New Classic Furniture MING D3660-10 Assembly Instruction

Thank you for purchasing this quality product. Be sure to check all packing materials carefully for
small parts, which may have come loose inside the carton during shipment. Identify and count all
items and compare with the parts list and/or hardware list shown below.
Please read all instructions carefully. See the hardware and furniture part listing for guidance. Be
sure you have all parts listed before beginning assembly. Place all wooden parts on a clean, flat
surface to protect the finish from scratches. Follow the diagram to assemble.
CAUTION
1. Do not fully tighten the nuts or bolts until the table is fully assembled.
2. Please tighten by hand, not by a drill. Overtightening will damage threads. Do not
overtighten.
3. Keep all hardware out of the reach of children.
PARTS LIST
ITEM DESCRIPTION
A GLASS TOP
B SUPPORT LEG
C SUPPORT BAR
D CENTER STRETCHER UPPER
E CENTER STRETCHER LOWER
STEP 1
DO NOT fully tighten screws, leave finger tight until turning base upright
B
ASSEMBLY INSTRUCTION
MING
COLLECTION
MODEL : D3660-10 DINING TABLE
SKETCH
QTY
1 PC
4 PCS
4 PCS
1 PC
1 PC
E
1 of 2
HARDWARE LIST
ITEM DESCRIPTION
1
JCBC M6 x 45
2 SPRING WASHER M6
CSK SCREW M4 X 32
3
4
5
GLASS SUPPORT BOLT M6 X 20
6
M4 ALLEN KEY
CSK SCREW M4 X 38
7
7
QTY
SKETCH
16 PCS
16 PCS
6 PCS
4 PCS
4 PCS
1 PC
16 PCS
6
1
2
8 X 8 X
