Technical Support and E-Warranty Certificate www.vevor.com/support
Spool Gun HBT200
MODEL: XLHBTSR200
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only
represents an estimate of savings you might benefit from buying certain tools
with us compared to the major top brands and does not necessarily mean to cover
all categories of tools offered by us. You are kindly reminded to verify carefully
when you are placing an order with us if you are actually Saving
Half in comparison with the top major brands.

Advertisement

loading
Need help?

Need help?

Do you have a question about the HBT200 and is the answer not in the manual?

Questions and answers

Summary of Contents for VEVOR HBT200

  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support Spool Gun HBT200 MODEL: XLHBTSR200 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
  • Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are...
  • Page 3: Specifications And Parameters

    Operation Manual Please Carefully read the operation manual prior to using, installing and maintaining the electric welding machine for the purpose of preventing damages such as fire, electric shock and etc from occurring.Please keep the manual for the reference in the future Specifications and Parameters Model XLHBTSR200...
  • Page 4 1. Connecting Spool Gun Machine 1 Spool Gun 2 Drive Assembly 3 Gun End 4 Gun Securing Knob Loosen gun securing knob. Insert gun end through opening until it bot-toms against drive assembly. The black o-rings should not be visible.Tighten the gun securing knob.
  • Page 5: Opening Cover

    2. Opening Cover 1 Thumbscrew 2 Cover Loosen thumbscrew and rotate cover open. 3 Installing Wire Spool And Threading Welding Wire 1 Cover 2 Canister 3 Thumbscrew (Cover) Cover Canister Thumbscrew (Cover) 4 Wire Spool Loosen wire from spool, cut off bent wire, and pull 6 in (150 mm) of wire off spool.
  • Page 6 4 Adjusting Drive Roll And Spool Brake Pressure 1 Thumbscrew 2 Cover Loosen thumbscrew and rotate cover open. 3 Spool Cut welding wire off at contact tip. Retract wire onto spool and secure. 4 Spool Brake Thumbnut Grasp spool in one hand and turn while adjusting spool brake thumb-nut.
  • Page 7 5. Gun Drive Assembly Maintenance Retract wire onto spool. 1 Setscrew 2 Drive Roll Use stainless steel wire brush to clean drive roll. install drive roll with desired groove down, and turn drive roll so one setscrew faces flat side of shaft. 3 Bearing Use stainless steel wire brush to clean bearing.
  • Page 8 6. Replacing Inlet Guide 1 Cover 2 Pressure Roll Assembly Cut off welding wire where it enters pressure roll assembly area. 3 Nozzle Pull wire out nozzle end. 4 Thumbscrew Loosen thumbscrew and rotate cover open. 5 Wire Spool 6 Spool Brake Thumbnut Loosen thumbnut, retract wire onto spool, secure, and remove spool.
  • Page 9 Connector Pin-out(as following picture shows) Pin No. Function Gun Cable Lead Color Trigger Blue Trigger Brown + Motor Yellow -Motor Black...
  • Page 10: Fcc Information

    Product Selling Points: 1 Replacement torch model: SpoolRunner 200 2 Adaptive Welding Machines: Handler 210 MVP 3 Maximum rated current: 200A 4 Lead Length: 20 feet 5 wire diameter: 0.030"/0.035" 6 Conductive nozzle included: 0.030"*2pc / 0.035"*1pc. 7 Suitable for aluminum welding, also for mild and stainless steel wires 8 Tool-less removal of header tubes, easy loading and unloading of cords with pressure bar 9 Quick access to wire compartments with hinged flip-top lid...
  • Page 11: Correct Disposal

    CORRECT DISPOSAL This product is subject to the provision of european Directive 2012/19/EU. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories marked with this symbol.
  • Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...

This manual is also suitable for:

Xlhbtsr200
