Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts,
which may have come loose inside the carton during shipment. Identify and count all items and compare with
the PARTS LIST and/or HARDWARE LIST shown below.
Please read the instructions thoroughly before assembly.
1. We recommend that you assemble this product with the assistance of another person; this will make the
assembly easier, and will help eliminate damage to the product or injury to persons during assembly.
2. Please do not tighten screws or bolts until the assembly is completed.
3. To level the chairs or table, before tightening all the screws, the chairs or table must be place on a flat
surface and then tighten the screws.
4. Please put all parts on a non-abrasive floor before assembly and follow the assembly steps to assemble
your newly purchased product correctly and efficiently.
PARTS LIST
NO.
COMPONENT
A
CHAIR BACK
CUSHION
B
SEAT
C
FRONT LEG
SKETCH
QTY.
2 PCS
2 PCS
4 PCS
MADE IN VIETNAM
ITEM NO.D3832-20
HUDSON DINING CHAIR
(2 PER CARTON)
HARDWARE LIST
NO.
COMPONENT
FLAT WASHER
1
5/16" DIA.
SPRING
2
WASHER
5/16" DIA.
NUT
3
5/16" DIA.
ALLEN
WRENCH
4
5/16" DIA.
SHORT BOLT
5
1/4" x 1 3/4"
LONG BOLT
6
1/4" x 3"
SKETCH
QTY.
22 PCS
22 PCS
8 PCS
1 PC
6 PCS
8 PCS
PAGE: 1 OF 2
Advertisement
Table of Contents
Related Manuals for New Classic Furniture HUDSON D3832-20
Summary of Contents for New Classic Furniture HUDSON D3832-20
- Page 1 Assembly Instructions ITEM NO.D3832-20 HUDSON DINING CHAIR (2 PER CARTON) Thank you for purchasing this quality product. Be sure to check all packing materials carefully for small parts, which may have come loose inside the carton during shipment. Identify and count all items and compare with the PARTS LIST and/or HARDWARE LIST shown below.
- Page 2 Assembly Instructions ITEM NO.D3832-20 HUDSON DINING CHAIR (2 PER CARTON) To assemble the chairs, please follow the following steps and repeat for each chair: STEP 1 STEP 2 Lay the chair back on soft clean surface and Insert long bolts to secure the cushion seat. install the cushion seat.
