYRA DINING TABLE D3765-10B LYRA PEDESTAL BASE D3765-10T LYRA DINING TABLE TOP AND BASE BOTTOM HARDWARE LIST PARTS LIST Q'TY Q'TY DESCRIPTION SKETCH DESCRIPTION SKETCH TABLE TOP ALLEN BOLT (5/16" x2-1/2") LEFT SIDE FACING (LSF) TABLE LEG ALLEN BOLT (5/16" x1-3/8") SPRING WASHER (5/16 ") RIGHT SIDE FACING (RSF) TABLE LEG TABLE BASE... - Page 4 Assembly Instruction LYRA DINING TABLE D3765-10B LYRA PEDESTAL BASE D3765-10T LYRA DINING TABLE TOP AND BASE BOTTOM STEP 3: Turn the assembled bottom piece right side up. Assemble the TABLE TOP CONNECTON PLATE (E) to the TABLE LEGS (B & C) by using ALLEN KEY (6) with hardware 2, 3, and 4.
- Page 5 Assembly Instruction LYRA DINING TABLE D3765-10B LYRA PEDESTAL BASE D3765-10T LYRA DINING TABLE TOP AND BASE BOTTOM STEP 5: Assemble the bottom piece with the TABLE TOP (A) by using ALLEN KEY (6) with hardware 2, 3, and 4. STEP 6: To level the table, place the table right side up on a flat surface and adjust the levelers. Leveler MADE IN VIETNAM Created date : 2024-04-04...
